Lumens LC300 Quick Installation Manual

LC300 / LC300S Quick Installation Guide
1. Product connection
USB3.0
Audio Out
XLR Output XLR Input
Audio In
*12G-SDI is only applicable to LC300S
2. Real-time operation menu
 Connect the HDMI MultiView output to the display panel to show the real-
time operation menu
(the default output is director screen, click HOME return to the menu)
 Connect the keyboard/mouse through the USB port and use the
keyboard/mouse to select the menu settings
Items Name
1 System Settings Perform the system network setting, recording/streaming encoded setting
Director Input signal selection, audio source management, recording/streaming
2
Management control, output version selection, and network video camera control
File Conduct the video file content management, including the following functions:
3
Management upload, download, delete, replay video files
Display the current firmware version and relevant production information of
4 About
device
When connecting to the router, the current assigned device IP address will be
5 Device IP
displayed
3. Webpage management
3.1 Confirm the IP address of the device
Connect the WAN to the router and get the IP address of the device in the
HDMI MultiView output screen.
3.2 Input the device's IP address into a web browser to access the webpage
management login interface.
3.3 Enter the account/password to log in
4. Search and add video sources
4.1 System Settings (Configuration) > Video Source
Support HDMI/ SDI/ USB/ IP signal source settings
*12G-SDI is only applicable to LC300S
DEC. 2023
USB3.0
RS-232
RS-232 Input
12G-SDI* Video
Output
In/Loop-Through
Video Out
Video In
LAN Port USB Port
HDMI
Loop-Through
Audio In
Function Descriptions
Account: admin

Password: admin

Physical Video Source Manager
4.1.1
Click [Edit] to edit the HDMI signal source name and resolution
*LC300S supports 12G-SDI signal sources and can switch signal sources on the
Video Input1 edit page
Power Supply
USB Video Source
4.1.2
Click [+Add], select the USB signal source device and apply to add.
Audio Out
Network Source Manager
4.1.3
Support automatic search for network cameras within the local area
network or manually add RTSP/SRT streams
 Network Source
(1) Click [Refresh] to search for network cameras within the local
(2) Select Camera, click [Login]
(3)
(4)
 Network Stream
Click [Add], enter the streaming information, manually add RTSP/SRT
streams
4.2
Video Channel Manager
Click on [Edit]
4.2.1
The online video sources will be displayed in a list, please drag the
4.2.2
source to the desired channel
4.3
Go to the director's management page and set up the channel signal
source
Click [Video], select the channel video source
4.3.1
Click [] to preview the screen of each channel signal source
4.3.2
PVM: Click [] to output the preview screen
4.3.3
PGM: Click [] to output the director's screen
4.3.4
If you want to switch scenes, click [CUT] to switch to the director's
4.3.5
screen
2
1
www.MyLumens.com
area network
Enter username/account, click [Authentication]
Certification complete, status displayed as [OK]
1
2
4
5
3 4
3
