Blueline
®
Installation and Maintenance Instructions
BUB205NC
BUB205NCBF
BUB224NC
BUB224NCBF
BUB219NC
BUB219NCBF
technical data
Inlet Connection
Recommended Pressure Range
Flow Rate
Operating Temperature Range
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00285_06 Mar 2024
1300 369 273 | info@enware.com.au | enware.com.au
Bubbler
1/2" BSP Female
Min 100 kPa
Max 500 kPa
2 L/min (Bubbler)
5 L/min (Bottle Filler)
5 - 30°C
Advertisement
Related Manuals for Watts ENWARE Blueline BUB205NC
Summary of Contents for Watts ENWARE Blueline BUB205NC
- Page 1 Blueline Bubbler ® Installation and Maintenance Instructions BUB205NC BUB205NCBF BUB224NC BUB224NCBF BUB219NC BUB219NCBF technical data Inlet Connection 1/2” BSP Female Recommended Pressure Range Min 100 kPa Max 500 kPa Flow Rate 2 L/min (Bubbler) 5 L/min (Bottle Filler) 5 - 30°C Operating Temperature Range Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
-
Page 2: Installation
installation • All supply lines must be flushed thoroughly to remove debris prior to the installation of this product, as per AS/NZS 3500.1. Strainers (40 mesh) are recommended if debris is an ongoing problem. • A pressure reduction valve may be required to comply with the recommended maximum supply pressure pressure requirements. -
Page 3: Maintenance
maintenance Mesh Filter Check Valve Flow Regulator Mesh Filter Flow Regulator Cartridge The bubbler components will require minimum maintenance. Periodically the mesh filter should be checked for cleanliness, and other components checked for tightness. The servicing interval will vary depending on the frequency of use of the product, water quality and the general environment. - Page 4 CLEANING Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive. Use of unsuitable cleaning agents may damage the surface.
-
Page 5: Troubleshooting
troubleshooting PROBLEM CAUSE RECTIFICATION Flow stream is unsteady or Water supply conditions Check that water pressure is between too low have changed or are 100kPa and 500kPa. fluctuating Remove the bubbler outlet and/or Incorrect flow adjustment bottle filler by removing the securing grubscrew and pulling free. -
Page 6: Spare Parts
spare parts Hob/Wall Penetration Description Product Code Handle, Cap, Screw & Adaptor - Bubbler BUB378NC Handle, Cap, Screw & Adaptor - Bubbler & BUB378NCBF Bottle Filler Cap and Screw BUB400 Cartridge - Bubbler BUB260NC Cartridge - Bubbler and Bottle Filler BUB260NCBF BUB734NC Mouth Guard &... -
Page 7: Product Warranty Statement
- WATTS AUSTRALIA EFFECTIVE FROM 20 November 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662... - Page 8 1300 369 273 info@enware.com.au enware.com.au...
