SERVICE PARTS
98827T-4E2
Single Handle Lavatory Faucet
99448T-4E2
Single Handle Tall Lavatory Faucet
1226316**
1209778**
1209777
1226072
1292054
1281236
1360095
1360096
836549
**Color code must be specified when ordering
1256320-2A-D
KUMIN
833438
3008523
99448T-4E2:880096
98827T-4E2:1024405
1281236
880008**
1080817
880406
1121328**
880037
4
INSTALLATION INSTRUCTIONS
98827T-4E2
Single Handle Lavatory Faucet
99448T-4E2
Single Handle Tall Lavatory Faucet
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. If possible, install this faucet before installing the lavatory.
3. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
4. Observe local plumbing codes.
5. Shut off the water supplies to the fitting.
HANDLE OPERATION
Lift handle gently. Turn clockwise for hot water, turn counter-clockwise for cold water.
ROUGH-IN DIMENSIONS
20°
121
Ø32~Ø36
G1/2˝
99448T-4E2
1256320-2A-D
KUMIN
18°
101
Ø32~Ø36
Ø54
Ø36.5
G1/2˝
98827T-4E2
Ø31.75
1
