USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes to
read carefully through this brief but
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your future
reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLite E430T and is the answer not in the manual?

Questions and answers

Summary of Contents for Iiyama ProLite E430T

  • Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place for your future reference.
  • Page 2 Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
  • Page 3 Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances.
  • Page 4: Fcc Declaration Of Conformity

    To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by iiyama could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE...
  • Page 5: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS ..............1 SPECIAL NOTES ON LCD MONITORS ..........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES ..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 OPTIONAL PARTS ................
  • Page 6: For Your Safety

    Disassembling the AC Adapter may expose you to the danger of fire or electric shock. USE THE POWER CABLE AND THE AC ADAPTER SUPPLIED Do not use a power cable or AC adapter not supplied by iiyama. It may cause fire or damage. DO NOT PUT ANY OBJECT INTO THE MONITOR Do not put any solid objects or liquids such as water into the monitor.
  • Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
  • Page 8: Special Notes On Lcd Monitors

    Power Switch for hours. There is the possibility that the previous screen has been fixed. Pay attention sufficient when you use LCD Monitor. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself.
  • Page 9: Before You Operate The Monitor

    CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office.
  • Page 10: Optional Parts

    OPTIONAL PARTS Optional parts as below are available for your LCD monitor. Please contact your local iiyama dealer or regional iiyama office for more details. n Tuner / Video Adapter OTA2-1PS Accessories: Remote Control, RCA Cable (Video / Audio), S-Video Cable, Scart Adapter, Screw ×...
  • Page 11: Controls And Connectors

    CONTROLS AND CONNECTORS DC IN LINE IN D-SUB <Front> <Back> A Power Switch / Power Indicator (POWER) Blue: Normal operation NOTE Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 3W when receiving no horizontal and/or vertical sync signal.
  • Page 12: Connecting Your Monitor

    An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office.
  • Page 13: Computer Setting

    Change to the desired signal timing listed on page 21: COMPLIANT TIMING. n Windows 95/98/2000/Me/XP Plug & Play The iiyama LCD monitor complies with DDC1/2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC1/2B compliant computer with the Signal Cable supplied.
  • Page 14: Installation Of Protection Sheet

    INSTALLATION OF PROTECTION SHEET The Protection Sheet can be attached to the LCD panel surface as you like to protect it from stains or scratches, and to make the picture clear. n Please be careful when handling the Protection Sheet as the edges may be sharp. CAUTION n Please be careful when attaching or removing the Protection Sheet because the NOTE...
  • Page 15: Operating The Monitor

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 21. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 15 for SCREEN ADJUSTMENTS.
  • Page 16: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS PC Input MENU : 1 M E N U : 1 1280 × 1024 H: 80.0 KHz V: 75.0 Hz Adjustment Item Problem / Option Button to Press Too dark Direct BRIGHTNESS * Too bright Too dull Direct CONTRAST Too intense...
  • Page 17 MENU : 2 MENU:2 1280 × 1024 H: 80.0 KHz V: 75.0 Hz Adjustment Item Problem / Option Button to Press Return to Menu. AUTO SET-UP * Adjust CLOCK, PHASE, V-POSITION and H-POSITION Direct automatically. The AUTO SET-UP is not performed when the SETTING signal input is changed.
  • Page 18 MENU : 2 Adjustment Item Problem / Option Normal GAMMA MODE1 High contrast Dark MODE2 Normal ECONOMY MODE MODE1 Brightness of back-light is reduced. Direct MODE2 Brightness of back-light is reduced more than MODE1. NOTE is displayed while ECONOMY MODE is active. PIP function is turned off.
  • Page 19 MENU : 3 M E N U : 3 1280 × 1024 H: 80.0 KHz V: 75.0 Hz Adjustment Item Problem / Option Button to Press Too soft Direct VOLUME Too loud NOTE is displayed while MUTE is active. 1 2 3 4 5 OSD POSITION You can move the OSD display area to any one of the following 5 positions...
  • Page 20: Screen Adjustments

    SCREEN ADJUSTMENTS n The screen adjustments described in this manual are designed to set image position and minimize flicker or blur for the particular computer in use. n The monitor is designed to provide the best performance at resolution of 1280 × 1024, but can not provide the best at resolutions of less than 1280 ×...
  • Page 21 C Press the Auto Button. (AUTO SET-UP) D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the AUTO SET-UP. E Stretch the right side of the picture frame to the right edge of the display area by adjusting the CLOCK.
  • Page 22: Power Management Feature

    H Select “Brightness” in the Adjustment Program and adjust the BRIGHTNESS and CONTRAST so that all 16 levels of gray in the grayscale pattern are visible. Click on “FINISH” to close the Adjustment Program. POWER MANAGEMENT FEATURE The power management feature of this product complies with every power saving requirement of ®...
  • Page 23: Trouble Shooting

    2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...
  • Page 24 Problem Check o The audio equipment (computer etc.) is ON. No sound. o The Audio Cable is properly connected. o If the headphone is connected, disconnect it. o The Volume is turned up. o The MUTE is OFF. o The audio output level of the audio equipment is within the specification of the monitor.
  • Page 25: Specifications

