PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE
kit user guide

About this document

Scope and purpose
KIT_PSoC4-HVMS-64K_LITE is a lite kit for the PSOC™ high-voltage (HV) mixed signal (MS) microcontroller, a
fully integrated programmable embedded system for several automotive human machine interface (HMI),
body, and powertrain applications. The system features an Arm® Cortex®-M0+ processor with programmable
and reconfigurable analog and digital blocks.
It is a microcontroller with the following features:
A 12-bit SAR ADC
•
Fifth-generation multi-sense converter (MSC) block supporting capacitive sensing (CAPSENSE™)
•
Digital peripherals such as PWMs
•
Serial communication interfaces along with a LIN/CXPI interface with integrated PHY
•
High-voltage subsystem to operate directly off the 12-V car battery
•
Intended audience
This document is intended for design engineers and evaluation for automotive HMI, body, and powertrain
applications.
User guide
Please read the sections "Important notice" and "Warnings" at the end of this document
www.infineon.com
002-38460 Rev. *B
2025-03-17

Advertisement

loading
Need help?

Need help?

Do you have a question about the KIT PSoC4-HVMS-64K LITE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infineon KIT PSoC4-HVMS-64K LITE

Summary of Contents for Infineon KIT PSoC4-HVMS-64K LITE

  • Page 1: About This Document

    • Intended audience This document is intended for design engineers and evaluation for automotive HMI, body, and powertrain applications. User guide Please read the sections “Important notice” and “Warnings” at the end of this document 002-38460 Rev. *B www.infineon.com 2025-03-17...

  • Page 2: Important Notice

    Boards provided by Infineon Technologies. The design of the Evaluation Boards and Reference Boards has been tested by Infineon Technologies only as described in this document. The design is not qualified in terms of safety requirements, manufacturing, and operation over the entire operating temperature range or lifetime.

  • Page 3: Safety Precautions

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Safety precautions Safety precautions Note: Please note the following warnings regarding the hazards associated with development systems. Table 1 Safety precautions Warning: The evaluation or reference board contains DC bus capacitors which take time to discharge after removal of the main supply.

  • Page 4: Table Of Contents

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Table of contents Table of contents About this document ........................1 Important notice ..........................2 Safety precautions .......................... 3 Table of contents ..........................4 KIT_PSoC4-HVMS-64K_LITE kit contents ................... 5 Overview ..............................6 Block diagram ............................

  • Page 5: Kit_Psoc4-Hvms-64K_Lite Kit Contents

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide KIT_PSoC4-HVMS-64K_LITE kit contents KIT_PSoC4-HVMS-64K_LITE kit contents The kit includes one main board and a USB cable. Figure 1 KIT_PSoC4-HVMS-64K_LITE kit contents User guide 002-38460 Rev. *B 2025-03-17...

  • Page 6: Overview

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide KIT_PSoC4-HVMS-64K_LITE kit contents Overview The KIT_PSoC4-HVMS-64K_LITE board can mount the 56-QFN package of PSOC™ 4 HVMS 64K microcontrollers (MCU). The kit features and blocks are shown in Figure Figure 2 KIT_PSoC4-HVMS-64K_LITE board - top view Block diagram Figure 3 KIT_PSoC4-HVMS-64K_LITE kit board –...

  • Page 7: Board Functions

    23 mikroBUS header Two 1x8 mikroBUS headers J32/J33 24 Groove connector 5-pin, 100 mils, SMBus No load 25 XENSIV™ S2G Bus Infineon’s XENSIV™ bus sensor 17- S2G1 No load connector pin interface 26 User LED User LED connected to MCU...

  • Page 8: Getting Started

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Getting started Getting started Initial jumper configuration The initial jumpers are configured according to the factory default settings. Figure 4 Initial jumper configuration and switch setting Table 3 lists the configuration of jumpers. Table 3 Jumper details Reference...

  • Page 9: Power From Usb

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Getting started 2.2.1 Power from USB By default, the lite kit is configured to run on 5 V. Ensure the power jumpers, J35 and J36, are closed on position (J35_2-J35_3 and J36_2-J36_3) for USB-powered configuration. In case of USB power, the different sections’ power requirements are as follows: MCU power: VBAT from USB (5 V) •...

