Server IxD Flavor+ Manual

Syrup dispenser, general market
Hide thumbs

Advertisement

Quick Links

Download this manual
Thank you for purchasing the IxD
This unit dispenses up to fourteen flavors with a push of a button and
is clean-in-place certified for easy clean-up.
S I M P L I F Y I N G F L A V O R M A N A G E M E N T
Model: General Market
Dispense precise portions of
up to fourteen syrup and sauce
flavors and maximize workflow
with one centralized modular
unit that creates a complete
menu of perfectly sweet
beverages.
Electronic Dispense
Series FLAVOR+
™
™
WI-FI
Syrup Dispenser.

Advertisement

loading
Need help?

Need help?

Do you have a question about the IxD Flavor+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Server IxD Flavor+

Summary of Contents for Server IxD Flavor+

  • Page 1 Model: General Market Dispense precise portions of up to fourteen syrup and sauce flavors and maximize workflow with one centralized modular unit that creates a complete menu of perfectly sweet beverages. Electronic Dispense WI-FI Thank you for purchasing the IxD Series FLAVOR+ Syrup Dispenser.

  • Page 2: Safety - Parts

    WARNING - Be aware of the product you are serving and the temperature the product is required to maintain. Server Products, Inc. cannot ELECTRICAL SHOCK COULD OCCUR be responsible for the serving of potentially hazardous product. This unit must be earthed or grounded.
  • Page 3 Parts PATENT PENDING (14) Flavor Stacked Configuration - 101575 COMPLETE UNIT 101575 CABINET C1 CABINET B2 101450 101494 CABINET A1 101962 CABINET B1 101454 GENUINE OEM PARTS...
  • Page 4 Cabinet Combinations L = Fits Large Bottles Cabinet Key S = Fits Standard Bottles (750ML - 1L Bottles) Back Connection #'s: 1-14 13-14 7-12 9-10 101962 Part #: 101505 101450 101503 101454 101494 101504 101495 102917 (Euro) Main Configurations 10 Flavors 14 Flavors 101576 101575...
  • Page 5 Initial Startup - What you will need KAY-5 Sanitizer/Cleaner Solution (2L per flavor) Clean, dry towels Sanitizer Container to hold 2L (per flavor) of sanitizer/ Dry erase markers cleaner solution 1L of rinse sanitizer (per flavor) if cleaning with Syrups of Choice detergent Container to receive flushed sanitizer/cleaner solution (2L per flavor)
  • Page 6 Summary of Assembly Instructions HELPFUL TIP: Have the unit turned 45° to you. This helps with the assembly process. ROTATE UNIT 45° Start by stacking unit as shown with backs facing you. Cabinets A & B1 (with base installed) on bottom. Cabinets B2 &...
  • Page 7 Summary of Assembly Instructions 101829 101826 (2X) Install 2 vertical brackets (101528). Install 2 horizontal brackets (101529). 101943 101942 Install rack support posts into the back wall and sides of each cabinet and install corresponding rack(s). 101943 101942 101943 101826 (2X) (25x) (4x) 101826 Front View Assembly...
  • Page 8 Detailed Assembly & Setup Instructions Remove Put the B or F cabinet next to the components from A cabinet. box. Depending on what was purchased, put the A unit on the counter where you plan to put it into service. Put drip tray into place.
  • Page 9 Detailed Assembly & Setup Instructions 101829 101826 (2X) 101943 101942 101943 101942 (25x) 101943 101826 (2X) (4x) 101826 UNIT FRONT (1x) 101829 Remove the knobs Looking at the from the two back back of the unit, stabilizing brackets put the second then place the long knob bracket into thin bracket over the...
  • Page 10 Detailed Assembly & Setup Instructions Using hoses from bags 101580, 101463, & 101738, connect the back tubing matching the number from the A unit with the corresponding number on the other cabinets. Do 12 11 this for all of the back connections. HELPFUL TIPS: Start with the highest number and work your way down to #1.
  • Page 11 Detailed Assembly & Setup Instructions You'll then be prompted In the next step, insert bottle to start the cleaning tubes into the cabinet fittings. process. The system will Be sure to select bottle tubes auto advance between with caps that match your cycles and prompt user bottles.
  • Page 12 Detailed Assembly & Setup Instructions If you are If cleaning more lines, prep the done cleaning sanitizing solution container and and ready to place an empty container under load bottles, the dispense point to receive setup the the flushed solution. Follow the products, and prompts.
  • Page 13 Detailed Assembly & Setup Instructions There are some generic recipes started or you can add your own by hitting the "+" button. Delete any recipes you won't be using. In the Recipe edit or addition screens you can modify the name, add or delete flavors, and modify portions by size.
  • Page 14 Detailed Assembly & Setup Instructions The system will ask you to prime each flavor and then press the forward arrow to complete priming. Be sure to have a container under the dispense point to receive product. Your unit is now setup and ready for use.
  • Page 15 How to use - Dispensing Place cup Select the under the portion you dispense want to point and dispense of select the that flavor desired flavor. by pushing the "+" or "-" button and then push "Dispense". To access preprogrammed recipes with multiple flavors and sizes, press the arrow button...

  • Page 16: How To Use - Menu

    How to use - Menu Pushing and "8306" holding the is the icon in the password upper left and hit the hand corner check-mark of the screen to enter. will take you to a login screen for user level access. You will then have access to the Menu screen.

  • Page 17: How To Use Settings

    How to use - Settings In the "Settings" screen, you can modify various settings: Recipe Setup - Add, delete, or modify recipes. Product Setup - Add, delete, or modify products. Line Setup - Assign, unassign, set container size, or calibrate. Factory Reset - All settings will be cleared and initial setup will be initiated.
  • Page 18 Cleaning Sanitizer Mix a packet of Kay-5 Press and hold the icon sanitizer in water between in upper left of the screen 75° and 90° F following the For each bottle, one at a This will take you to the (3-5 seconds).

  • Page 19: Troubleshooting

    Internal component not functioning properly. If screen does not turn on after 10 minutes, contact Server customer care. There is no product in the bottle or jug. Use a bottle or jug with product in it. Bottle/jug is not properly connected.
  • Page 20 Troubleshooting Problem Problem Cause Solution Unit is dispensing Connected bottle/jug is not in the Ensure bottle/jug is in the proper location. wrong product. correct location. The numbers don't match on both sides In the back of the unit, ensure the numbers of the tubing in the back of the unit.
  • Page 21 Series located on the lid or base of the unit. MODEL SERIES XXXX ##X ##X Example: ##### This Server product is backed by a one-year limited warranty against defects in materials and workmanship. See Server-Products.com for details. Need help? Server Products Inc.
  • Page 22 © 2023 Server Products, Inc. IxDM_Flavor+_101810_RevF...
