- Page 2 TABLE OF CONTENTS Safety Information ....................3 Package Contents ....................8 Preparation ......................8 Assembly Instructions ..................9 Operating Instructions ..................11 Care and Maintenance ..................12 Troubleshooting ....................13 Replacement Parts List ..................14...
- Page 3 I N T R O D U CTION hank you for purchasing this drill press. This machine has been designed for drilling large or small holes in metal, wood and plastic etc. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully.
- Page 4 ALWAYS ensure the workplace is well lit. Ensure that lighting is placed so that you will not be working in your own shadow. Do not use tools in the presence of flammable liquids or gasses. Stay alert, watch what you are doing, use common sense and do not operate the tool when you are tired.
-
Page 5: Additional Safety Rules For Drill Presses
ADDITIONAL SAFETY RULES FOR DRILL PRESSES CAUTION: AS WITH ALL MACHINERY, THERE ARE CERTAIN HAZARDS INVOLVED WITH THEIR OPERATION AND USE. EXERCISING RESPECT AND CAUTION WILL CONSIDERABLY LESSEN THE RISK OF PERSONAL INJURY. HOWEVER, IF NORMAL SAFETY PRECAUTIONS ARE OVERLOOKED, OR IGNORED, PERSONAL INJURY TO THE OPERATOR, OR DAMAGE TO PROPERTY MAY RESULT. - Page 6 P R O T E C T I V E C L O T H I N G Dress properly, loose clothing or other jewellery may get caught in moving parts. Non-slip footwear is recommended. ALWAYS wear safety glasses. (Everyday glasses are not safety glasses.) Wear a face mask if drilling into any material which produces dust.
-
Page 19: Troubleshooting
T R O U B L E S H OOT I N G PROBLEM PROBABLE CAUSE REMEDY Noisy a. Incorrect belt tension. a. Adjust tension. operation b. Dry spindle. b. Remove spindle and quill (under load). assembly and lubricate. c. Loose pulley. c.
