USER MANUAL
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes to
r e a d c a r e f u l l y t h r o u g h t h i s b r i e f b u t
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your future
reference.
PLE434S-e-update.P65
Page 1
ENGLISH
DEUTSCH
FRANCAIS
NEDERLANDS
SVENSKA
ITALIANO
2004/06/08, 15:33
Adobe PageMaker 7.0J/Win
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Iiyama ProLite E434S
Summary of Contents for Iiyama ProLite E434S
- Page 1 DEUTSCH FRANCAIS NEDERLANDS SVENSKA Thank you very much for choosing the iiyama LCD monitor. ITALIANO We recommend that you take a few minutes to r e a d c a r e f u l l y t h r o u g h t h i s b r i e f b u t comprehensive manual before installing and switching on the monitor.
- Page 2 Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
- Page 3 Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances.
-
Page 4: Fcc Declaration Of Conformity
To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by IIYAMA could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE... -
Page 5: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS ..............1 SPECIAL NOTES ON LCD MONITORS ..........4 CUSTOMER SERVICE ..............4 CLEANING ..................4 BEFORE YOU OPERATE THE MONITOR ..........5 FEATURES ..................5 CHECKING THE CONTENTS OF THE PACKAGE ......5 OPTIONAL PARTS ................ -
Page 6: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock. - Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
- Page 8 OTHERS ERGONOMIC RECOMMENDATIONS To eliminate eye fatigue, do not operate the monitor against a bright background or in a dark room. For optimal viewing comfort, the monitor should be just below eye level and 40-60 cm (16-24 inches) away from your eyes. When using the monitor over a prolonged time, a ten minute break every hour is recommended as looking at the screen continuously can cause eye strain.
-
Page 9: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself. -
Page 10: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. -
Page 11: Optional Parts
INSTALLATION OF STAND The monitor is designed to be used with the Stand installed. Be sure to install the Stand before operating the monitor. CAUTION Install the Stand on a stable surface. The monitor may cause injury or damage if it falls or is dropped. -
Page 12: Controls Andconnectors
CONTROLS AND CONNECTORS <Back> <Front> A Power Switch / Power Indicator (LED Indicator) Green: Normal operation NOTE Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 3W when receiving no horizontal and/or vertical sync signal. -
Page 13: Connecting Your Monitor
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. -
Page 14: Computer Setting
Change to the desired signal timing listed on page 22: COMPLIANT TIMING. Windows 95/98/2000/Me/XP Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 15: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 22. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 15 for SCREEN ADJUSTMENTS. -
Page 16: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Menu : 1 Menu:1 H: 80.0 KHz V: 75 Hz 1280 × 1024 Adjustment Item Problem / Option Button to Press Too dark Brightness * Direct Too bright Too dull Contrast Direct Too intense Clock * To correct flickering text or lines Phase * To correct flickering text or lines Too far to the left... - Page 17 Menu : 2 Menu:2 H: 80.0 KHz V: 75 Hz 1280 × 1024 Adjustment Item Problem / Option Button to Press Return to Menu. Auto Set-up * Adjust Clock and Phase automatically. Direct The Auto Set-up is not performed when the signal input is changed.
- Page 18 Menu : 3 Menu:3 H: 80.0 KHz V: 75 Hz 1280 × 1024 Adjustment Item Problem / Option Button to Press Too soft Volume Too loud Direct NOTE is displayed while Mute is active. 1 2 3 4 5 OSD Position You can move the OSD display area to any one of the following 5 positions within the overall display:...
- Page 19 OPQ Mode Direct Adjustment Item Problem / Option Picture Mode High brightness Text Mode Text Normal Eco1 Economy 1 Brightness of back-light is reduced Brightness of back-light is reduced more than Eco2 Economy 2 Economy1 NOTE Changing to a lower brightness mode can lessen eye fatigue. Change from Picture Mode to Text Mode when working with text.
-
Page 20: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com). - Page 21 C C C C C Press the Auto Button. (Auto Set-up) D D D D D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up.
- Page 22 G G G G G Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. – NOTE In case the strong flicker or blurs remain on a part of the screen, repeat steps F and G because the Clock may not be adjusted correctly.
-
Page 23: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with every power saving requirement of ® and VESA DPMS. When activated, it automatically reduces unnecessary power NERGY consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. -
Page 24: Trouble Shooting
2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... - Page 25 Problem Check The audio equipment (computer etc.) is ON. No sound. The Audio Cable is properly connected. The Volume is turned up. The Mute is OFF. The audio output level of the audio equipment is within the specification of the monitor. The sound is too The audio output level of the audio equipment is within the specification of loud or too quiet.
-
Page 26: Appendix
APPENDIX SPECIFICATIONS LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 43cm / 17.0" Pixel pitch 0.264mm H × 0.264mm V Brightness 350cd/m (Typical) Contrast ratio 350 : 1 (Typical) Viewable angle Right / Left: 80 degrees each, Up / Down: 60 degrees each (Typical) Response time 14ms (Black, white, black) Display Colors... -
Page 27: Dimensions
DIMENSIONS 387mm / 15.2" 57mm / 2.24" 340mm / 13.4" 239mm /9.41" COMPLIANT TIMING COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 25.175MHz 31.469kHz 59.940Hz 31.500MHz 640 × 480 37.500kHz 75.000Hz 37.861kHz 72.809Hz 31.500MHz 35.156kHz 56.250Hz 36.000MHz 37.879kHz 60.317Hz 40.000MHz VESA... -
Page 28: Connector Pin Assignment
CONNECTOR PIN ASSIGNMENT D-Sub mini 15pin Input Signal Input Signal Connector Red video Green video Ground Blue video Data line (SDA)* Ground H-Sync Red video ground V-Sync Green video ground Clock line (SCL)* Blue video ground * Compliant to VESA DDC. 23 APPENDIX PLE434S-e-update.P65 Page 28...
