USER MANUAL
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes to
read carefully through this brief but
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your future
reference.
ENGLISH
ENGLISH
DEUTSCH
FRANCAIS
NEDERLANDS
ITALIANO
ESPAÑOL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Iiyama ProLite E481S
Summary of Contents for Iiyama ProLite E481S
-
Page 1: User Manual
USER MANUAL ENGLISH ENGLISH DEUTSCH FRANCAIS NEDERLANDS Thank you very much for choosing the iiyama ITALIANO LCD monitor. We recommend that you take a few minutes to ESPAÑOL read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place for your future reference. - Page 2 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
-
Page 3: Fcc Declaration Of Conformity
To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by iiyama could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE... -
Page 4: Table Of Contents
BEFORE YOU OPERATE THE MONITOR ............4 FEATURES ....................5 CHECKING THE CONTENTS OF THE PACKAGE : ProLite E481S ..6 CHECKING THE CONTENTS OF THE PACKAGE : ProLite H481S ..6 INSTALLATION OF STAND : ProLite E481S ........... 7 CONTROLS AND CONNECTORS : ProLite E481S ........ -
Page 5: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock. -
Page 6: Installation Location
CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. -
Page 7: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself. -
Page 8: Before You Operate The Monitor
BEFORE YOU OPERATE THE MONITOR [Stopper] : ProLite H481S Please stand the monitor and then remove the stopper on the back of the stand slowly. BEFORE YOU OPERATE THE MONITOR... -
Page 9: Features
ProLite E481S-W5S / E481S-B5S / E481S-S5S / H481S-W5S / H481S-B5S High Contrast 700:1 / High Brightness 300cd/m / Quick Response Time 2ms (Gray to Gray) : ProLite E481S-W6S / E481S-B6S / E481S-S6S / H481S-W6S / H481S-B6S 19.8mm Narrow Bezel & Slim Design Multi-Color Control... -
Page 10: Checking The Contents Of The Package : Prolite E481S
CHECKING THE CONTENTS OF THE PACKAGE : ProLite E481S The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. -
Page 11: Installation Of Stand : Prolite E481S
INSTALLATION OF STAND : ProLite E481S The monitor is designed to be used with the stand installed. Be sure to install the stand before operating the monitor. CAUTION Install the stand on a stable surface. The monitor may cause injury or damage if it falls or is dropped. -
Page 12: Controls And Connectors : Prolite E481S
Green: Normal operation (ProLite E481S) NOTE Blue: Normal operation (ProLite E481S-B / ProLite E481S-S) Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 2W when receiving no horizontal and/or vertical sync signal. -
Page 13: Controls And Connectors : Prolite H481S
CONTROLS AND CONNECTORS : ProLite H481S AC IN DVI-D D-SUB LINE <Front> <Back> A Power Switch / Power Indicator ( Green: Normal operation (ProLite H481S) NOTE Blue: Normal operation (ProLite H481S-B) Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 2W when receiving no horizontal and/or vertical sync signal. -
Page 14: Connecting Your Monitor : Prolite E481S
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. -
Page 15: Connecting Your Monitor : Prolite H481S
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. -
Page 16: Computer Setting
Change to the desired signal timing listed on page 35: COMPLIANT TIMING. Windows 95/98/2000/Me/XP Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 17: Adjusting The Height And The Viewing Angle : Prolite H481S
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite H481S For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's Height and angle to your own preference. Hold the stand so that the monitor does not topple when you change the monitor’s angle. -
Page 18: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 35. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 22 for SCREEN ADJUSTMENTS. -
Page 19: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Analog Input Menu : 1 Menu:1 (Analog) 1280 × 1024 : 80.0 K z V: 75.0 z Adjustment Item Problem / Option Button to Press Too dark Brightness * Direct Too bright Too dull Contrast Direct Too intense Clock * To correct flickering text or lines Phase *... - Page 20 enu:2 Menu : 2 (Analog) 1280 × 1024 H: 80.0 KHz V: 75.0 Hz Adjustment Item Problem / Option Button to Press Return to Menu. Auto Set-up * Adjust Clock, Phase, V-Position and H-Position Direct automatically. Setting The Auto Set-up is not performed when the signal input is changed.
- Page 21 Menu : 2 (Analog) Adjustment Item Problem / Option Gamma Mode1 High contrast Mode2 Dark Normal Economy Mode Mode1 Brightness of back-light is reduced. Direct Mode2 Brightness of back-light is reduced more than Mode1. NOTE is displayed while Economy Mode is active. Return to Menu Highlight “Menu : 2”...
- Page 22 Menu:3 Menu : 3 (Analog) 1280 × 1024 : 80.0 K z V: 75.0 z Problem / Option Button to Press Adjustment Item Too soft Volume Direct Too loud NOTE is displayed while Mute is active. 1 2 3 4 5 OSD Position You can move the OSD display area to any one of the following 5 positions...
