DEMO MANUAL SCP-LT3470A-BEVALZ
PARTS LIST
ITEM QTY REFERENCE
1 1 PCB
2 1 C1
3 1 C2
4 1 C3
5 1 C4
6 1 C6
7 1 INPUT
8 1 L1
9 1 OUTPUT
10 1 P1
11 1 R1
12 1 R2
13 2 R24, R25
14 1 R26
15 1 R3
16 4 R7, R9, R22,
R23
17 1 R8
18 1 U1
19 1 VIOC
Note 1. These items are not stuffed (DNI).
Note 2. Locations R4–R6, R10–R12, R19–R21 are shorted with 0Ω resistors for the Positive Buck option; R13–R15, R16–R18 are DNI.
4
PART DESCRIPTION
PCB
CAP ALUM 10UF 50V 20% RAD SMD
CAP CER X7R, GENERAL PURPOSE
CAP CER 0.22UF 50V 10% X5R 0402
CAP CER 22UF 10% 25V X5R 1206
CAP CER NP0
CONN-PCB MALE HEADER 3POS 2.54MM PITCH R/A GOLD
IND SHIELDED POWER, 0.5OHM DCR, 0.75A
CONN FEMALE 3POS 2.54MM PITCH R/A GOLD
CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY STRAIGHT 2MM
PITCH (Note 1)
RES PRECISION THICK FILM CHIP 100k 1% 1/8W 0805
RES THICK FILM 324k 1% 1/8W 0805
RES FILM SMD 0603 (Note 1)
RES FILM SMD 0-Ohm 5% 0.1W 0603
RES THICK FILM 0805 200k 1% 1/8W
RES STANDARD THICK FILM CHIP JUMPER 0805 (Note 1)
RES STANDARD THICK FILM CHIP JUMPER, FOR AUTOMOTIVE
IC MICROPWR BUCK REGULATOR
CONN FEMALE 2POS 2.54MM PITCH R/A GOLD
MANUFACTURER/PART NUMBER
ANALOG DEVICES 08_051162c
PANASONIC 50SVPF10M
YAGEO CC1206KKX7R9BB105
TAIYO YUDEN UMK105BJ224KV-F
SAMSUNG CL31A226KAHNNNE
YAGEO CC0402JRNPO9BN220
SULLINS PBC03SBAN
WURTH ELEKTRONIK 74408942330
SULLINS PPPC031LGBN-RC
MOLEX 53253-0370
PANASONIC ERJ-6ENF1003V
VISHAY CRCW0805324KFKEA
N/A
PANASONIC ERJ-3GEY0R00V
PANASONIC ERJ-6ENF2003V
N/A
VISHAY CRCW08050000Z0EA
LINEAR TECHNOLOGY LT3470AEDDB#PBF
SULLINS PPPC021LGBN-RC
