Level Controller, Operating and Display Unit
Description
The functional unit consisting of the operating and display unit BHD50 and the LCR2652 level controller in conjunction with level
transmitter LP20/LP21/PA420 is used as water level controller and as a limit switch, for instance in steam boilers, (pressurized) hot-
water installations as well as condensate and feedwater tanks. One BHD50 can be used with a LCR2652 and a BCR3250 controller to
provide a combined level and TDS control system.
A level limit switch (LCS3050 and/or LCS3051) can be connected to the LCR2652 to signal and log level alarms on the BHD50.
The LCR2652 level controller processes the level-dependent current signal from the LP20/LP21/PA420 level transmitter. This input
signal is recognised by the controller as 0 and 100 % of the boiler measuring range.
The operating and display unit BHD50 and the level controller LCR2652 form a functional unit featuring the following properties:
-
3-position stepping controller with proportional-plus-integral
control action (PI controller) and control of an electrically
actuated control valve (VMD - Valve Motor Drive)
-
Continuous controller as PI controller for the control of an
electro-pneumatically operated control valve and a relay for
pump ON/OFF control
-
Indication of MIN/MAX water level limit
-
Fill or discharge control
-
Level damping filter
-
Current inputs for steam and feedwater flowrate (2 or
3-element control)
-
Actual value output 4-20 mA
-
Level limit switch alarm input (24Vdc), to display the status
of any LCS3050 or LCS3051 level limit switch
-
Indication of actual value (indicated in percent and as
bar graph)
-
Standardized measuring range when the level transmitter
LP20/LP21/PA420 is connected
-
Indication/adjustment of control parameters
-
Adjustment and evaluation of current inputs for steam and
feedwater flowrate (2 or 3-element control)
-
Trend record
-
Indication and listing of errors, alarms and warnings
-
Test of MIN/MAX output relays
-
Manual/automatic operation
-
Modbus RTU (RS232, RS422 or RS485) and Modbus TCP
(Ethernet 10/100Mb) communication
-
Password protection
Local regulations may restrict the use of this product to below the conditions quoted.
LCR2652 BHD50
Typical applications
-
-
-
BHD50
Steam Boilers
Hot-Water Installations
Condensate and Feedwater Tanks
TI-P693-24
EMM Issue 1
Page 1 of 6
