The X1E combo package comes with the following:
screen
spool holder
filament
spare hotend
2 nozzle wiping pads
power cord
unclogging pin tool
glue stick for build plate
Bambu filament swatches
air filter
4*6PIN cable
screw pack for scraper
Allen Keys (H1.5 and H2)
screw pack for spool holder
screw pack for extruder
hotend clip
2 scrapers
micro ridar quick label
Textured PEI Plate (pre-installed on the hotbed)
lubricant oil
thermal paste
5 lubricant grease
quick start guide
disclaimer
AMS disclaimer
warranty leaflet.
Step 1: Unboxing and Removing Protective Parts
Open the cardboard box and remove the foam inserts.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bambu Lab X1E
Summary of Contents for Bambu Lab X1E
- Page 1 The X1E combo package comes with the following: screen spool holder filament spare hotend 2 nozzle wiping pads power cord unclogging pin tool glue stick for build plate Bambu filament swatches air filter 4*6PIN cable screw pack for scraper Allen Keys (H1.5 and H2)
- Page 2 Take out the plastic bag and retrieve the Quick Start Guide from the top cover (please read the Quick Start Guide before proceeding to the next step). Take out the printer and the filament spools and air filter included at the bottom of the box. Step 2: Remove the glass top cover and the plastic bag protecting the front door glass.
- Page 3 Step 3: Take out the accessory box.
- Page 4 Step 4: Remove the two fixing screws of the AMS and take out the AMS. Step 5: Remove the front chamber LED protective cover (do not forget this step) Forgetting to remove the protective cover will result in XY home position errors, leading to print failures and a series of error messages.
- Page 5 Step 6: Remove the four fixing screws of the AMS bracket and take out the bracket. Step 7: Remove the zip tie, protective cardboard, and tape from the tool head.
- Page 6 Step 8: Remove the three fixing screws of the heatbed. Open the front glass door and remove the three screws securing the heatbed. Step 9: Place the build plate.
- Page 7 Step 10: Install the touchscreen Carefully connect the ribbon cable to the touchscreen. You may need to gently pull the ribbon cable, so handle it with caution to avoid damage. When inserting the ribbon cable, ensure the correct orientation and try to insert it vertically. If you need to remove it, make sure to press the buttons on both sides to release the metal latch.
- Page 8 Step 11: Install the external spool holder and put the glass top cover back in place.
- Page 9 Step 12: Install the AMS. Remove the protective film from the AMS. Take out the spare PTFE tubes. Place the AMS on top of the printer.
- Page 10 Connect the PTFE tubes. Use the 4-pin cable to connect the filament bu er to the printer.
- Page 11 Use the 6-pin cable to connect the filament bu er to the AMS.
- Page 12 Step 13: Power on the printer, start it up, and complete the initialization process...
- Page 13 Step 14: Complete the calibration and remove the foam under the heatbed. Note: After the calibration is completed, please remember to remove the fixed foam under the heatbed. Step 15: Place the provided filament into the AMS, and close the AMS cover...
