Summary of Contents for Nice Pro-TB

Page 1 Pro-T/TB/APT Automation for sectional and rolling door EN - Instructions and warnings for installation and use...
Page 2: Warranty
NICE CANADA warrants that materials and workmanship are free from defects for a period of two years from the date of invoice. Materials returned to Nice deemed defective after examination will be returned at the option of Nice with repaired, new or re-manufactured parts.
Page 3: Table Of Contents
TABLE OF CONTENTS PAGE: WARRANTY __________________________________________________________________ VERIFICATION OF OPERATOR AND HARDWARE ___________________________ SPECIFICATIONS ___________________________________________________________ SAFETY INSTRUCTIONS ____________________________________________________ INSTALLATION________________________________________________________________ ELECTRICAL CONNECTIONS SETTINGS________________________________ LIMIT SWITCH ADJUSTMENT ________________________________________________ PHOTOBEAM INSTALLATION INSTRUCTIONS________________________________ CLUTCH ADJUSTMENT______________________________________________________ BRAKE ADJUSTMENT_______________________________________________________ EMERGENCY MANUAL OPERATION _________________________________________ OPERATOR MAINTENANCE _________________________________________________ MECHANICAL DRAWINGS AND PARTS LISTS ________________________________ ELECTRICAL DIAGRAMS ___________________________________________________ OPTIONS MP00041-44...
Page 4: Verification Of Operator And Hardware
SAVE THESE INSTRUCTIONS VERIFICATION OF OPERATOR AND HARDWARE Upon delivery of your Nice heavy-duty trolley door operator, please inspect the unit carefully for damage. Verify that operator horsepower, voltage, phase and amperage correspond to available power supply and door application.
Page 5: Specifications
PRO-T, PRO-TB SPECIFICATIONS PRO-T and PRO-TB heavy-duty trolley operators are designed for standard lift overhead sectional garage doors. Model PRO-TB is essentially the same as model PRO-T with the exception that the PRO-TB operator has a solenoid operated braking system.
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING TO REDUCE THE RISK OF INJURY OR DEATH: READ AND FOLLOW ALL INSTRUCTIONS Never allow children to operate or play with door controls. Keep the remote control (where provided) away from children. Personnel should keep away from a door in motion and keep the moving door in sight until it is completely closed or opened.
Page 7: Installation
INSTALLATION INSTRUCTIONS WARNING DO NOT INSTALL THIS OPERATOR BEFORE READING THIS MANUAL CAREFULLY. Note: Installation of operator must be done by a qualified installer. Door must be properly installed and working smoothly. Remove all door locks prior to installation. Install control station away from all moving door parts, within sight of the door and a minimum of 5 ft (1.5 m) from the ground.
Page 8 PREPARATION: Lay out operator and trolley tracks on ground in front of door with door operator motor facing away from door. Install track spacers evenly to track assembly. Install 3/8” take-up bolt to carriage using two 3/8” hex nuts and lock washer provided. Slide trolley carriage through end of tracks towards operator with take-up bolt facing operator.
Page 9 WALL MOUNTING BRACKET AND OPERATOR INSTALLATION: NOTE: Trolley type operators should generally be mounted directly over the center of the door and the trolley tracks should clear the tracks by 2-1/2” (6.5 cm). However, if interfering structures or other reasons do not allow for centered mounting, it is possible to install it up to 18”...
Page 10 Install hanging brackets (braces) from ceiling or structure to any of the five 3/8” holes located on operator frame. For tracks over 14’ long it is recommended to install braces to the tracks at 4’(1.2m) to 5’ (1.5m) from operator. TROLLEY ARM INSTALLATION Manually close door to fully closed position.
Page 11: Electrical Connections And Settings
IMPORTANT EACH INDIVIDUAL COMMERCIAL DOOR OPERATOR MUST HAVE IT’S OWN DEDICATED POWER SUPPLY NICE HIGHLY RECOMMENDS THAT EACH INDIVIDUAL COMMERCIAL DOOR OPERATOR HAVE AN EXTERNAL CIRCUIT BREAKER OR FUSED DISCONNECT WARNING COMPARE AVAILABLE POWER SUPPLY VOLTAGE TO OPERATOR NAMEPLATE PRIOR TO ELECTRICAL CONNECTION.
Page 12: Section A: Pro-T, Pro-Tb Standard Relay Logic Controls
SECTION A: PRO-T, PRO-TB Standard relay logic controls (not UL325 (2010) compliant, not available in US) CONNECTION OF POWER SUPPLY AND CONTROL STATION POWER WIRING: Use 1-1/8” (2.85 cm) diameter holes for all power wiring. Single phase: Connect single phase power supply to terminals L/L1 (line) and N/L2 on three-pole power terminal strip.
Page 13 CONNECTION OF A REVERSING EDGE DEVICE AND CONTROL ACCESSORIES Reversing Edge device (must be normally open contact): Note: If the door is controlled by any device or wired in such a manner that the door is not controlled by constant pressure on close then an appropriate reversing edge must be installed. External interlock: Remove jumper between terminals 1 and 2 and wire a N.C.
