Detention Basin Set with SP003 Fixed
Spout - Standard Breech
Installation and Maintenance Instructions
DET306
technical data
Working Pressure Range
Maximum Static Pressure
Maximum Working
Temperature
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00506_20 Jan 2024
1300 369 273 | info@enware.com.au | enware.com.au
Min 50 kPa
Max 500 kPa
800 kPa
85°C (Ceramic disc)
Advertisement
Table of Contents
Related Manuals for Watts ENWARE DET306
Summary of Contents for Watts ENWARE DET306
- Page 1 Detention Basin Set with SP003 Fixed Spout - Standard Breech Installation and Maintenance Instructions DET306 technical data Working Pressure Range Min 50 kPa Max 500 kPa Maximum Static Pressure 800 kPa Maximum Working 85°C (Ceramic disc) Temperature Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500. Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
- Page 2 BENCH BENCH BENCH Screw M5x16 CSK 304SS 12 Fibre washer Security Torx 13 Back nut - tap body Handle - hot / warm 14 Tap body Handle - cold 15 Compression nut Anti-rotation grub screw 16 Tee M4x12mm 304 SS 17 O-ring BS008.5 Flange 18 Spout...
-
Page 3: Installation
installation • All supply lines must be flushed thoroughly to remove debris 22 - 25 33 - 35 prior to the installation of this product. Strainers (40 mesh) are recommended if debris is an ongoing problem. 2x HANDLE 1x SPOUT •... - Page 4 9. Screw flange [5] onto SBA lock nut [7], then fit brass spacer [9] and handle [2, 3] onto SBA spindle. Fix the handle in place with screw [1]. 10. Wind the flange [5] back so that there is a 2mm gap between the handle [2, 3] and the flange.
-
Page 5: Maintenance
maintenance CLEAN AERATOR Clean aerator [20] periodically. Unscrew the aerator shell [21] using a spanner, and rinse the aerator [20] under running water. CLEANING Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. - Page 6 dimensions 150 - 300 1/2" BSP WITH OLIVE (CUT TO SUIT ON SITE) COMPRESSION FITTING All measurements are in millimetres. www.enware.com.au Page 6 © Enware Pty Ltd...
-
Page 7: Product Warranty Statement
- WATTS AUSTRALIA Effective 27 October 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662... - Page 8 1300 369 273 info@enware.com.au enware.com.au...