  • Page 10: Hands-On Shipping Firmware

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Getting started Hands-on shipping firmware The KIT_PSoC4-HVMS-64K_LITE kit comes with preinstalled firmware to check all the onboard peripherals. The firmware logs different events on the serial USB or LIN slave interface for the user. For simplicity, the serial console is set in the default mode and all the events are sent to the serial terminal with the fixed event IDs.

  • Page 11: Software Checks

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Getting started 2.3.2 Software checks The lite kit comes with a preinstalled firmware and starts executing as soon as it is powered on. After completing the tool setup, follow these steps to check the firmware and lite kit features: 1.

  • Page 12: Hardware

    The board also has a provision to install the MCU socket; a supported socket part is given for reference. Table 4 IC socket description Reference Manufacturer Part number Size Supported package Infineon Technologies CY8C4146LWE 8 mm × 8 mm 56-QFN Socket Enplas Corporation QFN-56AMG-0.5-005S-00 25 mm ×...

  • Page 13: Capsense™ Buttons

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Hardware Figure 10 Power supply configuration on lite kit Note: 1. By default, the KIT_PSoC4-HVMS-64K_LITE kit supports 5 V power input from the USB port. To change the power input configuration, remove the resistor from positions 2-3 of connectors J35 and J36 and install the resistor on positions 1-2 of connectors J35 and J36.

  • Page 14: Potentiometer And Temperature Sensor

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Hardware Potentiometer and temperature sensor The KIT_PSoC4-HVMS-64K_LITE kit has an onboard temperature sensor and potentiometer to evaluate the analog functions. The temperature sensor uses a thermistor (R29) with a divider resistor and potentiometer (R30) uses 250k variable resistor.

  • Page 15: Kitprog3 Usb Program Interface

    LIN/CXPI interface on lite kit KitProg3 USB program interface KitProg3 is Infineon’s low-level communication firmware for programming and debugging. It provides communication between the programming tool (AutoFlash Utility) and a target PSOC™ HVMS device. KitProg3 uses the industry-standard Serial Wire Debug (SWD) protocol. It uses CMSIS-DAP V2.0.0 and V1.2.0 as the bulk and HID endpoint transport mechanisms.

  • Page 16: Third-Party Debugger Connector

    Third-party debugger connector on lite kit Extension headers The KIT_PSoC4-HVMS-64K_LITE kit provides a variety of header expansions to be compatible with the most popular interfaces. The kit is compatible with Arduino connection headers, Infineon standard connector interface, mikroBUS header, and XENSIV bus.

  • Page 17: Arduino Compatible Header

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Hardware 3.8.1 Arduino compatible header Table 8 Pin assignment of Arduino compatible connections Connector Pin number Pin name KIT_PSoC4-HVMS-64K_LITE connections IOREF VDDIO RESET XRES 3P3V_LDO 5V_LDO DGND DGND VBAT P5_2 P5_3 P5_4 P5_5 A4/SDA P5_0...

  • Page 18: Ifx Standard Header

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Hardware 3.8.2 IFX standard header Table 9 Pin assignment of IFX standard connections Connector Pin number Pin name KIT_PSoC4-HVMS-64K_LITE connections 3P3V_LDO DGND DGND 5V_LDO 3P3V_LDO DGND DGND 5V_LDO 3.8.3 mikroBUS compatible header Table 10 Pin assignment of mikroBUS compatible connections Connector...

  • Page 19: Xensiv Tm Header

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Hardware 3.8.4 XENSIV header Table 11 Pin assignment of XENSIV bus connections Connector Pin number Pin name KIT_PSoC4-HVMS-64K_LITE connections S2G1 5V_LDO S2G1 P5_6 S2G1 P5_7 S2G1 P0_1 S2G1 P0_0 S2G1 DGND S2G1 3P3V_LDO S2G1 P3_2...

  • Page 20: Other Peripherals

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Hardware Other peripherals The GPIO pins are grouped into ports; a port can have up to eight GPIOs. See Table 8 for the GPIO pin assignments. The following table shows the connection to other peripherals. Table 13 GPIO pins used by peripherals GPIO pin assignment...

  • Page 21: Programming And Debugging

    The power supply that the board gets from the USB bus power is also used for programming. The MCU flash data is programmed via the PSOC™ 5 LP device in KitProg3, which is the Infineon low-level communication firmware for programming and debugging. See the PSOC™ programmer user guide along with KitProg3 user guide for more information.

