Page 1
SRG0080 PAGE 1 OF 12 FITTING INSTRUCTIONS FOR SRG0080 STAINLESS RADIATOR GUARD YAMAHA YZF-R1M 2020- Picture A HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT...
Page 4
PAGE 4 OF 12 SRG0080 Picture 7 Picture 8 Picture 9 R&G Racing Unit 1, Shelleys Lane, East Worldham, Alton, Hampshire GU34 3AQ. Tel: +44 (0)1420 89007 Fax +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
Page 5
SRG0080 PAGE 5 OF 12 FITTING INSTRUCTIONS • To fit the radiator guard to the bike cut the foam strip provided into 10mm wide pieces and stick them to the back of the radiator guard frame, so that they sit between the radiator guard and the radiator.
Page 6
PAGE 6 OF 12 SRG0080 CONSUMER NOTICE The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design changes which do not diminish their performance or visual appeal and supplying them in such state shall conform to the order.
Page 7
SRG0080 PAGE 7 OF 12 NOTICE DE MONTAGE SRG0080 PROTECTION RADIATEUR YAMAHA YZF-R1M 2020- Photo A E KIT CONTIENT LES ARTICLES EN PHOTO ET ETIQUETTES SUR LA PAGE LES PARTIES PRESENTÉES PEUVENT ETRE UNIQUEMENT REPRESENTATIVES POUR LA CLARTE DES INSTRUCTIONS E PAS ROCÉDER AU MONTAGE AVANT DE VOUS ÊTRES ASSURE QUE TOUTES LES PIECES SOIENT PRÉSENTES...
Page 9
SRG0080 PAGE 9 OF 12 NOTICE DE MONTAGE • Pour installer la protection radiateur sur la moto, coupez la bande de mousse fournie en morceaux de 10 mm de large et collez-les à l'arrière du cadre de la protection de radiateur, de sorte qu'ils se trouvent entre la protection radiateur et le radiateur.
Page 10
PAGE 10 OF 12 SRG0080 MONTAGEANLEITUNG FÜR SRG0080 EDELSTAHL KÜHLERSCHUTZ YAMAHA YZF-R1M 2020- Abbildung A ALLE KIT-TEILE SIND UNTEN ABGEBILDET UND GEKENNZEICHNET. DIE ABGEBILDETEN TEILE DIENEN LEDIGLICH ZUR ERKLÄRUNG. ÜBERPRÜFEN SIE ZUERST, DASS ALLE TEILE VORHANDEN SIND. LESEN SIE DIE MONTAGEANLEITUNG KOMPLETT DURCH, BEVOR SIE ANFANGEN WENN SIE BEI DER MONTAGE DIESES PRODUKTES UNSICHER SIND , BITTE EINEN UNSERER HÄNDLER KONTAKTIEREN ODER DAS KIT VON EINEM QUALIFIZIERTEN...
Page 12
PAGE 12 OF 12 SRG0080 MONTAGEANLEITUNG • Um den Kühlerschutz am Motorrad zu montieren, schneiden Sie zuerst die mitgelieferten Schaumstoffstreifen in 10 mm breite Streifen und kleben Sie diese auf der Rückseite des Kühlerschutzrahmens, so dass sie zwischen dem Kühlerschutz und dem Kühler angebracht sind.
