- Page 1 Pro-T/TB/APT Automation for sectional overhead doors Instructions and warnings for installation and use...
-
Page 2: Table Of Contents
NICE N-4 Photocell (MK00650) . . . . . . . . . . . . . . . . . . -
Page 3: Warranty
Warranty NICE NORTH AMERICA warrants that materials and workmanship are free from defects for a period of four (4) years or 100,000 cycles, whichever comes first. The start of the warranty will be determined by the date of invoice. Materials returned to Nice deemed defective after examination will be returned at the option of Nice with repaired, new, or re-manufactured parts. -
Page 4: Verification Of Operator And Hardware
Verification of Operator and Hardware Upon delivery of your Nice heavy-duty trolley door operator, please inspect the unit carefully for damage. Verify that operator horsepower, voltage, phase and amperage correspond to available power supply and door application. Check that along with your operator you have received the following standard hardware. -
Page 5: Pro-T, Pro-Tb Specifications
PRO-T and PRO-TB heavy-duty trolley operators are designed for standard lift overhead sectional garage doors. Model PRO-TB is essentially the same as model PRO-T with the exception that the PRO-TB operator has a solenoid operated braking system. Standard Operator Weight 50-70 Lbs... -
Page 6: Important Safety Instructions
Important Safety Instructions WARNING TO REDUCE THE RISK OF INJURY OR DEATH:. • READ AND FOLLOW ALL INSTRUCTIONS • Never allow children to operate or play with door controls. Keep the remote control (where provided) away from children. • Personnel should keep away from a door in motion and keep the moving door in sight until it is completely closed or opened. NO ONE SHOULD CROSS THE PATH OF A MOVING DOOR. -
Page 7: Installation Instructions
Installation Instructions WARNING DO NOT INSTALL THIS OPERATOR BEFORE READING THIS MANUAL CAREFULLY. NOTE: • Installation of operator must be done by a qualified installer. Door must be properly installed and working smoothly. Remove all door locks prior to installation. 1. -
Page 8: Preparation
Preparation 1. Lay out operator and trolley tracks on ground in front of door with door operator motor facing away from door. 2. Install track spacers evenly to track assembly. 3. Install 3/8” take-up bolt to carriage using two 3/8” hex nuts and lock washer provided. 4. -
Page 9: Wall Mounting Bracket And Operator Installation
Wall Mounting Bracket and Operator Installation NOTE : Trolley type operators should generally be mounted directly over the center of the door and the trolley tracks should clear the tracks by 2-1/2” (6.5 cm). However, if interfering structures or other reasons do not allow for centered mounting, it is possible to install it up to 18”... - Page 10 6. Install hanging brackets (braces) from ceiling or structure to any of the five 3/8” holes located on operator frame. For tracks over 14’ long it is recommended to install braces to the tracks at 4’(1.2m) to 5’ (1.5m) from operator. BRACES BRACES BRACES...
-
Page 11: Electrical Connections
EACH INDIVIDUAL COMMERCIAL DOOR OPERATOR MUST HAVE IT’S OWN DEDICATED POWER SUPPLY • NICE HIGHLY RECOMMENDS THAT EACH INDIVIDUAL COMMERCIAL DOOR OPERATOR HAVE AN EXTERNAL CIRCUIT BREAKER OR FUSED DISCONNECT WARNING COMPARE AVAILABLE POWER SUPPLY VOLTAGE TO OPERATOR NAMEPLATE PRIOR TO ELECTRICAL CONNECTION. -
Page 12: Section A: Pro-T, Pro-Tb
SECTION A: PRO-T, PRO-TB Standard relay logic controls (not UL325 (2010) compliant, not available in US or Canada) Connection of Power Supply and Control Station Power Wiring: Use 1-1/8” (2.85 cm) diameter holes for all power wiring. 1. Single Phase: Connect single phase power supply to terminals L/L1 (line) and N/L2 on three-pole power terminal strip. -
Page 13: Connection Of A Reversing Edge Device And Control Accessories
Connection of a Reversing Edge Device and Control Accessories 1. Reversing Edge device (must be normally open contact): NOTE: If the door is controlled by any device or wired in such a manner that the door is not controlled by constant pressure on close then an appropriate reversing edge must be installed. -
Page 14: Section B: Pro-T(M), Pro-Tb(M) Relay Logic Controls With
Operator Electrical Connections and Start-up Instructions NOTE: THIS OPERATOR COMES WITH AN INTERFACE MODULE INTEGRATED INTO THE CONTROL CIRCUIT. THE PURPOSE OF THE INTERFACE MODULE IS TO ALLOW FOR FAILSAFE MONITORING OF A NICE COMPATIBLE SAFETY DEVICE AS PER UL 325 (2010) REQUIREMENTS. - Page 15 3) Verify Motor Direction After the electrical power connections are made and push button station is connected, manually move the door to mid-position. Press Close button for several seconds and then press stop button. If door did not move in correct direction (or if limit cams not moving in correct direction towards the close limit switch) see below: Single Phase Operators: The operators leave the factory with correct motor and limit shaft direction according to standard door installations.
