LaneGuard
Single Sensor Blind Spot Detection System
Read and understand all warnings and instructions in this manual prior to use.
Failure to follow warnings and instructions could result in serious injury or death.
MN-1198 • Revision 012406 • ERN 10336
Kit 25341
Installation Guide
Watch the video
Info on Table of Contents page
Advertisement
Table of Contents
Related Manuals for Air Lift Towtal View LaneGuard
Summary of Contents for Air Lift Towtal View LaneGuard
- Page 1 Installation Guide LaneGuard Watch the video Single Sensor Blind Spot Detection System Info on Table of Contents page Kit 25341 Read and understand all warnings and instructions in this manual prior to use. Failure to follow warnings and instructions could result in serious injury or death. MN-1198 •...
- Page 2 Protect your Air Lift Purchase by Completing your Warranty Registration Thank you for purchasing an Air Lift towing solution product! Take a photo of your sales receipt and then scan the QR code to complete your online warranty registration.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Notation Explanation Important Safety Information Installation Precautions System Overview System Specifications Hardware and Tools Install LaneGuard Install the Indicator Lights Sensor Mounting Details LaneGuard Wiring Diagram Mount the LaneGuard Sensor Route the Sensor Harness Route the Main Harness Install the Control Unit 7-Way Wiring Electrical Connections Statements... -
Page 4: Introduction
Blind Spot Detection System Introduction Important Safety Information This guide has been crafted to simplify installing and maintaining the Air Lift Towtal View LaneGuard (single sensor) system. Every LaneGuard kit features state- of-the-art design, ensuring reliable performance for WARNING various applications. -
Page 5: System Overview
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System System Overview Sensor Holder LaneGuard Sensor Control Unit Indicator Lights (x2) Wiring Harnesses Main Harness Sensor Harness Indicator Light Harness (optional) System Specifications Description ..................Specification Operating Voltage ................12V (10.5-16V) Operating Temperature ................-20°C ~ +60°C... -
Page 6: Hardware And Tools
Rag ....................1 Safety glasses ................1 (x10) (x5) Missing or damaged parts? Call Air Lift customer Missing or damaged parts? Call Air Lift customer STOP! service at (800) 248-0892 for a replacement part. service at (800) 248-0892 for a replacement part. -
Page 7: Install Laneguard
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System Install LaneGuard Prepare LaneGuard for installation by following these recommendations: 1. Gather all necessary tools and materials for installation, including screwdrivers, drills, and any components specified in this installation guide. -
Page 8: Install The Indicator Lights
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System INSTALL THE INDICATOR LIGHTS Ensure the Indicator Light wires and Main NOTE Harness wires are routed for easy access. 1. Select the proper locations for the right & left Indicator Lights (D) to be installed. - Page 9 LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System 5. Route the Indicator Light's wire through the drilled hole (Fig. 5). Fig. 5 6. Remove the adhesive release paper from the back of the Indicator Light and install it to the cleaned surface (Fig.
-
Page 10: Sensor Mounting Details
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System SENSOR MOUNTING DETAILS 1. The LaneGuard Sensor unit is comprised of a Sensor Holder (A) and the LaneGuard Sensor (B) (Fig. 8). Fig. - Page 11 LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System 7. Sensor to Ground (vertical): Locate an installation area for the 79" LaneGuard Sensor unit between 59 – 79 inches (150 – 200cm), preferably within 59 –...
-
Page 12: Laneguard Wiring Diagram
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System LANEGUARD WIRING DIAGRAM Sensor Harness Control Unit LaneGuard Sensor Unit Fig. 14 MN-1198... - Page 13 LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System Indicator Light (left) Main Harness Connections Right turn signal Left turn signal Power (12V+) (Red) GND (Black) ROUTE TO THE JUNCTION BOX Indicator Light (right) Main Harness (45') Use a multi-meter for identifying wires in...
-
Page 14: Mount The Laneguard Sensor
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System MOUNT THE LANEGUARD SENSOR CAUTION BE AWARE OF WHAT IS ON THE OTHER SIDE OF THE SURFACE BEING DRILLED. CONFIRM THERE IS ROOM TO ROUTE CABLES BEFORE DRILLING. 1. - Page 15 LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System 8. Remove the adhesive release paper from the back of the Sensor Mounting Gasket (H) and apply it to the back of the Sensor Holder (A), aligning the mounting holes on both components (Fig.
-
Page 16: Route The Sensor Harness
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System ROUTE THE SENSOR HARNESS Please keep in mind that each installation will be unique. The primary objective when NOTE routing the Sensor Harness is to ensure it is Example of the as unobtrusive as possible while still allowing Sensor Harness... -
Page 17: Route The Main Harness
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System ROUTE THE MAIN HARNESS Please keep in mind that each installation will be unique. The primary objective when NOTE Cavity wall routing the Main Harness is to ensure it is as unobtrusive as possible while still allowing for easy access. -
Page 18: Install The Control Unit
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System INSTALL THE CONTROL UNIT 1. Confirm the identified location to install the Control Unit (C) is within reach of the Sensor Harness connector and Main Harness connector routed in the two previous sections of this installation guide. -
Page 19: 7-Way Wiring Electrical Connections
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System 7-WAY WIRING ELECTRICAL CONNECTIONS 1. Remove the cover to the junction box which is typically under the front of the trailer (Fig. 31). If there is no junction box, check the connections to identify turn signals and other NOTE... - Page 20 LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System 5. Connect each of the labeled Main Harness wires to the appropriate wires in the junction box using the provided hardware, Waterproof Crimp Connectors (I) and #10 Ring Terminals (J).
-
Page 21: Statements
LaneGuard PRO LaneGuard PRO ™ ™ Dual Sensor Dual Sensor Blind Spot Detection System Blind Spot Detection System Statements FCC STATEMENT ISED STATEMENT This device complies with Part 15 of the FCC Rules. This device contains license-exempt transmitter(s) Operation is subject to the following two conditions: that comply with Innovation, science and economic development Canada’s license-exempt RSS(s). -
Page 22: Limited Warranty And Return Policy
Limited Warranty and Return Policy Air Lift Company provides a 2-Year Limited Warranty* to the original purchaser of the Towtal View LaneGuard (single sensor) system, from the date of original purchase, that the products will be free from defects in... - Page 24 For calls outside the U.S. or Canada, dial +1 (517) 322-2144. Air Lift Company • 2727 Snow Road • Lansing, MI 48917 or P.O. Box 80167 • Lansing, MI 48908-0167 Air Lift Company reserves the right to make changes and improvements to its products and publications at any time.
