Kohler Nectar 98200A-CP Installation Instructions

Shower tapware, slide shower

INSTALLATION INSTRUCTIONS

BEFORE YOU BEGIN

All information is based on the latest product information available at the time of publication. Kohler Co.

reserves the right to make changes in product characteristics, packaging, or availability at any time

without notice.

Please leave these instructions for the consumer. They contain important information.

NOTES:

1.) Flush the water supply pipes thoroughly to remove debris.

2.) An in line water filter must be used with this product.

3.) The highest working pressure for the hand shower is 0.5Mpa(5 bars). If it exceeds 0.5Mpa(5 bars) a

pressure reducer is needed. The highest water and environment temperature is 60 C. Please keep the

hand shower away from any heater or it may become damaged and cause injury to the user.

4.) Don't remove the flow controller or the hand shower will be damaged.

50.4

1201504-AN2-A

16/09/2013

SHOWER TAPWARE

NECTAR

Slide Shower

Nectar Slide Shower: 98200A-CP

Ø93

G1/2"

Table of Contents

Do you have a question about the Nectar 98200A-CP and is the answer not in the manual?

Page 1 Nectar Slide Shower: 98200A-CP BEFORE YOU BEGIN All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice.
Page 2 Many cleaners may contain such chemicals as ammonia, chlorine, toilet chemicals etc. which could adversely affect the finish and are not recommended for cleaning. 1190006** Cover Do not use abrasive cleaners or solvents on Kohler fittings. 1190001** Bracket Cover 1061576...
