SS0059
Fitting Instructions FOR SS0059 SPINDLE SLIDERS
TO FIT BMW F900R/F900XR 2020
Picture A
Picture B
This Kit contains the items pictured and labelled over page.
Some parts may be shown for clarity of instructions only.
Do not proceed until you are sure all parts are present.
Please read all instructions before proceeding.
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS
OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
Please note that the way the kit is packed does not necessarily represent the way of
mounting to the bike.
In the event of rubber washers being used to hold components onto bolts,
these rubber washers can be thrown away.
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM
www.rg-racing.com
R&G
Unit
, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
1
Tel: +44 (0)
420 89007 Fax: +44 (0)
420 87301
www.rg-racing.com
Email:
info@rg-racing.com
1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for R&G SS0059
Summary of Contents for R&G SS0059
- Page 1 Page 1 of 6 SS0059 FITTING INSTRUCTIONS FOR SS0059 SPINDLE SLIDERS TO FIT BMW F900R/F900XR 2020 Picture A Picture B This Kit contains the items pictured and labelled over page. Some parts may be shown for clarity of instructions only.
- Page 2 Page 2 of 6 SS0059 TOOLS REQUIRED GENERAL TORQUE SETTINGS M4 BOLT = 8Nm Socket Set to Include 2 x 10mm • M5 BOLT = 12Nm sockets and wrenches. M6 BOLT = 15Nm • Small amount of superglue or M8 BOLT = 20Nm Loctite.
- Page 3 Page 3 of 6 SS0059 FITTING INSTRUCTIONS • Fit one M6 nut (item 5) and one M6 washer (item 6) to the end of the spindle bar (item 3), engaging the nut so the plastic insert of the nut is fully engaged and the bar protrudes by 1 or 2 threads. It is recommended to use a small amount of superglue or Loctite to fix this nut as this will aid when tightening the opposite side later.
- Page 4 Page 4 of 6 SS0059 NOTICE DE MONTAGE POUR SS0059 BRAS OSCILLANT POUR BMW F900R/F900XR 2020 Photo A Photo B E KIT CONTIENT LES ARTICLES ILLUSTRES ET ETIQUETES SUR LA PAGE ERTAINES PARTIES PEUVENT ETRE PRESENTES UNIQUEMENT POUR LA CLARTE DES INSTRUCTIONS...
- Page 5 Page 5 of 6 SS0059 OUTILS REQUIS VALEURS DE SERRAGE Clés à cliquet + douilles 2 x 10mm. M4 BOULON = 8Nm • • Un peu de superglue ou Loctite. M5 BOULON = M6 BOULON = M8 BOULON = 20Nm...
- Page 6 Page 6 of 6 SS0059 ÔTÉ DROIT NOTICE DE MONTAGE • Montez un écrou M6 (article 5) et une rondelle M6 (article 6) sur une extrémité de l’axe (article 3) en engageant l'écrou de sorte que l'insert en plastique de l'écrou soit complètement engagé et que la l’axe dépasse de 1 ou 2 filets.
