Superpanel 30
User Manual
SUPERPANEL DUAL COLOR 30 HARD
SUPERPANEL DUAL COLOR 30 SOFT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Superpanel 30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lupo Superpanel 30

Summary of Contents for Lupo Superpanel 30

  • Page 1 Superpanel 30 User Manual SUPERPANEL DUAL COLOR 30 HARD SUPERPANEL DUAL COLOR 30 SOFT...
  • Page 2 Thanks for having purchased Lupo products. All the products are made in Italy and all the efforts have been put to keep the quality standards high. We hope this product can help you in your job and make your life easier as a professional.
  • Page 3 Instructions • Device for indoor use only. • Maximum ambient temperature: 35 °C. • Make sure power supply plug is suitable to power required. • As prescribed by international regulations, a safety cable must be used when the fixture is suspended from ceiling.

  • Page 4: Control Panel

    6. See DMX PROTOCOL MANUAL to DMX channel specification. NOTE: The symbol - ! - on the display indicates that there is no DMX signal. * The name of the mode changes according to the Superpanel 30 version: mono or dualcolor.

  • Page 5: Light Modes

    DMX OPERATION - Advanced Settings 1. Press the « OK » button to enter the main MENU. 2. Navigate through the main MENU with the « » or « » buttons to the DMX item, select by pressing the « OK » button.
  • Page 6 DMX OPERATION - DMX protocol The Superpanel 30 can be used with 8 bit (1 channel per function) and 16 bit (2 channels per function). The Superpanel 30 uses consecutive channels starting from the DMX address set on the panel used as reference for the connection to the control desk. Please take the above into consideration when using many units of Superpanel 30 to avoid overlaps.

  • Page 7: Device Settings

    DEVICE SETTINGS 1. Press the « OK » button to enter the main MENU. 2. Navigate through the MENU using the « » or « » buttons, select DEVICE SETTINGS, press the « OK » button to confirm the selection. 3.
  • Page 8 AC input: 100 V - 240 V DC output: 24 V ATTENTION: Please keep the original package of the product in a safe place for warranty reasons. Superpanel 30 USB port Use USB port for firmware updates. MENU e submenus - Select “EXIT”...
  • Page 9 DMX Protocol Introduction The Superpanel Full Color 30 can be used with 8 bit or 16 bit DMX control. (See DMX OPERATION - advanced settings in the user's manual). When used in 8 bit mode the Superpanel Full Color 30 uses one channel for each function. DMX values for each channel are in the range of 0 to 255.
  • Page 10 Dayled 1000 mono color 0x0003 Dayled 1000 dual color 0x0004 Dayled 2000 mono color 0x0005 Dayled 2000 dual color 0x0006 Superpanel 30 dual color soft 0x0007 Superpanel 30 dual color lens 0x0008 Superpanel 30 fullcolor soft 0x0009 Superpanel 30 fullcolor lens 0x0010...
  • Page 11 0: linear 1: exponential 2: logarithmic 0: full speed 1: normal speed 2: high speed 3: FILTER 0x8007 low speed Lupo srl - Via V. Sassi 28/30 Collegno (TO) - 10093 - Italy Phone: +39 011 411 9919 / e-mail: contact@lupo.it / website: www.lupo.it...

This manual is also suitable for:

Superpanel dual color 30 hardSuperpanel dual color 30 softSuperpanel soft 30Superpanel dual color 30Superpanel soft dual color 30
