Summary of Contents for Lumens AI-Box1
- Page 1 AI-Box1 User Manual-English To download the latest versions of the Quick Start Guide, multilingual user manual, software, driver, etc., please visit Lumens https://www.MyLumens.com/support...
-
Page 2: Table Of Contents
Chapter4 Connect to a conference video software ......19 4.1 Set the output mode of AI-Box1 to UVC or HDMI+UVC, then click the Video output button 4.2 Launch a video software like Skype, Zoom, Microsoft Teams, or other similar software19 4.3 Choose the video source to output camera images .............. -
Page 3: Chapter 1 System Connection And Application
Chapter 1 System Connection and Application 1.1 System Connection 1.2 AI-Box1 IO Interface... -
Page 4: Chapter 2 Operation Interface
Display the devices according to the Device Numbers Select Microphone Device Devices Please check the supported devices from Products- CamConnect Pro in Lumens website. Device IP Enter the IP address of the microphone Display based on the connected devices Port... -
Page 5: B)Camera Control & Status
IP, and click [Add] to add it Refresh/ Add Please ensure that the camera and AI-Box1 are on the same network segment. Device Name Display the camera name in the same network segment. - Page 6 Click to enable PTZ control PTZ Control Refer to 2.2.1 PTZ Control for function description Enable/Disable AI Tracking Center Stage ：When the camera has been triggered to preset position, the individual will be centered on the screen for 5 seconds AI Setting before tracking stops.
-
Page 7: D)Device & Camera Mapping
Zoom Zoom In/ Zoom Out ratio Exit Exit the PTZ Control page 2.3 (D)Device & Camera Mapping After the microphone device is connected, the camera can be controlled to turn to the corresponding preset position according to the microphone detection position. Item Function Descriptions Select mapping quantity. -
Page 8: E)System Setting
Profile Setting cameras once. If the devices have a longer boot-up time, it may cause AI-Box1 failed to connect to the devices properly. To prevent this issue, please adjust the system waiting time based on the current environment and the boot-up time of the microphones and cameras. -
Page 9: F)Video Output Setting
Network Ethernet Setting. When it is set to Static IP, the setting can be modified. Once the settings are completed, click Apply. (F)Video Output Setting Item Function Descriptions Video Output Mode Set the Output Mode to either UVC, HDMI or UVC+HDMI Configure the layout of the video output according to the provided reference in section 2.5.1 Video Output Layout... -
Page 10: G)Start Video Output
2.5.1 Video Output Layout 1 camera in 2 cameras in 3 cameras in 4 cameras in connection connection connection connection Cross If there are three connected cameras, they will be displayed in a 4-grid layout, with one grid showing a black screen. Crop On Crop Off Crop... -
Page 11: H)Information
(H)Information Function Descriptions This window displays the software version information of AI-Box1. Click on to confirm the latest version and updates For technical support, please scan the QRcode on the right. -
Page 12: Chapter 3 Web Interface
Chapter 3 Web Interface 3.1 Device Setting Item Function Descriptions Array Microphone Number：Select the desired number of microphones to connect Devices: Select Microphone Device Device IP: Enter the IP address of the microphone Port: Display based on the connected devices ... - Page 13 Audio Trigger Level > dB： Triggered only if audio source exceeds the dB value. Sennheiser:-90~0 (recommended -55) Nureva:0~120 (recommended 40 up) Audio-Technica:0~60 (recommended 30) Yamaha:0~126 (recommended 80 up for RM-CG / 70 up for RM-W) ...
-
Page 14: Device - Camera List
Resolution/ FPS： Must match the camera's resolution settings Refresh : search the cameras in this network segment. Add：Manually type the IP address, then click AI-Box1 Please ensure that cameras and are under the same network segment。 Camera List ... -
Page 15: Video Output Setting
3.3 Video Output Setting Item Function Descriptions Video Output Mode HDMI,UVC or HDMI+UVC The system is set up for single screen output, and the screen switching is Seamless Switching triggered by the microphone signal. Start Video Output Click the button to start or stop video output. -
Page 16: System- Network
3.4 System- Network Function Descriptions Ethernet Setting. When it is set to Static IP, the setting can be modified. Once the settings are completed, click Apply. 3.5 System- Profile Item Function Descriptions External Profile Import and export the config file. Internal Profile Save and load the config file. - Page 17 3.6.1 System- Settings-Device Item Function Descriptions Language English Device Name CamConnect_Processor Location Default_XXXX(The last four characters of the MAC address) 3.6.2 System- Settings- Auto Connection...
- Page 18 Item Function Descriptions The microphone, camera and Video output can be reconnected Auto Connection automatically after restarting the AI Box. Auto Save The profile can be saved automatically after a specific interval time. 3.6.3 System- Settings- Web User Item Function Descriptions User Name Admin Current Password...
-
Page 19: About
The log file, which preserves the activity over a period, can be exported. Reboot Restarts the device. System Factory Resets the device to its factory default settings. 3.7 About Function Descriptions This window displays the version information of AI-Box1. For technical support, please scan the QR code at the bottom right... -
Page 20: Chapter4 Connect To A Conference Video Software
Chapter4 Connect to a conference video software Set the output mode of AI-Box1 to UVC or HDMI+UVC, then click the Video output button Launch a video software like Skype, Zoom, Microsoft Teams, or other similar software Choose the video source to output camera images... -
Page 21: Chatper5 Microphone Settings
Chatper5 Microphone Settings Please check the supported devices for the CamConnect Pro on the Lumens website. Below are examples. Compatibility is not limited to these Microphones. Before AI-Box1 installation, third-party microphone systems may require configuration in their software. Sennheiser When using TCC2 with CamConnect, please set and configure the channels on the Sennheiser Control Cockpit software first. -
Page 22: Chapter6 Troubleshooting
Chapter6 Troubleshooting This chapter describes problems you may encounter while using AI-Box1. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center. -
Page 23: Chapter7 System Message
IP address is on the same network as the AI Box. Microphone cannot be found, please check Microphone You can also refer to the link below from Lumens website for more connection status and try to information about the setup method with the compatible ceiling connect it again. -
Page 24: Copyright Information
Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
