Emphasi s Opti ons
Emphasis systems are created by choosing the server type, maximum channel count and
Facepanel type. Emphasis is offered as an upgrade to an existing Express or Expression-
style console (see below for compatible Facepanel types), or as a complete package.

Server Types

• 3D - Includes full console feature set and full visualization functionality: paperwork and
presentation tools, data tasks, 3D CAD drafting, complete visualization and rendering.
WYSIWYG Design stand-alone software is included. The 3D Server supports up to two
monitors.
• 2D - Includes full console feature set and limited visualization functionality: paperwork
and presentation tools, data tasks, and 2D CAD drafting. WYSIWYG Report stand-
alone software is included. The 2D Server supports one monitor.

Channel Counts

• 500 channels
• 1000 channels
• 2500 channels
• 5000 channels
Channel counts refer to the maximum number of control channels you can have in a show.
All channel options have 32,767 EDMX™ addresses available.

Facepanels

• Expression with Emphasis (Expression ECS), Expression 3, Expression 2x,
Expression LPC, Imagine™ 3
• Insight™ with Emphasis (Insight ECS), Insight 3, Insight 2x, Insight LPC, Focus™
• Express (all varieties), Express LPC
6 Emphasis Control System Quick Guide
