SYSTEM
MODELS
4-Way Blow Ceiling-Suspended type
FXUQ18PAVJU
FXUQ24PAVJU
FXUQ30PAVJU
FXUQ36PAVJU
Read these instructions carefully before installation.
Keep this manual in a handy place for future reference.
This manual should be left with the equipment owner.
Lire soigneusement ces instructions avant l'installation.
Conserver ce manuel à portée de main pour référence ultérieure.
Ce manuel doit être donné au propriétaire de l'équipement.
Lea cuidadosamente estas instrucciones antes de instalar.
Guarde este manual en un lugar a mano para leer en caso de tener alguna duda.
Este manual debe permanecer con el propietario del equipo.
OPERATION MANUAL
Inverter Air Conditioners
English
Français
Español
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daikin FXUQ18PAVJU
Summary of Contents for Daikin FXUQ18PAVJU
- Page 1 OPERATION MANUAL SYSTEM Inverter Air Conditioners MODELS 4-Way Blow Ceiling-Suspended type FXUQ18PAVJU FXUQ24PAVJU English FXUQ30PAVJU FXUQ36PAVJU Français Read these instructions carefully before installation. Español Keep this manual in a handy place for future reference. This manual should be left with the equipment owner.
-
Page 2: Safety Considerations
Read these Safety Considerations for Operations carefully Improper repair and maintenance may result in water before installing air conditioning equipment. After complet- leakage, electric shock, and fire. Only use accessories ing the installation, make sure that the unit operates properly made by Daikin that are specifically designed for use during the startup operation. Instruct the customer on how to with the equipment and have them installed by a pro- operate and maintain the unit. fessional. - Page 3 • Do not wipe the controller operation panel with ben- CAUTION zene, thinner, chemical dust cloth, etc. The panel may • Do not use the air conditioner for any other purposes get discolored or the coating can peel off. If it is heavily other than comfort cooling or heating. Do not use the dirty, soak a cloth in water-diluted neutral detergent, unit for cooling precision instruments, food, plants, squeeze it well and wipe the panel clean. Then wipe it animals or works of art. with another dry cloth. • Do not place items under the indoor unit as they may • Dismantling of the unit, disposal of the refrigerant, oil, be damaged by condensates that may form if the hu- and additional parts, should be done in accordance midity is above 80% or if the drain outlet gets blocked. with the relevant local, state, and national regulations. • Before cleaning, stop the operation of the unit by turn- • Operate the air conditioner in a sufficiently ventilated ing the power off or by pulling the supply cord out from area and not surrounded by obstacles. Do not use the its receptacle. Otherwise, an electric shock and injury air conditioner in the following places. may result. a. Places with a mist of mineral oil, such as cutting oil. • Do not wash the air conditioner with excessive water. b. Locations such as coastal areas where there is a An electric shock or fire may result. lot of salt in the air. • Avoid placing the controller in a spot splashed with wa- c. Locations such as hot springs where there is a lot ter. Water entering the controller may cause an electric...
-
Page 4: Names And Functions Of Parts
CONTENTS 2. MAINTENANCE SAFETY CONSIDERATIONS ........[i] [ii] (FOR SERVICE PERSONNEL) 1. NAMES AND FUNCTIONS OF PARTS ......1 ONLY A QUALIFIED SERVICE PERSON IS 2. MAINTENANCE (FOR SERVICE PERSONNEL) ........1 ALLOWED TO PERFORM MAINTENANCE WARNING 1. NAMES AND FUNCTIONS OF PARTS • Do not use flammable gas (such as hair sprays and insecticides) near the air conditioner. • Do not wipe the air conditioner with benzine or thinner. It may cause cracks, electric shocks or a fire. • Never put your fingers or rods in the suction grille, air outlet or horizontal blade. The fan is rotating at high speed, so you would get injured. CAUTION • Do not wash the air conditioner with water. It may cause electric shocks or a fire due to leakage. -
Page 5: How To Clean The Suction Grille
1. Open the suction grille. 4. Attach the air filter. Simultaneously and slowly slide the two knobs down the Attach the air filter in the reverse order mentioned in the suction grille. step 2. 5. Close the suction grille. Simultaneously slide the two knobs, slowly lift the suction grille and securely fix it in the reverse order mentioned in the step 1. - Page 6 2. Remove the suction grille. 7. Close the suction grille. 1 Remove the 4 straps attached to the indoor unit. (Refer Simultaneously slide the two knobs in the reverse order to the figure shown below.) mentioned in the step 1, slowly lift the suction grille and 2 Open the suction grille to 45°...
- Page 7 The above operation is performed not only for installation, but every time the power circuit breaker is turned off/on. For comfortable use, do not turn off the power circuit breaker during seasonal use of the HEATING OPERATION. WHAT TO DO WHEN STOPPING THE AIR CONDITIONER FOR A LONG PERIOD Turn on FAN OPERATION for a half day on a nice day and dry the indoor unit.
- Page 8 Daikin Texas Technology Park, 19001 Kermier Road, Waller, TX, 77484, U.S.A. 3P338599-15J EM20A007 [2105] HT...
