Detention Conical Shower Rose Wall
Mounted
Installation and Maintenance Instructions
DET660
technical data
Inlet Connection
Working Pressure Range
Flow Rate
Maximum Working Temperature
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00492_20 Jan 2024
1300 369 273 | info@enware.com.au | enware.com.au
1/2" BSP Female
Min 50 kPa
Max 500 kPa
8 L/min (3 Star WELS)
6 L/min (5 Star WELS)
70°C (Ceramic disc)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Watts ENWARE DET660
Summary of Contents for Watts ENWARE DET660
- Page 1 Detention Conical Shower Rose Wall Mounted Installation and Maintenance Instructions DET660 technical data Inlet Connection 1/2” BSP Female Working Pressure Range Min 50 kPa Max 500 kPa Flow Rate 8 L/min (3 Star WELS) 6 L/min (5 Star WELS) 70°C (Ceramic disc) Maximum Working Temperature Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
-
Page 2: Flow Regulator
ANTI-ROTATION PIN GRUB SCREW WALL BASE FLOW REGULATOR O-RING installation • All supply lines must be flushed thoroughly to remove debris prior to the installation of this product, as per AS/NZS 3500.1. Strainers (40 mesh) are recommended if debris is an ongoing problem. - Page 3 2. Prepare a 1/2" BSP thread on wall, allowing 11mm of thread to protrude from finished wall. SEE IMAGE 02 3. Flush the water supply line. Ensure there are no debris or contaminants. 1/2” BSP 4. To disassemble wall base from shower rose, first unscrew the grub screw out of shower rose using 2.5mm Allen key.
-
Page 4: Maintenance
maintenance CLEANING Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive. Use of unsuitable cleaning agents may damage the surface. -
Page 5: Troubleshooting
troubleshooting FAULT / SYMPTOM CAUSE RECTIFICATION 1. Poor water flow Debris in line Dismantle shower rose and clean / reverse rinse shower rose. Dismantle flow control and clean. Replace if necessary. 2. Leaking from wall O-ring is damaged or Check and clean or replace O-ring on the base missing wall base... - Page 6 dimensions 1/2" BSP All measurements are in millimetres. www.enware.com.au Page 6 © Enware Pty Ltd...
-
Page 7: Product Warranty Statement
- WATTS AUSTRALIA Effective 27 October 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662... - Page 8 1300 369 273 info@enware.com.au enware.com.au...
