Detention Recess Adaptor
Installation and Maintenance Instructions
DET608
DET608-15EXT
technical data
Working Pressure Range
Maximum Static Pressure
Maximum Working
Temperature
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00484_18 Jan 2024
1300 369 273 | info@enware.com.au | enware.com.au
Min 50 kPa
Max 500 kPa
800 kPa
85°C (Ceramic disc)
Advertisement
Table of Contents
Related Manuals for Watts ENWARE DET608
Summary of Contents for Watts ENWARE DET608
- Page 1 Detention Recess Adaptor Installation and Maintenance Instructions DET608 DET608-15EXT technical data Working Pressure Range Min 50 kPa Max 500 kPa Maximum Static Pressure 800 kPa Maximum Working 85°C (Ceramic disc) Temperature Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500. Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
- Page 2 wall depth adjustment Finished Wall Recess Body To choose the correct Enware product, firstly find out the required wall depth dimension A. Order DET608 or DET608-15EXT. Order DET005 or DET015 Trouble Dome if required. (Refer to table below.) Recess Wall Trouble Dome Replacement Product Code...
-
Page 3: Installation
installation • All supply lines must be flushed thoroughly to remove debris prior to the installation of this product, as per AS/NZS 3500.1. Strainers (40 mesh) are recommended if debris is an ongoing problem. • A pressure reduction valve may be required to comply with the recommended maximum supply pressure and/or balanced pressure requirements. - Page 4 6. Screw the wall flange onto the SBA until flush with wall. Ensure there is no gap between the wall and the flange. 7. Mark the location of the anti-rotation screw through one of the two anti-rotation screw holes in the flange, being aware to avoid any pipe work in the wall. Remove flange from wall fixture and drill a 5mm diameter hole approximately 10mm deep at the marked location.
- Page 5 14. Fit indicator button onto handle. To do this, ensure the surface of handle is clean and dry, free of dust, moisture and grease. Peel off the indicator button from its backing paper, taking care not to touch the adhesive side. Place the indicator button onto flat section of the handle, and push the button firmly onto handle.
-
Page 6: Operation
operation CLOSED Turn anti-clockwise to turn on. Turn clockwise to turn off. OPEN cleaning Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. -
Page 7: Product Warranty Statement
- WATTS AUSTRALIA Effective 27 October 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662... - Page 8 1300 369 273 info@enware.com.au enware.com.au...
