- Page 1 USER GUIDE 0.9 Cu. Ft. Microwave Oven NS-MW09RD7 Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
NS-MW09RD7 NS-MW09RD7 0.9 Cu. Ft. Microwave Oven Por table CD Player with FM Tuner Contents SAFETY INFORMATION ......3 Cookware and cooking materials . -
Page 3: 0.9 Cu. Ft. Microwave Oven
0.9 Cu. Ft. Microwave Oven SAFETY INFORMATION PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY: 1 Do not attempt to operate this oven with the door open because this can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. - Page 4 NS-MW09RD7 iv) Do not use the oven cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the cavity when not in use. 5 This oven must be grounded. Connect only to a properly grounded outlet. See “GROUNDING INSTRUCTIONS” found on page 5.
-
Page 5: Save These Instructions
0.9 Cu. Ft. Microwave Oven v) Use extreme care when inserting a spoon or other utensil into the container. WARNING Handling the power cord on this oven, or cords associated with accessories sold with this oven, will expose you to lead, a chemical known to the state of California to cause cancer and birth defects or other reproductive harm. -
Page 6: Cookware And Cooking Materials
NS-MW09RD7 • The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally. RADIO INTERFERENCE 1 Operation of the microwave oven may cause interference to your radio, TV, or similar equipment. -
Page 7: Materials You Can Use
0.9 Cu. Ft. Microwave Oven Materials you can use Material Remarks Use as shielding only. Small, smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if the Aluminum foil foil is too close to oven walls. The foil should be at least 1 inch (2.5 cm) away from oven walls. -
Page 8: Features
NS-MW09RD7 Material Remarks Paper bags May cause a fire in the oven. Plastic foam may melt or contaminate the liquid inside when exposed to Plastic foam high temperature. Wood will dry out when used in the microwave oven and may split or Wood crack. -
Page 9: Control Panel
0.9 Cu. Ft. Microwave Oven Control panel Item Description In standby mode, displays the time. In cooking mode, displays Display cooking time, weight, and other information. Time Defrost Press this button, then enter the time you want for an item to defrost. Time Cook Press this button, then enter the time you want for an item to cook. -
Page 10: Setting Up Your Microwave Oven
NS-MW09RD7 Item Description Press to set the clock, then press the number buttons to enter the Clock current time. Press to enter cook time, defrost time, clock time, and other Number buttons information. Press to stop the cooking process. Press again to cancel the cooking STOP/Cancel operation. -
Page 11: Installing The Turntable
0.9 Cu. Ft. Microwave Oven 5 Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating label. Caution Do not install your oven over a range cooktop or other heat-producing appliance. -
Page 12: Using Your Microwave Oven
NS-MW09RD7 Using your microwave oven Understanding and setting the power level The following table shows the 11 power levels available. Level Power 100% 90% Display PL10 1 Press POWER once. The display shows “PL10” (the default power is 100%). 2 Press the number keys to adjust the power level. For example, press 5 to set the power level to 50%. -
Page 13: Defrosting In Your Microwave Oven
0.9 Cu. Ft. Microwave Oven 3 Press POWER once. The display shows “PL10” (the default power is 100%). 4 Press the number keys to adjust the power level. For example, press 5 to set the power level to 50%. 5 Press START/+30SEC. to start cooking. Notes •... -
Page 14: Cooking Popcorn
NS-MW09RD7 Defrosting by time 1 Press TIME DEFROST. The display shows “dEF2. ” 2 Press the number buttons to input the defrosting time you want. The time range must be between 00:01 and 99:99. 3 The default microwave power for Time Defrost is power level 3. If you want to change the power level, press POWER once. -
Page 15: Heating A Dinner Plate
0.9 Cu. Ft. Microwave Oven Heating a dinner plate 1 Press DINNER PLATE repeatedly until the size of the meal (in ounces) you want to heat shows on the display. The display cycles through "9.0">"12.0">"18.0" (oz.). 2 Press START/+30 SEC.. When the meal is heated, the buzzer sounds five times and the oven returns to standby mode. -
Page 16: Using Multi-Stage Cooking
NS-MW09RD7 Using multi-stage cooking Up to two stages can be used to cook your food. For example, you can defrost a meal, then cook it. In this example, the food will be cooked with 80% power for five minutes, then 60% power for 10 minutes. -
Page 17: Troubleshooting
0.9 Cu. Ft. Microwave Oven Troubleshooting If you have a problem with your oven, review the following chart for a possible solution. If the oven still does not work properly, contact the nearest authorized service center. Problem Possible cause Possible solution The electrical cord is not plugged Plug in the electrical cord. -
Page 18: Specifications
27.6 lbs. (12.5 kg) Legal notices Copyright INSIGNIA is a trademark of Best Buy and its affiliated companies. Registered in some countries. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2016 Best Buy. All rights reserved. -
Page 19: One-Year Limited Warranty
Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. - Page 20 Damage due to incorrect operation or maintenance • Connection to an incorrect voltage or power supply • Attempted repair by any person not authorized by Insignia to service the Product • Products sold “as is” or “with all faults” •...
- Page 21 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC V1 ENGLISH ©2016 Best Buy. All rights reserved. 16-0037 Made in China.
