- Page 1 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 WM150 DEHUMIDIFIER WM150 DEHUMIDIFIER WM150 DEHUMIDIFIER WM150 DEHUMIDIFIER OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL OWNER’S MANUAL www.eipl.co.uk Page 1 of 16...
-
Page 2: Safety Information
Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 SAFETY INFORMATION Children shall not play with the appliance. This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved. - Page 3 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 The appliance uses R454c refrigerant gas. This gas is much kinder to the environment as it is non-toxic with zero Ozone Depletion Potential (ODP). This is a flammable gas and the following warnings should be considered: •...
- Page 4 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 DEHUMIDIFIER PRINCIPLE Dehumidifiers remove moisture from the air that is circulating through the appliance. The resulting reduction of relative humidity helps prevent rust, rot, mould, mildew and condensation within the room, or other enclosed spaces where the dehumidifier is used.
-
Page 5: Installation
Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 INSTALLATION POSITIONING: The appliance can be left free standing and should be positioned in the center of the room to be conditioned if at all possible. If a damp patch is particularly apparent the outlet grille should be pointed towards it. - Page 6 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 NOTE: Both inlet grille and outlet grille of the appliance must have clear space around them and not be obstructed in anyway. The unit must also be level whether free standing or wall mounted.
-
Page 7: Operation
After defrost the lights will switch back. Shutdown Procedure After using the WM150, turn it off at the switch (do not disconnect from mains supply) for 5 minutes to allow the condensate on the coils to drain into the pump reservoir. - Page 8 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 Light Functions: The unit has four LED indicators, located on the side of the unit. The following lists the functions of these lights: 1 - ON / OFF Green solid –...
-
Page 9: Routine Service
Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 ROUTINE SERVICE WARNING: ENSURE THE POWER CORD TO THE APPLIANCE IS DISCONNECTED BEFORE CARRYING OUT ROUTINE SERVICE. SERVICING AND REPAIR SHOULD ONLY BE CARRIED OUT BY A SUITABLY QUALIFIED PERSON. To ensure continued full efficiency of the appliance, maintenance procedures should be performed as follows: Clean the surface of the evaporator and condenser coils by blowing the... -
Page 10: Specifications
Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 SPECIFICATIONS : 11285GL-GB ODEL : 680 mm (26.7 in) EIGHT : 810 mm (31.9 in) IDTH : 305 mm (12 in) EPTH : 75 Kg (165.3 lb) EIGHT : 580 M /Hr (341 CFM) IRFLOW... - Page 11 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 APPLIANCE SPARE PARTS LIST Description Part Number Product Part Number 11285GL-GB PCB Timer 1619522 Controls Display PCB 1619524 Humidity Sensor PCB 1619526 PCB Connecting Cable 2013748 Condenser Coil 2028400 Evaporator Coil 2028401 Filter 2028517 Mains Cable 2029217...
- Page 12 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 300mm 300mm 300mm 300mm Page 12 of 16...
- Page 13 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 Page 13 of 16...
- Page 14 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 Page 14 of 16...
- Page 15 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 Page 15 of 16...
- Page 16 Drawing : - TPC550 Issue : - 2 Date : - 29/11/24 UK Head Office American Sales Office Ebac Industrial Products Ltd Ebac Industrial Products Inc St Helens Trading Estate 700 Thimble Shoals Blvd. Bishop Auckland Suite 109, Newport News County Durham Virginia, 23606-2575 DL14 9AD...