- Page 16 Primary monitored safety device: Nice monitored failsafe photo beams or Nice compatible monitored failsafe devices must be connected to terminals P1 and P2 if momentary close on pushbutton is required (B2 mode). If not connected, door can only be closed by constant pressure on close pushbutton.
-
Page 17: Section C: Pro-J(E): Pro-H(E) Full Feature Logic Board
SECTION C: PRO-J(E): PRO-H(E) Full Feature Logic Board Smart 10 .0 [UL325 (2010) Compliant] NOTE: The operator is shipped from the factory in the D1 mode setting (constant pressure open and close). The operator should remain in this mode until all connections and limit switch adjustments are completed. Power Wiring Instructions Connect primary power supply directly to the separate power terminal strip supplied using any of the 1-1/8”... - Page 18 Primary monitored safety device Nice monitored failsafe photo beams or Nice compatible monitored failsafe devices must be connected to terminals P1 and P2 as primary monitored safety device. Primary monitored safety device must be connected if momentary activation on close is required in B2, T and TS modes.
-
Page 19: Connection Of External Single-Button Device
Secondary Non-Monitored Safety Device(s): A standard 2-wire safety edge, non-monitored photo beams or any other non-monitored reversing devices with a N.O contact can be connected to terminals S1 and S2 as secondary non-monitored safety device. NOTE: More than one secondary non-monitored safety device can be connected to terminals S1 and S2. IMPORTANT: Do not remove the resistor that is factory installed across terminals S1 and S2 unless installing a 4-wire electric edge. - Page 20 C2 (Momentary open, constant pressure close): • Open Button: Momentary activation opens the door. When door is closing, momentary activation reverses the door (OPEN OVERRIDE). Momentary contact from mid-stop opens the door to full open position. Constant activation when door is opening, bypass mid-stop if enabled. •...
-
Page 21: Programming Instructions
• Timer to Close: Closes the door from mid-stop or full open. Momentary activation of stop button will deactivate the timer. When door is closing, momentary activation of safety devices will reverse the door to mid-stop (if enabled) or full open and deactivates the timer. -
Page 22: Mid-Stop Setup
POT2 amount of time. On-Board Receiver Programming This logic board has a built-in 372 MHz radio receiver and can only be used with Nice single button, 3-button (OPEN/CLOSE/STOP) and 3-channel radio transmitters. Installing the Antenna Direct Connection: Attach the antenna when supplied with the operator to the F connector on the control box. -
Page 23: Programming The On-Board Radio Receiver
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: If an external radio-receiver (Nice or other) is used instead of the built-in radio receiver, it is highly recommended to disconnect the co-axial cable from the logic board. -
Page 24: Dip-Switch Setup
Mid-stop Timer Timer is enabled from mid-stop only full open a timer for mid-stop Nice recommends 1 .5 second delay on Delay on reverse Delay on reverse is 1 .5 seconds Delay on reverse is 0 .5 seconds reverse for all applications... -
Page 25: Section D: For All Operator Control Types
SECTION D: For all Operator Control Types Limit Switch Adjustment Adjustment of door travel is done by moving the limit cams on the threaded shaft. The position of the 4 limit switches are factory adjusted and should not be altered. The limit switches are: •... -
Page 26: Section E: For Operators With Interface Modules Or Logic
IMPORTANT For momentary activation on close, the Nice photobeams (or a Nice 2-wire monitored edge), must be installed as part of the operator system. If a Nice 2-wire monitored edge or the Nice infrared photobeam system is not installed (or not operating correctly), the operator will only operate in fault mode “constant pressure to close”. -
Page 27: Nice N-4 Photocell (Mk00650)
6. Connect these paired wires to the P1 and P2 terminals on the logic board (or interface module if applicable) as shown in Figure 3. FIGURE 3 NICE N-4 Photocell (MK00650) NOTE: The MK00650 photocell system has a maximum range of 24 ft. Sun Visor protector optional. Installation NOTE: Photo beams should be mounted as close to the door track inside the door to offer maximum entrapment protection. -