Page 14: Section B: Pro-T(M), Pro-Tb(M) Relay Logic Controls With Interface
NOTE: THIS OPERATOR COMES WITH AN I NTERFACE MODULE INTEGRATED INTO THE CONTROL CIRCUIT. THE PURPOSE OF THE INTERFACE MODULE IS TO ALLOW FOR FAILSAFE MONITORING OF A NICE COMPATIBLE SAFETY DEVICE AS PER UL 325 (2010) REQUIREMENTS. Important: Follow these steps carefully and in the order shown...
Page 15 Single phase operators: The operators leave the factory with correct motor and limit shaft direction according to standard door installations. However, for special fire door, thru- wall mounting or other special door applications, the motor direction and limit switch direction may need to be reversed. To reverse the motor rotation, interchange black and white wires going to motor on the reversing contactor.
Page 16 Note: Only one monitored failsafe safety device can be connected across terminals P1 and P2. Note: See section E for complete installation instructions for the Nice N-1 or N-4 photocells or the Fraba photocells. Secondary non-monitored safety device(s): A standard 2-wire safety edge, non-monitored reflective or thru-beam photo eye or any other non-monitored reversing devices with a N.O dry contact can be connected to terminals S1 and S2.
Page 17: Section C: Pro-T(E), Pro-Tb(E) Full Feature Logic Board Smart
SECTION C: PRO-T(E), PRO-TB(E) Full feature logic board Smart 10.0 (UL325 (2010) compliant) Note: The operator is shipped from the factory in the D1 mode setting (constant pressure open and close). The operator should remain in this mode until all connections and limit switch adjustments are completed.
Page 18: Limit Switch Adjustments
1 or more secondary non-monitored safety device(s). Primary monitored safety device: Nice monitored failsafe photo beams or Nice compatible monitored failsafe devices must be connected to terminals P1 and P2 as primary monitored safety device. Primary monitored safety device must be connected if momentary activation on close is required in B2, T and TS modes.
Page 19: Modes Of Operation
Secondary non-monitored safety device(s): A standard 2-wire safety edge, non-monitored photo beams or any other non-monitored reversing devices with a N.O contact can be connected to terminals S1 and S2 as secondary non-monitored safety device. Note: More than one secondary non-monitored safety device can be connected to terminals S1 and S2. Important: Do not remove the resistor that is factory installed across terminals S1 and S2 unless installing a 4-wire electric edge.
Page 20 C2 (Momentary open, constant pressure close) • Open Button: Momentary activation opens the door. When door is closing, momentary activation reverses the door (OPEN OVERRIDE). Momentary contact from mid-stop opens the door to full open position. Constant activation when door is opening, bypass mid-stop if enabled. •...
Page 21: Programming Instructions
• Timer to close: Closes the door from mid-stop or full open. Momentary activation of stop button will de-activate the timer. When door is closing, momentary activation of safety devices will reverse the door to mid-stop (if enabled) or full open and de-activates the timer.
Page 22: Installing The Antenna
MID-STOP SETUP: Mid-stop feature can be used to open the door to a preset point prior to full open position. Note: Limits must be set prior to setting mid-stop position. To Activate mid-stop: Close the door to full close position. Set the selector dial to “Mid-stop”...
Page 23: Operation
Note: If an external radio-receiver (Nice or other) is used instead of the built-in radio receiver, it is highly recommended to disconnect the co-axial cable from the logic board.
Page 24: Dip Switch Setup
Delay on Delay on reverse Delay on reverse Nice recommends 1.5 sec reverse is 1.5 seconds is 0.5 seconds delay on reverse for all applications Standard motor...
Page 25: Section D: For All Operator Control Types
SECTION D: For all operator control types LIMIT SWITCH ADJUSTMENT Adjustment of door travel is done by moving the limit cams on the threaded shaft. The position of the 4 limit switches are factory adjusted and should not be altered. The limit switches are: - “Open”...
Page 26: Section E: For Operators With Interface Modules Or Logic Boards
IMPORTANT: For momentary activation on close, the Nice photobeams (or a Micanan 2-wire monitored edge), must be installed as part of the operator system. If a Nice 2-wire monitored edge or the Nice infrared photobeam system is not installed (or not operating correctly), the operator will only operate in fault mode (constant pressure to close).
Page 27 2• V/1£ 2-4 VN:. L _______ NICE N-4 PHOTOCELL (MK00650) Note: The MK00650 photocell system has a maximum range of 24 ft. Sun visor protector optional. Installation Note: Photo beams should be mounted as close to the door track inside the door to offer maximum entrapment protection.
Page 28 Photo system operation: Nice photo beams must be connected for the door to close in momentary mode (unless a Nice monitored 2-wire edge is connected). When the photo system is properly installed and aligned, the infrared beam will detect any obstruction in the path of the beam.
