TRASSIR TR-D8321WDIR4 User Manual

Specification
Model TR-D8321WDIR4
Image sensor 1/2.8" CMOS 2МP
Max resolution 2MP(1920x1080)
Main stream 50Hz: 2MP@25fps (WDR on)
2MP@50fps (WDR off)
60Hz: 2MP@30fps (WDR on)
2MP@60fps (WDR off)
Substream
50Hz: 720p@25fps (WDR on)
720p@50fps (WDR off)
60Hz: 720p@30fps (WDR on)
720p@60fps (WDR off)
Third stream 50Hz: 4CIF@25fps (WDR on)
4CIF@50fps (WDR off)
60Hz: 4CIF@30fps (WDR on)
4CIF@60fps (WDR off)
Electronic shutter speed 1/2 ~ 1/1 000 s
Day/Night mode Mechanical ICR
Sensitivity 0.003Lux (F1.3)
IR range
up to 40 m
Lens (mm)
Field of view (horiz./vert.)
2.8mm: 109˚±5˚ / 57˚±5˚
3.6mm: 87˚±5˚ / 47˚±5˚
Axes setting Pan: 0˚-360˚
Tilt: 0˚-90˚
Rotation: 0˚-360˚
WDR Real WDR (120dB)
Digital noise reduction
Video compression Н.265+ / Н.265 / H.264
Bitrate up to 8Mbps
Local storage MicroSD up to 256GB
Audio Built-in microphone
Audioinput / Audiooutput
Alarm inputs/outputs
Corridor mode
IVS
RTC
General
Power supply
PoE Class
Power consumption
Case material
Dimensions (mm)
Weight Net/Gross (g)
Protection
Power surge suppressor
Working temperature
Cold start
2.8 / 3.6
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
3D DNR
1 / 1
Yes
Yes
No
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
TR-D8321WDIR4
Outdoor IR Eyeball Network Camera
PoE (802.3af) / 12V DC
0
DC: 5.6W
PoE: 6.4W
Metal
Ø93 x 92.2
400 / 490
IP67, IK10
TVS 4000V
-40°C ... +60°C
-40°C
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
IK10
