Type 47 Spring Action Bib Tap
Installation and Maintenance Instructions
BUB208B
BUB208C
BUB208L
technical data
Inlet Connection
Recommended Working Pressure Range
Flow Rate
Recommended Temperature Range
Maximum Operating Temperature
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00598_18 Dec 2023
1300 369 273 | info@enware.com.au | enware.com.au
1/2" BSP (15mm)
50 - 500 kPa
6 L/min
5 - 30 °C
50°C
Advertisement
Related Manuals for Watts ENWARE BUB208B
Summary of Contents for Watts ENWARE BUB208B
- Page 1 Type 47 Spring Action Bib Tap Installation and Maintenance Instructions BUB208B BUB208C BUB208L technical data Inlet Connection 1/2” BSP (15mm) Recommended Working Pressure Range 50 - 500 kPa Flow Rate 6 L/min Recommended Temperature Range 5 - 30 °C 50°C Maximum Operating Temperature Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
-
Page 2: Installation Procedure
installation Ensure all supply lines are flushed thoroughly to remove debris prior to the installation of this product. Strainers (40 mesh) are recommended if debris is an ongoing problem. A pressure reduction valve may be required to comply with the recommended maximum supply pressure requirements. -
Page 3: Operation
operation CAM ACTION HANDLE To turn on water flow, turn handle and hold. To turn off water flow, let go of handle. Water flow stops automatically. (Handle can be turned either way until it reaches a stop.) IMAGE 04 LEVER ACTION HANDLE To turn on water flow, push or pull on the lever handle and hold. - Page 4 components & spare parts Cam Action Top Assembly Lever Action Top Assembly Button Action Top Assembly (BUB261) (BUB262) (BUB263) (BUB260C) (BUB260L) (BUB260B) Spindle SPACER SPACER Grub Screw LEVER HANDLE PUSH BUTTON Dome Handle Insert Circlip DOME DOME Handle Handle ENWARE SALES PART CODE Colour Indicator Button...
-
Page 5: Service And Maintenance
service & maintenance DOME ADJUSTMENT Adjust the position of the dome if: - there is play on the handle that needs to be adjusted; - if the bubbler is not shutting off completely / water constantly running; or - if there is no water flow Adjust the dome by carrying out the following steps: 1. - Page 6 SPRING ACTION SBA It is recommended that the spring action be periodically serviced. As a guide, every 6 months the spindle should be cleaned and re-greased, and the handle insert and other components checked for tightness. The servicing interval will vary depending on the frequency of use of the product, water quality and the general environment.
- Page 7 SERVICING THE SBA WITH SERVICE KIT 1. Pull the piston assembly out from the SBA and remove the 2 piston o-rings. SBA SPRING 2. Use a spanner to unscrew bottom inlet port, STAINLESS STEEL BALL remove spring and stainless steel ball in the BALL SEATING WASHER port.
- Page 8 CAM HANDLE If the handle feels loose, check that the handle insert is fitted, and tighten with the Anti Vandal Handle Key. To take off handle, use the Anti-Vandal Handle Key to loosen the insert. Handle pulls off the spindle. IMAGE 09 AERATOR Spout aerator should be checked and...
- Page 9 CLEANING Enware product should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive. Epoxy coated surfaces should only be cleaned with a cloth and clear water or mild detergent.
-
Page 10: Troubleshooting
troubleshooting PROBLEM CAUSE RECTIFICATION Water runs constantly Dome screwed in too far Adjust dome. See DOME from outlet ADJUSTMENT Dome incorrectly adjusted Adjust dome. See DOME ADJUSTMENT Debris fouling ball seating Dismantle SBA and clean washer or stainless steel ball SBA ball seating washer Replace SBA components using is damaged or spring is... -
Page 11: Product Warranty Statement
- WATTS AUSTRALIA Effective 27 October 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662... - Page 12 1300 369 273 info@enware.com.au enware.com.au...