    APPENDIX A SPECIFICATIONS LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 43cm / 17.0" Pixel pitch 0.264mm H × 0.264mm V Brightness 300cd/m (Typical) Contrast ratio 450 : 1 (Typical) Viewable angle Right / Left: 70 degrees each, Up / Down: 60 degrees each Response time 16ms (Black, white, black) Display Colors...
  • Page 26: Dimensions

    DIMENSIONS 368.5mm/14.5" 53mm/2.1" 339.5mm/13.4" 214.5mm/8.4" COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 25.175MHz 31.469kHz 59.940Hz 37.500kHz 75.000Hz 31.500MHz 640 × 480 37.861kHz 72.809Hz 31.500MHz 35.156kHz 56.250Hz 36.000MHz 37.879kHz 60.317Hz 40.000MHz SVGA 800 × 600 46.875kHz 75.000Hz 49.500MHz VESA 50.000MHz 48.077kHz...
  • Page 27: Connector Pin Assignment

    CONNECTOR PIN ASSIGNMENT n D-Sub mini 15pin Input Signal Input Signal Connector Red video + 5V Ground Green video Blue video Data line (SDA)* Ground H-Sync Red video ground V-Sync Green video ground Clock line (SCL)* Blue video ground * Compliant to VESA DDC. APPENDIX A 22...
  • Page 28: Remote Control

    APPENDIX B Optional TV / VIDEO Input APPENDIX B is available only when the optional Tuner / Video Adapter is installed in the monitor. For more details, please refer to the user manual for the optional Tuner / Video Adapter. REMOTE CONTROL CAUTION Do not use any other batteries other than those specified in this manual for the...
  • Page 29 G SUBTITLE Display the TELETEXT Subtitle directly. H REVEAL Display a hidden information. (e.g. Answer to quiz) I RED / GREEN / YELLOW / CYAN Select the items on the lower part of the screen. J DISPLAY Information such as input signal, channel number and sound setting is displayed for 5 seconds on the screen.
  • Page 30: Basic Operation

    BASIC OPERATION n Turn On the monitor The monitor saves the power ON / OFF setting [ Remote Control ] Press the Power Switch. before the Power Cable is disconnected. If the monitor is OFF when connecting the Power Cable, press the Power Switch to turn ON the monitor.
  • Page 31 n Select channel [ Remote Control ] TV channel can be selected by the following 3 ways when antenna is connected. A Press the +/– Buttons on the monitor when the menu page is not displayed on the screen. B Press the CH Button (Channel Select) on the Remote Control.
  • Page 32 n Switch the input signal [ Monitor ] Press the Input Button. [ Remote Control ] Press the Input Button. This is switched when you successively press the Input Button on the monitor as follows: PC+TV (PIP) PC+VIDEO (PIP) PC+S-VIDEO (PIP) This is switched when you successively press VIDEO the Input Button on the Remote Control as follows:...
  • Page 33: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS PC Input Select “ON” at PIP on MENU: 2 first. MENU : 4 M E N U : 4 1280 × 1024 H: 80.0 KHz V: 75.0 Hz Adjustment Item Problem / Option Button to Press Display a TV picture in the sub screen. PIP SOURCE VIDEO Display a Video picture in the sub screen.
  • Page 34 TV / VIDEO / S-VIDEO Input MENU : 5 MENU:5 NTSC Adjustment Item Problem / Option Button to Press Remote Monitor Control Too dark Direct BRIGHTNESS * Too bright Too dull Direct CONTRAST * Too intense Too weak COLOR Too strong Greenish Purplish SHARPNESS...
  • Page 35 TV Input MENU : 6 MENU:6 CHANNEL CH:0 UNKNOWN FORMAT Adjustment Item Problem / Option Return to Menu. AUTO CHANNEL Select the receivable channels automatically. Exit: Return to Menu. n Select your relevant TV system at SYSTEM TYPE before performing the AUTO NOTE CHANNEL.
  • Page 36 MENU : 6 Adjustment Item Problem / Option Stereo broadcasting: AUDIO MODE STEREO Output the sound in stereo. Direct MONO Output the sound in monaural. Voice multiple broadcasting: SOUND1 Output the sound of SOUND1. SOUND2 Output the sound of SOUND2. SOUND1+2 Output the sound of SOUND1+2.
  • Page 37: Teletext Function

    TELETEXT FUNCTION Most Television channels carry “TELETEXT” pages of written information that provide information such as: l Television program times l News bulletins l Weather forecast l Sports results l Subtitles for the hard of hearing You can display TELETEXT information at any time, but signal reception must be good. Otherwise: l Information may be missing l Some pages may not be displayed n To switch On and OFF the TELETEXT...
  • Page 38: Specifications

    SPECIFICATIONS Input Video Connector RCA pin jack (Video) S-Video terminal Video Signal System * PAL, SECAM, NTSC TV Signal System PAL: B/G, I, D/K SECAM: B/G, D/K, L NICAM, A2 TV Stereo System LEVEL1.5, TOP / FLOF, 10 page TELETEXT Antenna Input VHF / UHF, 75Ω, Unbalanced Receive Channel...