-
Page 23: Digital Input
Digital Input Menu : 1 Menu:1 (Digital) 1280 × 1024 : 80.0 K z V: 75.0 z Adjustment Item Problem / Option Button to Press Too dark Brightness * Direct Too bright Too dull Contrast Direct Too intense Color 1: 9300K Color Temp. - Page 24 Menu : 1 (Digital) Adjustment Item Problem / Option Normal Economy Mode Mode1 Brightness of back-light is reduced. Direct Mode2 Brightness of back-light is reduced more than Mode1. NOTE is displayed while Economy Mode is active. Return to Menu Highlight “Menu : 1” again. Direct You can skip the Menu pages and display an adjustment scale directly by using the following button operations.
- Page 25 Menu:2 Menu : 2 (Digital) 1280 × 1024 : 80.0 K z V: 75.0 z Problem / Option Button to Press Adjustment Item Too soft Volume Direct Too loud NOTE is displayed while Mute is active. 1 2 3 4 5 OSD Position You can move the OSD display area to any one of the following 5 positions...
-
Page 26: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com). - Page 27 C C C C C Press the Auto Button. (Auto Set-up) D D D D D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up.
- Page 28 G G G G G Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. – NOTE In case the strong flicker or blurs remain on a part of the screen, repeat steps F and NOTE G because the Clock may not be adjusted correctly.
-
Page 29: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with every power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. -
Page 30: Trouble Shooting
2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... - Page 31 Problem Check The audio equipment (computer etc.) is ON. No sound. The Audio Cable is properly connected. The Volume is turned up. The Mute is OFF. The audio output level of the audio equipment is within the specification of the monitor. The sound is too The audio output level of the audio equipment is within the specification of loud or too quiet.
-
Page 32: Appendix
APPENDIX SPECIFICATIONS: ProLite E481S-W4S / E481S-B4S / E481S-S4S LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48cm / 19.0" Pixel pitch 0.294mm H × 0.294mm V Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left: 75 degrees each, Up: 70 degrees, Down: 60 degrees... -
Page 33: Specifications: Prolite E481S-W5S / E481S-B5S / E481S-S5S
SPECIFICATIONS: ProLite E481S-W5S / E481S-B5S / E481S-S5S LCD Panel a-Si TFT Active Matrix Driving system Size Diagonal: 48cm / 19.0" 0.294mm H × 0.294mm V Pixel pitch Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left: 75 degrees each, Up: 75 degrees, Down: 65 degrees... -
Page 34: Specifications: Prolite E481S-W6S / E481S-B6S / E481S-S6S
SPECIFICATIONS: ProLite E481S-W6S / E481S-B6S / E481S-S6S LCD Panel a-Si TFT Active Matrix Driving system Size Diagonal: 48cm / 19.0" 0.294mm H × 0.294mm V Pixel pitch Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left: 75 degrees each, Up: 75 degrees, Down: 65 degrees... -
Page 35: Specifications : Prolite H481S-W4S / H481S-B4S
SPECIFICATIONS : ProLite H481S-W4S / H481S-B4S LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48cm / 19.0" Pixel pitch 0.294mm H × 0.294mm V Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left: 75 degrees each, Up: 70 degrees, Down: 60 degrees Response time 8ms (Black, white, black) Display Colors... -
Page 36: Specifications : Prolite H481S-W5S / H481S-B5S
SPECIFICATIONS : ProLite H481S-W5S / H481S-B5S LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48cm / 19.0" Pixel pitch 0.294mm H × 0.294mm V Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left: 75 degrees each, Up: 75 degrees, Down: 65 degrees Response time 5ms (Black, white, black) Display Colors... -
Page 37: Specifications : Prolite H481S-W6S / H481S-B6S
SPECIFICATIONS : ProLite H481S-W6S / H481S-B6S LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48cm / 19.0" Pixel pitch 0.294mm H × 0.294mm V Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left: 75 degrees each, Up: 75 degrees, Down: 65 degrees Response time 5ms (Black, white, black), 2ms (Gray to Gray) Display Colors... -
Page 38: Dimensions : Prolite E481S
DIMENSIONS : ProLite E481S 418.0mm/16.5" 65.0mm/2.6" 378.5mm/14.9" 223.0mm/8.8" DIMENSIONS : ProLIte H481S 418.0mm/16.5" 65.0mm/2.6" 378.5mm/14.9" 300.5mm/11.8" ( ):Maximum adjustment range 34 APPENDIX... -
Page 39: Compliant Timing
COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 25.175MHz 31.469kHz 59.940Hz 37.500kHz 75.000Hz 31.500MHz 640 × 480 37.861kHz 72.809Hz 31.500MHz 35.156kHz 56.250Hz 36.000MHz 40.000MHz 37.879kHz 60.317Hz SVGA 800 × 600 49.500MHz 46.875kHz 75.000Hz VESA 50.000MHz 48.077kHz 72.188Hz 48.363kHz 60.004Hz 65.000MHz 1024 ×... -
Page 40: Connector Pin Assignment
CONNECTOR PIN ASSIGNMENT D-Sub mini 15pin Input Signal Input Signal Connector Red video Ground Green video / Sync on green Blue video Reserved port Data line (SDA)* Reserved port Ground Ground H-Sync/HV-Sync Red video ground V-Sync Green video ground Clock line (SCL)* Blue video ground * Compliant to VESA DDC.
