FVC SP0203B Installation Manual

Sprinter van rear door ladders (driver and passenger sides)

Advertisement

Quick Links

S PRI NTER VAN R E AR D OOR L AD D E RS (D RI VE R AN D PASSEN G ER SIDE S)
SP0203 B + SP0 204B
INSTALLATION
GUIDE
F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6
TOOLS REQUIRED
(NOT INCLUDED)
+
PAINTER'S TAPE
+
9/16" WRENCH OR SOCKET
+
RUST PREVENTATIVE PAINT
+
7/16" SOCKET
+
MEASURING TAPE
+
7/32" ALLEN KEY
+
MARKER
+
13/32" DRILL BIT
+
POWER DRILL
+
AUTO PANEL REMOVAL TOOL
INSTALL INFO
TIME TO INSTALL THIS PRODUCT: 1 HOUR
Additional help is suggested for a few of the install
steps.
BEFORE YOU START
Please inspect the product and packaging upon
delivery to ensure there are no issues and that all
parts and hardware are accounted for.
Contact us ASAP if anything is missing at:
support@flatlinevanco.com
0 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP0203B and is the answer not in the manual?

Questions and answers

Summary of Contents for FVC SP0203B

  • Page 1 INSTALLATION GUIDE S PRI NTER VAN R E AR D OOR L AD D E RS (D RI VE R AN D PASSEN G ER SIDE S) SP0203 B + SP0 204B TOOLS REQUIRED (NOT INCLUDED) PAINTER’S TAPE 9/16” WRENCH OR SOCKET RUST PREVENTATIVE PAINT 7/16”...
  • Page 2: Before You Start

    BEFORE YOU START All Flatline Van Co products must be properly assembled and secured before attaching to your vehicle. Improper attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others involved. You are responsible for assembling and securing Flatline Van Co products to your vehicle, checking the mounting points and attachments prior to use, and regularly inspecting the products for wear and or damage.
  • Page 3: Package Contents

    PACKAGE CONTENTS REAR LADDER WELDMENT (DRIVER OR PASSENGER SIDE) LOWER BACKER PLATE UPPER BACKER PLATE QTY: 1 QTY: 1 QTY: 1 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
  • Page 4 HARDWARE 3/8-16 X 1.25 BUTTON HEAD 1/4 X 1 SEALING WASHER 3/8-16 NYLON LOCKNUT 3/8” FLAT WASHER HEX DRIVE SCREW DRILLING SCREWS QTY: 4 QTY: 4 QTY: 4 QTY: 2 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
  • Page 5 INSTALL TOOLS REQUIRED FOR THIS STEP: AUTO PANEL REMOVAL TOOL STEP | 01 LAYOUT AND INSTALL PREP 1.1 Door Panel Removal: If applicable, start by removing the lower interior door panel (FIG 1) and any obstructions in the areas shown in FIG 2 (wires, insulation, etc.). We recommend using plastic panel removal tools (easily found at harbor freight or similar).
  • Page 6 TOOLS REQUIRED FOR THIS STEP: MEASURING TAPE RUST PREVENTATIVE PAINT MARKER PAINTER’S TAPE 13/32” DRILL BIT POWER DRILL STEP | 02 DRILL FOR BACKER MOUNTS 2.1 Prepare for Drilling: Move to the exterior of the van to mark the first hole. Apply a layer of painter’s tape over the mounting areas to protect the paint from scratches during drilling.
  • Page 7 9/16” WRENCH OR SOCKET TOOLS REQUIRED FOR THIS STEP: 7/32” ALLEN WRENCH 7/16” SOCKET POWER DRILL STEP | 03 LADDER INSTALL 3.1 Install Rear Door Ladder: Position the ladder on the door and insert the 3/8-16 Button Head Screws through the mounting holes, then position the backer plates as shown in FIG 7 and 9.
  • Page 8 FVC (and see) from you! Head to the products and following along and we will make it right. FVC is product page and click “Leave a company of van and outdoor with your adventures. Tag us Review.”...

This manual is also suitable for:

Sp0204b
