User Manual
SOFTBOX
UltrapanelPRO 30 - SuperpanelPRO 30
UltrapanelPRO 60 - SuperpanelPRO 60
DayledPRO 650 / 1000 / 2000 / 3000
SuperpanelPRO 30 and UltrapanelPRO 30 instructions
SuperpanelPRO 30
Softbox
UltrapanelPRO 30
To use the softbox, open the velcro string
at the edges of the panel and make sure to
tighten it. (fig 1)
Attention: please note this is the right way to
mount the softbox on the SuperpanelPRO 30 or the
UltrapanelPRO 30. (fig 2)
fig. 2
Please use the strap on the back to secure the
softbox to the panel. (fig. 3)
White
Eggcrate
Diffuser
fig. 1
fig. 3

Advertisement

loading
Need help?

Need help?

Do you have a question about the UltrapanelPRO 30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lupo UltrapanelPRO 30

  • Page 1 SuperpanelPRO 30 and UltrapanelPRO 30 instructions SuperpanelPRO 30 Softbox White Eggcrate UltrapanelPRO 30 Diffuser To use the softbox, open the velcro string at the edges of the panel and make sure to tighten it. (fig 1) fig. 1 Attention: please note this is the right way to mount the softbox on the SuperpanelPRO 30 or the UltrapanelPRO 30.
  • Page 2 SuperpanelPRO 60 and UltrapanelPRO 60 instructions DayledPRO 650, DayledPRO 1000 and DayledPRO 2000 instructions Install the softbox on the SuperpanelPRO 60 and the UltrapanelPRO 60. The black velcro string goes to the back of the panel to secure tightly the softbox. (fig 1) DayledPRO 650 Barndoors Softbox...
  • Page 3 DayledPRO 3000 instructions DayledPRO 3000 Barndoors Softbox 30 White Diffuser Pass the strings through the rod of the barndoor (fig.1) and attached them on the velcro. (fig.2) fig. 1 fig. 2 Press the barndoors to the softbox for a complete grip. (fig.3) Add the white diffuser at the velcro.
  • Page 4 Pass the strings bhind the panel and tighten them with the velcro. (fig. 3) fig. 3 fig. 3 Lupo srl Via V. Sassi 28/30 - Collegno (TO) - 10093 - Italy phone: +39 011 411 9919 / e-mail: contact@lupo.it website: www.lupo.it...
