- Page 1 Technical Manual Mainboard D1520 English...
- Page 2 ... any technical problems or other questions you need clarified? Please contact: your sales partner your sales outlet You will find further information in the manuals "Safety" and "Ergonomics". The latest information and updates (e. g. BIOS update) on our mainboards can be found on the Internet under: http://www.fujitsu-siemens.com/mainboards...
- Page 3 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright Fujitsu Siemens Computers GmbH 2002 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
- Page 4 Übersicht/Overview Mainboard D1520 1 = Stromversorgung / Power Interne Anschlüsse und Steckplätze / Internal Supply connectors and slots 2 = Diskettenlaufwerk / Floppy disk drive 3 = IDE-Laufwerke 3/4 / IDE-drives 4 = Bedienfeld / Front panel 5 = Schalter / Switch 6 = Steckbrücken / Jumper...
-
Page 5: Table Of Contents
Contents Mainboard D1520..........................1 Notational conventions ......................... 1 Important notes............................. 2 Information about boards ......................2 List of features ............................3 Special technical features – special features ................4 Brief instructions on installing mainboard ..................6 Prior to installation........................6 Interfaces and connectors ......................... -
Page 6: Mainboard D1520
Mainboard D1520 Your mainboard is available in different configuration levels. Depending on the configuration chosen, some of the hardware components described may not be available on your mainboard. Further information Information on the BIOS Setup and additional descriptions of the drivers are contained:... -
Page 7: Important Notes
Mainboard D1520 Important notes With the mainboard installed you must open the system to access the mainboard. How to dismantle and reassemble the system is described in the operating manual accompanying the system. Connecting cables for peripherals must be adequately shielded to avoid interference. -
Page 8: List Of Features
HI-SPEED USB 2.0 SmartCard Reader Support (USB / serial) - / - Temperature monitoring System Monitoring Fujitsu Siemens Computers Keyboard Power Button Support Internal ports DIMM Sockets (DDR 333 SDRAM, PC2700) AGP Slot (2/4x, 32 bit, 66 MHz, 1.5 V) PCI slot (32 bit, 33 MHz, 5 V and 3.3 V) -
Page 9: Special Technical Features - Special Features
Thermal Management and System Monitoring A microcontroller developed by Fujitsu Siemens Computers reliably protects your PC against damage caused by overheating. Overheating can lead to the data loss or processor damage. - Page 10 If an error occurs during a BIOS update (e.g. due to a power failure), the system BIOS will be destroyed. All Fujitsu Siemens Computers mainboards are equipped with a recovery BIOS. With it a destroyed BIOS can easily be restored. Exact instructions are provided in the chapter "BIOS Recovery –...
-
Page 11: Brief Instructions On Installing Mainboard
Equip the mainboard with the processor, heat sink and memory modules before installation if possible. Further information can be found in "Installing and removing processors" chapter. Ê Open the casing as described in the operating manual. 6 - English A26361-D1520-Z120-1-6319... -
Page 12: Driver Installation
Connect the plugs for the power supply, control panel and drives to the corresponding connections on the mainboard. Driver installation Ê Install the drivers for the chipset. You may find the driver on the "Drivers & Utilities" CD. Please refer to chapter "Drivers" for a description of installing drivers. English - 7 A26361-D1520-Z120-1-6319... -
Page 13: Interfaces And Connectors
The LAN RJ45 connector has two LEDs (light emitting diodes). 1 = a connection exists (e.g. to a hub). 2 = Link Mode: the LAN connection is active. WOL mode: a Magic Packet is being received. 8 - English A26361-D1520-Z120-1-6319... -
Page 14: Internal Ports And Connectors
An ultra ATA/66 or ultra ATA/100 hard disk must be connected with a cable especially designed for the ultra ATA/66 or ultra ATA/100 mode. Ê Connect the end of the cable marked with blue to the mainboard. English - 9 A26361-D1520-Z120-1-6319... -
Page 15: Pin Assignment Of Internal Ports
Indicates the system state APM or ACPI together with the Sleep LED (see chapter entitled "APM and ACPI system status, energy-saving modes"). Sleep LED Indicates the system state APM or ACPI together with the Power-On LED (see chapter entitled "APM and ACPI system status, energy-saving modes"). 10 - English A26361-D1520-Z120-1-6319... - Page 16 +12 V (P12VP) +5 V (VCC) Fan 1 (system fan - supervised) Signal Controlled Fan voltage (0 V, +6 V ... +12 V, max. 1 A) or fix Fan voltage (+12 V, max. 1 A) Fan sense English - 11 A26361-D1520-Z120-1-6319...
- Page 17 USB C/D / E/F - dual channel (internal or external via special wire) Signal Signal Chipcard reader on VCC C VCC D Data negative C Data negative D Data positive C Data positive D Not Connected Audio S/PDIF (3-pin) Signal SPDIF out 12 - English A26361-D1520-Z120-1-6319...
