Concrete Anchor Set
For Balcony/Corner or
Terminating/End Post Installation
(Preferred Installation on Page 2)
Balcony/Corner Post
Online Manual
Single Brace Anchor Set
For Balcony/Corner Installation
(Optional Installation on Page 3)
404-344-0000 • www.tiedown.com
605 Stonehill Drive SW, Atlanta, GA 30336
Corner Post
Part ID: 73075
Terminating
/End Post
Balcony/Corner
Post
Extended Ledge
or Balcony
Terminating/End Post Set
End Post Installation Only
(Optional Installation on Page 4)
Instructions #08446 (E2002 - Rev. 11/21/23)
