Page 1 of 6
SS0056
FITTING INSTRUCTIONS FOR SS0056 SWINGARM PROTECTORS
TO FIT ZERO FX & DSR 2019-
Picture A
Picture B
This Kit contains the items pictured and labelled over page.
Some parts may be shown for clarity of instructions only.
Do not proceed until you are sure all parts are present.
Please read all instructions before proceeding.
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS
OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
Please note that the way the kit is packed does not necessarily represent the way of
mounting to the bike.
In the event of rubber washers being used to hold components onto bolts,
these rubber washers can be thrown away.
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM
www.rg-racing.com
R&G
Unit
, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
1
Tel: +44 (0)
420 89007 Fax: +44 (0)
420 87301
www.rg-racing.com
Email:
info@rg-racing.com
1
1
Advertisement
Table of Contents
Related Manuals for R&G SS0056
Summary of Contents for R&G SS0056
- Page 1 Page 1 of 6 SS0056 FITTING INSTRUCTIONS FOR SS0056 SWINGARM PROTECTORS TO FIT ZERO FX & DSR 2019- Picture A Picture B This Kit contains the items pictured and labelled over page. Some parts may be shown for clarity of instructions only.
- Page 2 Page 2 of 6 SS0056 TOOLS REQUIRED GENERAL TORQUE SETTINGS M4 BOLT = 8Nm • Socket Set to Include 2 x 10mm sockets and wrenches. M5 BOLT = M6 BOLT = M8 BOLT = 20Nm 0 BOLT = 40Nm M12 BOLT = 40Nm LEGEND ITEM No.
-
Page 3: Fitting Instructions
Page 3 of 6 SS0056 FITTING INSTRUCTIONS • Fit one M6 nut (item 5) and one M6 washer (item 6) onto one end of the spindle bar (item3) engaging the nut so the plastic insert of the nut is fully engaged and the bar protrudes by 1 or 2 threads. - Page 4 Page 4 of 6 SS0056 NOTICE DE MONTAGE POUR SS0056 PROTECTIONS BRAS OSCILLANT POUR ZERO FX & DSR 2019- Photo A Photo B E KIT CONTIENT LES ARTICLES ILLUSTRES ET ETIQUETES SUR LA PAGE ERTAINES PARTIES PEUVENT ETRE PRESENTES UNIQUEMENT POUR LA CLARTE DES INSTRUCTIONS...
-
Page 5: Outils Requis
Page 5 of 6 SS0056 OUTILS REQUIS VALEURS DE SERRAGE M4 BOULON = 8Nm • Clés à cliquet + douilles 2 x 10mm. M5 BOULON = M6 BOULON = M8 BOULON = 20Nm 0 BOULON = 40Nm M12 BOULON = 40Nm LÉGÉNDE... -
Page 6: Notice De Montage
Page 6 of 6 SS0056 NOTICE DE MONTAGE • Montez un écrou M6 (article 5) et une rondelle M6 (article 6) sur une extrémité de l’axe (article3) en engageant l'écrou de sorte que l'insert en plastique de l'écrou soit complètement engagé et que la l’axe dépasse de 1 ou 2 filets.