-
Page 18: Audio Front Panel
Right line output Right line return Left line output Left line return CD-ROM audio Signal Left CD audio input CD GND CD GND Right CD audio input Processor power supply power supply Signal Signal +12 V +12 V English - 13 A26361-D1520-Z120-1-6319... -
Page 19: Settings With Switches And Jumpers
The System BIOS executes from floppy drive A: and the inserted "Flash-BIOS- Diskette" restores the System BIOS on the mainboard. Normal operation (default setting). Reserved - switch 3 and switch 4 Switch 3 and 4 are reserved. 14 - English A26361-D1520-Z120-1-6319... -
Page 20: Add-On Modules / Upgrading
(A) with regard to the position (4). The angled corner of the processor can also be at a different location than shown in the illustration. Ê Push the lever back down until it clicks into place (5). English - 15 A26361-D1520-Z120-1-6319... -
Page 21: Mounting Heat Sink
Depending on the processor variant, clips may also be supplied for mounting the heat sink that fix it in place. Ê When you have mounted the optional fan, connect the fan plug to the corresponding connection on the mainboard. 16 - English A26361-D1520-Z120-1-6319... -
Page 22: Upgrading Main Memory
Push the holders on each side of the memory compartment outwards. Ê Insert the memory module into the location (1). Ê At the same time flip the lateral holders upwards until the memory module snaps in place (2). English - 17 A26361-D1520-Z120-1-6319... -
Page 23: Upgrading Agp Screen Controllers
PCI IRQ Lines connect AGP slots, PCI slots and onboard components to the interrupt controller. PCI IRQ Lines are permanently wired on the mainboard. Which ISA IRQs are assigned to the PCI IRQ Lines is normally automatically specified by the BIOS (see description in "BIOS Setup"). 18 - English A26361-D1520-Z120-1-6319... - Page 24 IRQ sharing, check whether the expansion card properly supports IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all cards and components on this PCI IRQ Line must also support IRQ sharing. English - 19 A26361-D1520-Z120-1-6319...
-
Page 25: Replacing Lithium Battery
Press the locking lug in the direction of the arrow; the battery jumps somewhat out of the holder (1). Ê Remove the battery (2). Ê Insert a new lithium battery of the same type into the socket (3). 20 - English A26361-D1520-Z120-1-6319... -
Page 26: Bios Update
Add-on modules / Upgrading BIOS update When should a BIOS update be carried out? Fujitsu Siemens Computers makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated. -
Page 27: Bios Recovery - Recovering System Bios
To guarantee the best possible performance and error-free operation, Intel recommends updating the microcode regularly. Intel refers to the use of the processor without regular microcode updates as operation outside the specifications. 22 - English A26361-D1520-Z120-1-6319... -
Page 28: Drivers
Add-on modules / Upgrading Safety for processor on Fujitsu Siemens Computers mainboards If the processor uses an old or incorrect microcode, error-free operation cannot be ensured. Fujitsu Siemens Computers has therefore implemented a function on its mainboards that interrupts the booting process if no suitable microcode is available for the installed processor. -
Page 29: Error Messages
Available CPUs do not support the same bus frequency – System halted! Memory type mixing detected Non Fujitsu Siemens Memory Module detected – Warranty void There are more than 32 32 RDRAM devices in the system Check whether the system configuration has changed. If necessary, correct the settings. - Page 30 Keyboard error Check that the keyboard is connected properly. Keyboard error nn nn Stuck Key Release the key on the keyboard (nn is the hexadecimal code for the key). English - 25 A26361-D1520-Z120-1-6319...
- Page 31 = Group number x = Number of SEs found on the communication bus y = Number of SEs entered in Number of connected SE k1, k2 ... = Device ID of the storage extensions found 26 - English A26361-D1520-Z120-1-6319...
-
Page 32: Dos Error Messages
Critical error logged to server management processor - system halted If the NMI button of the control panel is pressed, then the following error text is output on the screen: Frontpanel NMI activated - system halted English - 27 A26361-D1520-Z120-1-6319... -
Page 33: Smartcard Reader - Error Messages
You have exceeded the maximum number of failed attempts to enter the PIN. The Sicrypt SmartCard is blocked. Enter the administrator PIN to re-activate the Sicrypt SmartCard. You must then enter a new User PIN to restart the system. 28 - English A26361-D1520-Z120-1-6319... -
Page 34: Annex
Mainboard current requirement You require a Pentium4 power supply nit as per the ATX12V specification for this mainboard. If you do not have a PC from Fujitsu Siemens Computers, make sure that the power supply unit provides the required amperages. -
Page 35: Apm And Acpi System Status, Energy-Saving Modes
* G = Global status; S = System status The power supply unit must provide sufficiently loadable 5 V standby voltage. To use the WOL functionality the power supply must provide a 5 V auxiliary voltage (5VSB) of at least 1 A. 30 - English A26361-D1520-Z120-1-6319... -
Page 36: Mainboard Revision And Bios Version
The revision status of the mainboard exactly identifies which mainboard you have. It is indicated on a sticker on the edge of the mainboard: D1520-B10 GS 1 05618476 Example of revision status of the mainboard D1520-B10 GS1 BIOS version The BIOS version can be displayed in the BIOS Setup. Ê... -
Page 37: Using 4- Or 6-Channel Audio Function
Line Out, Line In and MIC functions all exist under 2- channel configuration. 4-Channel Analog Audio Output Line In (Rear channels) Line Out (Front channels) Description: Line In is converted to Line Out function under 4-channel configuration. 32 - English A26361-D1520-Z120-1-6319... -
Page 38: Selecting The Setting For 4 Or 6-Channel Mode
Select Adjust Audio Properties. On the Sounds and Audio Devices Properties tab displayed, you will find the function Speaker settings. Ê Under the Advanced Audio Properties function, you can set the appropriate speaker configuration in Speaker setup. English - 33 A26361-D1520-Z120-1-6319... -
Page 39: Setting The Microphone Connection
Select Volume Control - Options – Properties - Adjust volume for recording. Ê On the Recording tab, click on Advanced. Ê Under the function Other Controls, you can select the microphone connection by checking the 2 Front Mic box. 34 - English A26361-D1520-Z120-1-6319... -
Page 40: Glossary
Universal Serial Bus GMCH Graphics and Memory Controller Video Graphic Adapter Graphics Performance Wake On LAN Accelerator Inter Integrated Circuit IAPC Instantly Available Power Managed Desktop PC Design I/O Controller Hub Intelligent Drive Electronics IPSEC Internet Protocol Security English - 35 A26361-D1520-Z120-1-6319...
