StarTech.com 2M2DC-NVME-ENCLOSURE Quick Start Manual

USB-C Dual Bay M.2 NVMe Reader and Standalone Duplicator Enclosure
Product ID
2M2DC-NVME-ENCLOSURE
Top
1
2
Front
3
Rear
6 7
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
4
5 5
8 9
Component
•
1 Drive Tray Cover
•
2 Drive Tray Cover Screw
•
3
Progress LED Indicators
•
4 Drive LEDs
•
•
•
5 Power LED
•
6 Clone Button
•
•
7
USB-C Aux Power Port
•
8
USB-C 10Gbps Host Port
9 Mode Selector Switch
•
Requirements
M.2 NVMe Drive(s)
•
Phillips Head Screwdriver x 1
•
USB-C Power Source (Required for dual-drive use)
•
For the latest product information, technical specifications, and declarations of
conformance, please visit: www.StarTech.com/2M2DC-NVME-ENCLOSURE
Package Contents
M.2 NVMe Enclosure x 1
•
USB-C Cable x 1
•
Set of Rubber M.2 Standoffs x 1
•
Quick-Start Guide x 1
•
Quick-Start Guide
Function
Protects the Source and Target M.2 NVMe
Drives
Secures the Drive Tray Cover to the M.2 NVMe
Enclosure
Indicates progress from 25% to 100% during the
Drive Cloning process
Individual LEDs for Source and Target Drive
detection
Solid LEDs: Drive(s) detected
Quick-Flashing LEDs: Read/Write Activity
Lights up when the M.2 NVMe Enclosure is
powered on
Starts the Drive Cloning process
See Operation section for more information
Connect the M.2 NVMe Enclosure to a USB-C
Power Source
Connect the M.2 NVMe Enclosure to an available
USB-C Port on a Host Computer
Only required for PC Mode
•
Switch between PC Mode or Clone Mode
Manual Revision: August 15, 2024