  • Page 22: Program And Debug Using An Iar Embedded Workbench

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Programming and debugging Program and debug using an IAR embedded workbench Download and install the latest AutoPDL for the PSOC™ HV devices on the target system. Install the AutoPDL outside the default program files to allow the IAR to access and create temporary files. Follow the installation steps given in “PSoC4HV_AutoPDL-MW_InstallationManual.pdf”...
  • Page 23 PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Programming and debugging Do the following to download and debug using the CM0+ core workspace: 1. Start IAR EWARM and open the AutoPDL template workspace file from: AutoPDL_Installation_Directory\examples\Tools\psoc4hvms64\psoc4hvms64k_flash_cm0plus_template.eww Figure 19 Selecting CM0+ single core template 2.
  • Page 24 PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Programming and debugging 3. Open “cy_pdl_config.h” present under “userenv” folder and select device for HVMS64K. Figure 21 Selecting target device 4. Right-click psoc4hvms64k_flash_cm0plus_template - Debug and select Rebuild All. Figure 22 Rebuilding workspace revision User guide 002-38460 Rev.
  • Page 25 PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Programming and debugging 5. The rebuild process starts. Check for errors and warnings in the Build log. Figure 23 Checking build status in build log 6. To load the program to the flash region of CM0+ core, click the green Download and Debug icon. Figure 24 Downloading and debugging User guide...
  • Page 26 PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Programming and debugging 7. Click the Go button to start executing the code from MCU. Note: You can also use the function keys in the Debug window: Go (F5), Step over (F10), Step into (F11), and Download and Debug (Ctrl+D).

  • Page 27: Schematics And Designs

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Schematics and designs Schematics and designs KIT_PSoC4-HVMS-64K_LITE kit schematics The KIT_PSoC4-HVMS-64K_LITE kit schematic is documented in this section. User guide 002-38460 Rev. *B 2025-03-17...
  • Page 28 Figure 27 PSOC™ 4 HVMS lite kit block diagram...
  • Page 29 Figure 28 KIT_PSoC4-HVMS-64K_LITE kit schematic: KitProg3...
  • Page 30 Figure 29 KIT_PSoC4-HVMS-64K_LITE kit schematic: Peripherals...
  • Page 31 Figure 30 KIT_PSoC4-HVMS-64K_LITE kit schematic: PSOC™ HVMS...
  • Page 32 Figure 31 KIT_PSoC4-HVMS-64K_LITE kit schematic: Power and components...
  • Page 33 Figure 32 KIT_PSoC4-HVMS-64K_LITE kit schematic: Arduino connectors...

  • Page 34: Kit_Psoc4-Hvms-64K_Lite Kit Assembly Drawing

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Schematics and designs KIT_PSoC4-HVMS-64K_LITE kit assembly drawing The KIT_PSoC4-HVMS-64K_LITE kit assembly drawing is documented in this section. Figure 33 Top view of KIT_PSoC4-HVMS-64K_LITE kit assembly drawing Figure 34 Bottom view of KIT_PSoC4-HVMS-64K_LITE kit assembly drawing User guide 002-38460 Rev.

  • Page 35: References

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide References References Datasheet Contact Infineon Support to obtain this document. [1] CY8C41x6, PSOC™ 4 High Voltage (HV) Mixed Signal (MS) Automotive MCU based on 32-bit Arm® Cortex®-M0+ User guide 002-38460 Rev. *B...

  • Page 36: Glossary

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Glossary Glossary capacitive sigma-delta CAPSENSE™ mutual sensing CXPI clock extension peripheral interface human machine interface HVMS high-voltage mixed signal light emitting diode local interconnect network microcontroller multi-sense converter printed circuit board pulse width modulation SAR ADC successive approximation resistor analog-to-digital converter Universal Serial Bus...

  • Page 37: Revision History

    PSOC™ 4 HVMS 64K: KIT_PSoC4-HVMS-64K_LITE kit user guide Revision history Revision history Document Date of release Description of changes version 2023-08-28 Initial release. 2024-02-06 Updated pointer from 3P3V to 3V3 in section 2.2.1 and section 2.2.2. Updated usage of SDL to AutoPDL in section 4.2.

  • Page 38: Disclaimer

    All referenced product or service names and trademarks are the property of their respective owners. PSOC™, formerly known as PSoC™, is a trademark of Infineon Technologies. Any references to PSoC™ in this document or others shall be deemed to refer to PSOC™.