Page 28: For Nice Nema-1 Photobeams
Photo system operation: Nice photo beams must be connected for the door to close in momentary mode (unless a Nice monitored 2-wire edge is connected). When the photo system is properly installed and aligned, the infrared beam will detect any obstruction in the path of the beam. -
Page 29: Fraba N-4/4 Thru-Beam Photocell (Mk00697)
FRABA N-4/4 Thru-Beam Photocell (MK00697) NOTE: The MK00687 photocell system has a maximum range of 45 ft. Sun Visor protector optional. 1. Select a location on the wall no more than 6 inches from the floor to install wall mounting brackets on the left and right side of the door. -
Page 30: Clutch Adjustment
Clutch Adjustment Installation Safety Precautions 1. Remove cotter pin tapped to pulley. 2. Rotate clutch nut counterclockwise (loosen) until there is insufficient tension to permit clutch to drive door. 3. Gradually tighten clutch nut until the tension on the Spring is sufficient to permit clutch to drive door smoothly but will allow clutch to slip if door is obstructed. -
Page 31: Emergency Manual Operation
Emergency Manual Operation The operator is equipped with a quick release disconnect system to manually operate door in case of emergency. This feature should not be used to manually operate a malfunctioning door. WARNING TO REDUCE THE RISK OF INJURY OR DEATH: DO NOT ATTEMPT TO USE EMERGENCY DISCONNECT SYSTEM WHILE OPERATOR IS RUNNING. -
Page 32: Operator Maintenance
Operator Maintenance WARNING TO REDUCE THE RISK OF INJURY OR DEATH: DO NOT ATTEMPT TO SERVICE THE OPERATOR UNLESS POWER SUPPLY HAS BEEN DISCONNECTED. • Inspect manual function of the door every 3-months. Make sure that door runs smoothly. If door does not manually open or close freely, have a qualified service person make repairs. -
Page 33: Trolley Operator Pro-T/Pro-Tb Diagram
Trolley Operator Pro-T/Pro-TB Diagram... -
Page 34: Trolley Operator Pro-T / Pro-Tb Parts List
Trolley Operator Pro-T / Pro-TB Parts List PRO-TB PRO-T CODE ARTICLE# DESCRIPTION C/W BRAKE QUANTITY QUANTITY MB01001 Motor 1/2HP 110/220V 1PH BM ODP MB02001 Motor 3/4HP 110/220V 1PH BM ODP MD00004 Sprocket 410B12 x 1" Bore 1/4" KW (2SS 1/4"-20) (1/2HP models) MD00007 Sprocket 41B12 x 1"... - Page 35 Trolley Operator Pro-T / Pro-TB Parts List MJ00006 Limit Switch Double Spacer 3/4" MJ00013 Brake Assembly #1 (Standard Operator) CODE ARTICLE# DESCRIPTION QUANTITY MK00004 Limit Switch MK00027 Solenoid 220V MM00001 Control Box Cover MM00002 Control Box MSI0001 MM00010 HHD Brake Plate MSI0007...
-
Page 36: Trolley Operator Pro-Apt/Aptb Diagram
Trolley Operator Pro-APT/APTB Diagram... -
Page 37: Trolley Operator Pro-Apt/Aptb Parts List
Trolley Operator Pro-APT/APTB Parts List CODE ARTICLE# DESCRIPTION QUANTITY MB01001 Motor 1/2HP 110/220V 1PH BM ODP MB02001 Motor 3/4HP 110/220V 1PH BM ODP MB01102 Motor 1/2HP 208/460V 3PH BM ODP MB01202 Motor 1/2HP 575V 3PH BM ODP MB02102 Motor 3/4HP 208/460V 3PH BM ODP MB02202 Motor 3/4HP 575V 3PH BM ODP MD00005... - Page 38 Trolley Operator Pro-APT/APTB Parts List CODE ARTICLE# DESCRIPTION QUANTITY MJ00004 Clutch Plate 0.75" ID MJ00005 Clutch Pad MJ00006 Limit Switch Double Spacer 3/4" MJ00013 Brake Assembly #1 (Standard Operator) MK00004 Limit Switch MK00026 Solenoid 120V MK00027 Solenoid 240V MK00028 Solenoid 460V MK00029 Solenoid 575V MM00001...
-
Page 39: Ms100-Ww 1-Phase Wiring Diagram
MS100-WW 1-Phase Wiring Diagram... -
Page 40: Ms100-Im-Ww 1-Phase Wiring Diagram
MS100-IM-WW 1-Phase Wiring Diagram... -
Page 41: Msl100-110V-Ww 1-Phase Wiring Diagram
MSL100-110V-WW 1-Phase Wiring Diagram... -
Page 42: Msl100-220V-Ww 1-Phase Wiring Diagram
MSL100-220V-WW 1-Phase Wiring Diagram... -
Page 43: Ms300-Ww 3-Phase Wiring Diagram
MS300-WW 3-Phase Wiring Diagram... -
Page 44: Ms300-Im-S Wiring Diagram
MS300-IM-S Wiring Diagram... -
Page 45: Msl300-Ww 3-Phase Wiring Diagram
MSL300-WW 3-Phase Wiring Diagram... -
Page 46: Msl300-Ww 3-Wiring Diagram
MSL300-WW 3-Wiring Diagram... -
Page 47: Notes
Notes... - Page 48 Technical Support: Nice North America 877-888-1116 c/o Customer Service 5919 Sea Otter Place, Suite 100 Technical Support Hours: Carlsbad, CA 92010 M – F, 8:00 a.m. – 6:00 p.m. ET Niceforyou.com ©2023 Nice North America LLC. All rights reserved. MN00020 Rev-A...
