R&G SP0058BK Fitting Instructions Manual

Swing-arm protectors honda cbr1000rr sp fireblade 2014-
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

FITTING INSTRUCTIONS FOR SP0058BK SWING-ARM PROTECTORS
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.
Please note that the way the kit is packed does not necessarily represent the way of
T
HE PARTS SHOWN MAY BE REPRESENTATIVE ONLY
CRASH PROTECTOR (B0457) (x1)
WASHER (x1)
M6x60mm LONG BUTTON
HEAD BOLT (x1)
HONDA CBR1000RR SP FIREBLADE 2014-
Unit 1, Shelleys Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: +44 (0) 1420 89007 | Fax : +44 (0) 1420 87301 | Email: info@rg-racing.com
mounting to the bike
(
FOR CLARITY OF INSTRUCTIONS ONLY
LEFT HAND SIDE
R&G Racing
)
MOUNTING BLOCK (M0390) (x1)
SPECIAL
NUT
(H0015) (x1)
