USER MANUAL

Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes to
read carefully through this brief but
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your future
reference.
ENGLISH
DEUTSCH
FRANCAIS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the prolite E1900WS and is the answer not in the manual?

Questions and answers

Related Manuals for Iiyama prolite E1900WS

Summary of Contents for Iiyama prolite E1900WS

  • Page 1: User Manual

    USER MANUAL ENGLISH DEUTSCH FRANCAIS Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place for your future reference.

  • Page 2: Why Do We Have Environmentally Labelled Computers

    Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.

  • Page 3: Environmental Requirements

    Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances.

  • Page 4: Fcc Declaration Of Conformity

    To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by IIYAMA could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS ..............1 SPECIAL NOTES ON LCD MONITORS ..........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 CHECKING THE CONTENTS OF THE PACKAGE ......4 HOW TO USE THE STAND ..............

  • Page 6: For Your Safety

    STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock.
  • Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.

  • Page 8: Special Notes On Lcd Monitors

    Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself.

  • Page 9: Before You Operate The Monitor

    CHEKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office.

  • Page 10: How To Use The Stand

    HOW TO USE THE STAND HOW TO USE THE STAND The monitor is the design that a stand rotate.Be sure to rotate the stand before opearating the monitor, and rotate the stand upward before you re-box the monitor. Install the Stand on a stable surface. The monitor may cause injury or damage if CAUTION it falls or is dropped.

  • Page 11: Controls And Connectors

    K D-SUB mini 15pin Connector (D-SUB) L Keyhole for Security Lock You can fasten a security lock and cable to prevent the monitor from being removed NOTE without your permission. * Available for ProLite E1900WS-2 only. BEFORE YOU OPERATE THE MONITOR...

  • Page 12: Connecting Your Monitor

    The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor.

  • Page 13: Computer Setting

    Change to the desired signal timing listed on page 21: COMPLIANT TIMING. Windows 95/98/2000/Me/XP Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied.

  • Page 14: Operating The Monitor

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 21. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 13 for SCREEN ADJUSTMENTS.

  • Page 15: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS Auto Adjust AUTO Auto Adjust Adjustment Item Problem / Option Button to Press Auto Adjust * Direct Adjust H. / V. Position, H.Size and Fine Tune automatically. Only Analog Input NOTE The screen becomes dark for approximately five seconds during the adjustment. * For best results, use the Auto Adjust in conjunction with the adjustment pattern.
  • Page 16 Color Adjust Color Adjust Adjustment Item Problem / Option Button to Press 9300K Bluish white 6500K Reddish white 5400K Greenish white R (Red) Too weak User Color G (Green) Too strong B (Blue) Information Information Information Displays information regarding the current input signal coming from the graphic card in your computer.
  • Page 17 When only one of the two signal inputs is connected to the signal source, the one connected is automatically selected. Input Select function is not available if there is no signal input from the selected connector or during the power management mode. * Available for ProLite E1900WS-2 only. Memory Recall Memory Recall...

  • Page 18: Screen Adjustments

    If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com).
  • Page 19 C C C C C Press the Auto Button. (Auto Adjust) D D D D D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust.
  • Page 20 G G G G G Adjust the Fine Tune to correct horizontal wavy noise, flicker or blur in the zebra pattern. In case the strong flicker or blurs remain on a part of the screen, repeat steps F and NOTE NOTE G because the H.Size may not be adjusted correctly.

  • Page 21: Power Management Feature

    POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of E NERGY ® and VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer.

  • Page 22: Trouble Shooting

    2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...
  • Page 23 Problem Check No sound. The audio equipment (computer etc.) is ON. The Audio Cable is properly connected. The Volume is turned up. The Mute is OFF. The audio output level of the audio equipment is within the specification of the monitor. The sound is too The audio output level of the audio equipment is within the specification of the monitor.

  • Page 24: Appendix

    APPENDIX SPECIFICATIONS Model ProLite E1900WS-1 LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48.1cm / 19.0" Pixel pitch 0.2835mm H × 0.2835mm V Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left : 75 degrees each, Up:75 degrees, Down: 65 degrees (Typical)
  • Page 25 Model ProLite E1900WS-2 LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48.1cm / 19.0" Pixel pitch 0.2835mm H × 0.2835mm V Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left : 75 degrees each, Up:75 degrees, Down: 65 degrees (Typical)

  • Page 26: Dimensions

    DIMENSIONS DIMENSIONS 71mm/2.8" 443mm/17.7" 231mm/9.2" COMPLIANT TIMING Vertical Horizontal Video Mode Dot Clock Frequency Frequency 31.468kHz 59.941Hz 25.175MHz 640 × 480 37.500kHz 74.997Hz 31.500MHz 35.156kHz 56.249Hz 36.000MHz 37.878kHz 60.317Hz 40.000MHz SVGA 800 × 600 46.875kHz 75.001Hz 49.500MHz 48.076kHz 72.186Hz 50.000MHz 48.362kHz 60.002Hz 65.000MHz...

  • Page 27: Connector Pin Assignment

    CONNECTOR PIN ASSIGNMENT D-Sub mini 15pin Input Signal Input Signal Connector Red video Green video Ground Blue video Data line (SDA)* Ground H-Sync Red video ground V-Sync Green video ground Clock line (SCL)* Blue video ground * Compliant to VESA DDC. DVI-D 24pin Input Signal Input Signal...
