Lumens CaptureVision Station LC300 User Manual

Hide thumbs Also See for CaptureVision Station LC300:
Table of Contents

Advertisement

Quick Links

Download this manual
LC300_LC300S
CaptureVision Station
User Manual - English
Version LCB021
[Important]
To download the latest versions of the Quick Start
Guide, multilingual user manual, software, driver,
etc., please visit Lumens
https://www.MyLumens.com/support
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CaptureVision Station LC300 and is the answer not in the manual?

Questions and answers

Related Manuals for Lumens CaptureVision Station LC300

Summary of Contents for Lumens CaptureVision Station LC300

  • Page 1 LC300_LC300S CaptureVision Station User Manual - English Version LCB021 [Important] To download the latest versions of the Quick Start Guide, multilingual user manual, software, driver, etc., please visit Lumens https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    Table of Contents Copyright Information ..................3 Chapter 1 Safety Instructions ..............4 Chapter 2 Package Contents ............... 5 Chapter 3 Product Appearance and Connection ........6 3.1 Product Appearance ................6 3.2 Product Connection ................7 3.3 RS-232 I/O Pin Description .............. 7 Chapter 4 Function Description ..............

  • Page 3: Copyright Information

    Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.

  • Page 4: Chapter 1 Safety Instructions

    Chapter 1 Safety Instructions Always follow these safety instructions when setting up and using the product: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on a tilted or unstable trolley, stand or table. 1.3 Please clean the dust on the power plug prior to usage.

  • Page 5: Chapter 2 Package Contents

    Chapter 2 Package Contents Power Adapter 3-PIN to 2-PIN LC300/LC300S Power Cord (DC 19V) Connector Appearance may vary (For Japan only) depending on country/region USB 3.0 Cable (2M) RS-232 Mounting Metal Plate M3 Metal Plate Screw (Type B to Type A) Connector (x2) (x2) (4x4)

  • Page 6: Chapter 3 Product Appearance And Connection

    Reset the device (long press for 3 seconds to trigger it) Connect the computer to convert PGM audio and video into USB signal for use with video software USB3.0 Port  Video/Audio source name: Lumens LC300(S) Processor XLR Out Balanced line output Line In(1)

  • Page 7: Product Connection

    Connect to WAN Operation interface output; display the settings menu and image HDMI 1 Multi View management HDMI 2 Program Main screen output, display the recording or streaming screen and layout USB 2.0 Port Can connect keyboard/mouse/USB flash drive/USB camera/LC-RC01 remote control panel USB 3.0 Port Line In(2)

  • Page 8: Chapter 4 Function Description

    Chapter 4 Function Description 4.1 Real-Time Operation Menu Connect the HDMI Multi View output to the display panel to show the real-time operation menu Connect the keyboard/mouse through the USB port and use the keyboard/mouse to select the menu settings Icon Name Function Descriptions...

