  • Page 1 CamConnect AI-Box1 User Manual - English To download the latest Quick Start Guide, multilingual user manual, firmware, drivers, and control modules, please visit https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 System Connection ..............2 1.1 System Connection ..........................2 1.2 AI-Box1 IO Interface ........................... 2 Chapter 2 Operation Interface ............... 3 2.1 (A)Device Setting ..........................3 2.2 (B)Camera Control & Status ......................4 2.3 (D)Device & Camera Mapping ......................6 2.4 (E)System Settings ..........................

  • Page 3: Chapter 1 System Connection

    Chapter 1 System Connection 1.1 System Connection 1.2 AI-Box1 IO Interface...

  • Page 4: Chapter 2 Operation Interface

    Chapter 2 Operation Interface 2.1 (A)Device Setting Item Function Descriptions Device Number Select the desired number of microphones to connect Device List Displays microphones in individual tabs Select Microphone Device Devices Please use a supported microphone (see Lumens website)

  • Page 5: B)Camera Control & Status

    Device IP Enter the IP address of the microphone Displays the microphone’s port  Shure: 2202 Shure: 2202  Sennheiser: 45  Sennheiser TCCM: 443 Port  Nureva: 8931  Yamaha: 49280  Audio-Technica : 17300 Only Nureva allows customized PORT Enable/Disable setting mode Connect When enabled, signals received by a microphone triggers camera preset...

  • Page 6: Ptz Control

    Click to search for a camera on the network or manually enter the specified IP, and click [Add] to add it Refresh / Add Please ensure that the camera and AI-Box1 are on the same network segment. Device Name Displays discovered cameras Connect Click to connect.

  • Page 7: D)Device & Camera Mapping

    Zoom Lens Zoom In / Out Exit Exit the PTZ Control page 2.3 (D)Device & Camera Mapping When a microphone is connected, the camera will move to a preset position corresponding to the sound position detected by the microphone. Item Function Descriptions Select the number of locations to be mapped.

  • Page 8: E)System Settings

    (E)System Settings Item Function Descriptions Language English Max Microphone Qty. Connect up-to 24 microphones. Auto-connected items setting after AI-Box1 power is turned on.  Sound Device Auto Connection  Camera  Video Output  Save/ Load: Save or Load the desired profile. ...

  • Page 9: F)Video Output Settings

    Network Choose either DHCP or Static. The address can be modified in Static mode. Click Apply to save. (F)Video Output Settings Item Function Descriptions Video Output Mode Set the Output Mode to either UVC, HDMI or UVC+HDMI Configure the layout of the video output according to the provided reference in section 2.5.1 Video Output Layout ...
  • Page 10 2.5.1 Video Output Layout 2 connected 3 connected 4 connected 1 connected camera cameras cameras cameras Cross If there are three connected cameras, they will be displayed in a 4-grid layout, with one grid showing a black screen. Crop On Crop Off Crop...

  • Page 11: G)Start Video Output

    (G)Start Video Output Click to output camera images via HDMI or USB (H)Information Function Descriptions This window displays the software version information of AI-Box1. Click on to confirm the latest version and do apply updates. For technical support, please scan the QRcode on the right.

  • Page 12: Chapter 3 Web Interface

    Chapter 3 Web Interface 3.1 Device Settings Item Function Descriptions  Array Microphone Number：Select the desired number of microphones to connect  Devices: Select a Microphone  Device IP: Enter the IP address of the microphone  Displays the microphone’s port ...
  • Page 13  Audio Trigger Level > dB： Triggered when an audio source exceeds the specified dB value.  Sennheiser:-90~0 (recommended -55)  Nureva:0~120 (recommended 40+)  Audio-Technica:0~60 (recommended 30)  Yamaha:0~126 (recommended 80+ for RM-CG / 70 up for RM-W)  Time To Trigger Preset: Audio Reception Delay Settings When a second sound trigger occurs, there will be a delay in triggering camera preset based on the configured duration in seconds.

  • Page 14: Device - Camera List

    3.2 Device - Camera List 項目 功能說明 Resolution/ FPS： Must match the camera's resolution settings  Refresh : search the cameras in this network segment.  Add：Manually type the IP address, then click AI-Box1 Please ensure that cameras and are in the same network segment。...

  • Page 15: Video Output Settings

    3.3 Video Output Settings Item Function Descriptions Video Output Mode HDMI,UVC or HDMI+UVC The system is set up for single screen output, and the camera switching is Seamless Switching triggered by the microphone signal. Configure the layout of the video output according to the provided reference in section 2.5.1 Video Output Layout ...

  • Page 16: System- Network

    Start Video Output Click the button to start or stop video output. 3.4 System- Network Function Descriptions Ethernet Settings. When it is set to Static IP, settings can be modified. Once the settings are complete, click Apply. 3.5 System- Profile Item Function Descriptions Save as New Profile...

  • Page 17: System- Settings-Device

    3.6.1 System- Settings-Device Item Function Descriptions Language English Device Name CamConnect_Processor Location Default_XXXX (The last four characters of the MAC address) Max Microphone Qty. 4 / 8 / 16 / 24 3.6.2 System- Settings- Auto Connection...

  • Page 18: System Settings: Web User

    Item Function Descriptions The microphone, camera and Video output can reconnect automatically Auto Connection after restarting the AI Box. Auto Save The profile can be saved automatically after a specific interval time. 3.6.3 System Settings: Web User Item Function Descriptions User Name Admin Current Password...

  • Page 19: About

    Item Function Descriptions Firmware Version Displays the current firmware version of the device. Auto Check Automatically checks if new firmware is available. Firmware Update Allows you to select and update a firmware file from your computer. Event Log The log file records activity over time and can be exported. Reboot Restarts the device.

  • Page 20: Chapter 4 Connect To Video Conferencing Software

    Chapter 4 Connect to video conferencing software Set the output mode of AI-Box1 to UVC or HDMI+UVC, then click the Video output button Launch software (such as Skype, Zoom or Microsoft Teams) Select CamConnect as the video source  Video Source Name: Lumens CamConnect Processor...

  • Page 21: Chatper 5 Microphone Settings

    Chatper 5 Microphone Settings Please check the latest list of supported microphones on the Lumens website. Below are examples. Compatibility is not limited to these microphones. Before installing AI-Box1, third-party microphone systems may require configuration. Sennheiser When using TCC2 with CamConnect, set and configure the channels on the Sennheiser Control Cockpit software first.

  • Page 22: Chapter 6 Troubleshooting

    Unable to search camera devices 2. Make sure the cameras are on the same network as the CamConnect AI-Box1. 3. Replace the cables and make sure they are not faulty The microphone fails to detect the Please confirm that the microphone device is in Connected status position of a sound 1.

  • Page 23: Chapter7 System Message

    Chapter7 System Message Warning message Action Ensure that the microphone's port has been typed correctly and check if the IP address is on the same network as the AI-Box. Microphone cannot be found. Please check Microphone You can also refer to the link below from for more information about the connection status and try to setup method with compatible ceiling microphones.

  • Page 24: Copyright Information

    Lumens is a trademark registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not permitted unless a license has been provided by Lumens Digital Optics Inc. or unless copying this file is for the purpose of backup after purchasing this product.