Page 29 FRABA N-4/4X THRU-BEAM PHOTOCELL (MK00697) Note: The MK00697 photocell system has a maximum range of 45 ft. Sun visor protector optional. Select a location on the wall no more than 6 inches from the floor to install wall mounting brackets on the left and right side of the door.
Page 30: Clutch Adjustment
BRAKE ADJUSTMENT (For model PRO-TB) The brake adjustment is factory set and should only require minor adjustment after extensive use. Verify brake adjustment by manually holding in solenoid plunger. When brake is properly adjusted, the brake shoe pads should make complete contact with brake drum with sufficient brake spring tension to stop and maintain door when solenoid is de-energized.
Page 31: Emergency Manual Operation
EMERGENCY MANUAL OPERATION The operator is equipped with a quick release disconnect system to manually operate door in case of emergency. This feature should not be used to manually operate a malfunctioning door. WARNING TO REDUCE THE RISK OF INJURY OR DEATH: DO NOT ATTEMPT TO USE EMERGENCY DISCONNECT SYSTEM WHILE OPERATOR IS RUNNING.
Page 32: Operator Maintenance
OPERATOR MAINTENANCE WARNING TO REDUCE THE RISK OF INJURY OR DEATH: DO NOT ATTEMPT TO SERVICE THE OPERATOR UNLESS POWER SUPPLY HAS BEEN DISCONNECTED Inspect manual function of the door every 3-months. Make sure that door runs smoothly. If door does not manually open or close freely, have a qualified service person make repairs.
Page 35: Electrical Diagrams
RAD! □ RECEIVER ...+-+---+-+-+-- RED "' > >- <t ...J TO R SE MOTOR DIR ON INT CHANGE BLAC AND WH TE W ES ON ERSING STA TER. MDT□R RELAY REVERSING & / .&. RELAY 115VAC 220V 24VAC □R 230VAC &...
Page 36 CLOSE r-----{, RAY--- ..----"HITE IJHJTE-----, � RAD!□ RECEIVER BLUE---� □ 0 ADVANCED A D VANCED O HASE □ . □ . N , C, N , C, Q LIHifPf�ITCH Q i� TCH lv\n IMI� BLACK-- -+ -+-.+--+-- BLACK ACK- � �...
Page 37 BLACK ANTENNA YELL □ ',/ INT.LOCK OPEN & Tl�� CLOSE IF STOP BUTTON STOP VALUE USED. REMOVE JUMPER BETWEEN "STOP" AND ' " "" ' 1 � 1 · STOP LEARN MID. STOP © "COM" TERMINALS. □ ON-BOARD T3 ! RADI □...
Page 38 [ CLOSE RADIO ,---��----, N,0, RECEIVER BLACK ANTENNA N,C, INT.LOCK OPEN TI�� &. CLOSE IF STOP BUTTON STOP VALUE USED, REMOVE JUMPER \®/ BETWEEN "STOP" AND LEARN STOP "' " " I � 1 · MID. STOP OPEN "COM" TERMINALS. ©...
Page 39 CLOSE BRAKE SOLENOID (IF USED) RADIO RECEIVER --+ +- -+-t - -BLACK BLUE -4 rnzi:l • 2 � □ BLACK rnzi:l • � SEE CORRESPONDING ASTERISKS ON REVERSING STARTER. •□• DENOTES '□PEN' SIDE OF REVERSING STARTER. :i:: "' "' <t ...J )<...
Page 40 GRAY-- --� . BRAKE S LENDID (IF USED) □ RAD! □ RECEIVER :---1-1--+-I--- BLAC K---="""'4 -6 [jjzg •3 ,,- -- - �,--, BLUE BLACK -4[jjzg •2 □ SEE CORRESPONDING ASTERISKS N REVERSING STARTER, □ DENOTES ' PEN' SIDE F REVERSING ST ARTER, •□•...
Page 41 C L OSE � BLUE -- -- -c - □ RADID □. RECEIVER � -- � - � N.C. BLACK ANTENNA N.C. YELL N.O. □ INT.LOCK □ TI��t@ CLOSE STOP VALUE "' " " ' 1 � 1 · LEARN STOP &...
Page 42 C L OSE � BLUE N.O. N.C. BLACK ANTENNA YELL "' "' □ � >- GRAY INT.LOCK OPEN TI��tif�' r CLOSE STOP VALUE \& .& .&. LEARN STOP MID. STOP OPEN IF STOP BUTTON ON-BOARD T3 ! USED, REMOVE JUMPER □...
Page 43 notes...
Page 44 HEADQUARTERS HEAD OFFICE CHICAGO ATLANTA PHOENIX Nice Canada Nice S.p.A. 1380 St-Regis 721 W. Racquet Club Dr. 2885 N. Berkeley Lake Rd. 1236 W. Southern Ave. Oderzo, TV Italy 31046 Dorval, QC Canada Addison, IL USA Suite 7, Duluth, GA USA...