  • Page 9: Parameter Setting

    4.3 Parameter Setting This Section provides descriptions of the web-based interface to control the display items. HDMI Multi View only provides item settings of [System Settings] > [Internet]. 4.3.1 System Settings 4.3.1.1 System Settings You may set up the device’s basic information, initial date and time, and others here. Item Function Descriptions Defines the device name and device description...
  • Page 10 Live Streaming Preview real-time PGM screen Supports different time zone setting. It can synchronize time with NTP service (default) and manual setup  Time Zone: Select the correct time zone according to current location Date & Time  Configuration Mode: ...
  • Page 11 4.3.1.2 Network The factory setting is DHCP. If you want to use a static IP address, please configure the connection here. Function Descriptions  DHCP: Dynamic IP address as default  Static IP: Configure static IP address according to the network and manually enter network information Select and fill in required network setting information and click [Apply] to save the settings The system will restart after changing network setting.
  • Page 12 4.3.1.3 Services Item Function Descriptions Main firmware information and update Click [Update] and select the main firmware file to update Firmware Advance: Engineers update sub-firmware usage Saves system log files to user’s computer Enter file name Service Data Click [Export] to export system log files The length of file name must be between 0 ~ 16 characters.
  • Page 13 4.3.1.4 Configuration You can export the configuration files of the device to a computer, and import the configuration files to another device to apply the same configuration. Item Function Descriptions Export Export the current configuration of device as a configuration file Import Import the exported configuration files from another device 4.3.1.5 Display...
  • Page 14 4.3.2 Account You can manage accounts for 3 kinds of user mode here: modify the username and password to [System Management], [Online Director], and [Content Management]. Item Username/Password Function Descriptions Top authority. Set up the permission of main system Administrator admin / admin management Online...
  • Page 15 4.3.3 Source 4.3.3.1 Physical Video Source Manager Function Descriptions Click [Edit] to edit the HDMI signal source name and resolution  3G-SDI video, can switch signal sources on the Video Input 4 edit page  LC300S supports 12G-SDI signal sources and can switch signal sources on the Video Input 1 edit page 4.3.3.2 USB Video Source Function Descriptions Click [+Add], select the USB signal source device, apply it, and then add it...
  • Page 16 Click [Login Verification]/[Add] and enter login information to connect the camera Lumens Network Camera  CameraAccount: admin  Password: 9999 Once the status display “OK”, indicating that the image can be set under the signal source input selection Click [Add]...
  • Page 17 4.3.4 Audio Source Manager Function Descriptions Click [Refresh] to search for the USB audio source device connected to the device 4.3.5 Video Support flexible recording configurations, administrators can choose to record a single PGM (mixing video) screen or record 2 to 4 signal source screens, different videos can be set with different encoding settings 4.3.5.1 Encoder Manager...
  • Page 18 4.3.5.2 Record Manager Function Descriptions Click [Add] to configure the image/sound source and encoder  Support maximum recording time: 12 hours  Resolution settings will affect the split-screen supported by PGM. Please refer to the following limitations PGM Maximum Resolution Description Split-screen Quantity 4K 60fps...
  • Page 19 4.3.6 Scene 4.3.6.1 Scene Provides 5 overlay styles, background images, and scenes. You can also add your own styles. Item Function Descriptions Select and delete overlay style. You can upload files to apply. Click [ ] and select a desired file from the window. Check the preview image and file name, and click [Apply] to start uploading and applying this overlay style.
  • Page 20 4.3.6.2 Macro Supports 9 sets of macros, users can quickly switch themes, while the camera moves to the specified default position. With the use of the LC-RC01 extension control panel (optional), the [1~3] buttons on the panel can trigger macro [1~3] settings. Item Function Descriptions Select a scene to be set...
  • Page 21 4.3.7 Storage You can set up recording storage, cycle recording, and display hard drive information and NAS setting here. Item Function Descriptions Local storage: Click drop-down menu and select local storage hard Record Disk drive Settings Formats supported: FAT/ FAT32/ NTFS/ ext3/ ext4/ exFAT Display hard drive information, free space, and capacity.
  • Page 22 Importing calendar periodically You can synchronize schedules from network servers (e.g. Google Calendar)  Please refer to the videos of How to series on Lumens™ YouTube channel for related settings Enable/disable the scheduled standby and wake-up functions. Set the Stand by and Wake up...
  • Page 23 4.3.9 Backup Auto backup service, which can upload videos to a designated space automatically. You can set up upload destination and test the connection here. Item Function Descriptions Auto upload: Disable / Upload right after recording completes / Upload periodically ...
  • Page 24 4.3.10 About Display device-related Information: Firmware version, device serial number, and technical support link...

  • Page 25: Online Director

    4.4 Online Director LC300_LC300S is built in Online Director, which allows you to monitor recording and preview the output video from streaming director. Three login methods below are available:  Select Online Director from the HDMI Multi View real-time operation menu ...
  • Page 26 Online Director related feature description as below: Item Function Descriptions Video source screen output, display source screen preview Channel Switch the PVM screen to the PGM screen Displays current recording status, hard disk capacity and Internet Status connection status, etc. PVM/PGM Display preview (PVM) and actual output (PGM) screen Record...
  • Page 27 Pause Pause Recording Index Timestamp can be added after the recording starts Capture Capture a photo Single-channel Push Push right away without starting recording function Button 4.4.2 Video Function Descriptions Preview Channel 1 ~ 4 signal sources screen, click on the screen to select the output signal source ...
  • Page 28 4.4.3 Scenes Layout Setting Item Function Descriptions Scenes page is the integration of “Overlay,” “Background Image,” and “Production Layout,” which can perform a series of scene change Scenes according to your needs. Apply a different layout to highlight the screen focus of different Layout channels.

  • Page 29: File Management

    4.5 File Management Perform the following functions via the file management interface: Upload, download, delete, replay video files and edit recording information. 4.5.1 Multi View Output Interface Item Function Descriptions Preview Click desired video files to play and control on the Preview screen Program Display the Director screen or switch to synchronize with the Preview screen Switch the Program screen to the LIVE Director screen or the Preview...
  • Page 30 4.5.2 Webpage Interface The default page after accessing web page is system setting page. Click the video management icon on the top-right corner to access video management page.  Video management Item Function Descriptions Video Click to access the video management page Management Photo Click to access the picture management page...
  • Page 31  File Management Description  Uploading Check the thumbnails of the videos to upload. Click [ ] and the videos will be uploaded to the location set in Upload Settings. Please refer to [System Management/Upload Settings] for related settings. Upload Status Description: Icon Upload Status Icon...
  • Page 32  Photo Management You can manage the photo files captured by pressing SNAPSHOT. Folders will be named with the shooting date automatically; all photos shot in the same date will be stored in the same folder. Just like Video Management, you can also upload, download, and delete photos in Photo Management subpage.

  • Page 33: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting This chapter describes problems you may encounter while using LC300_LC300S. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center. Problems Solutions Please confirm that the power cord used is of DC 19V...

  • Page 34: Addendum 1

    Addendum 1  Frequently used port No. Port No. Description Applicable for RTMP push to most platforms, such as YouTube, 1935/TCP Vimeo, and Twitch 80/TCP Applicable for RTMP push to Periscope 443/TCP Applicable for RTMPS push to Facebook 1935/TCP Applicable for RTMP push to LinkedIn 1936/TCP 2935/TCP Applicable for RTMPS push to LinkedIn...
