SERVICE PARTS
99856T-4
Single Handle Lavatory Faucet
99858T-4
Single Handle Tall Lavatory Faucet
1258102
1258105
1032559
3008523
3013706
1228836
1258089
**Color code must be specified when ordering.
1241098-2A-C
BEITOU
1223585**
1223586
1228831**
1223587**
1231860
1223593
1223584
1223368
1080817
1123942
1234008
870654
1228834
833730
1102890**
1102892
99856T-4: 834754
1142103**
99858T-4: 880096
INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
1258090
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
1258091
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. If possible, install this faucet before installing the lavatory.
3. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
4. Observe local plumbing codes.
5. Shut off the water supplies to the fitting.
HANDLE OPERATION
Lift handle gently. Turn clockwise for cold water, turn counter-colckwise for hot water.
ROUGH-IN DIMENSIONS
105
1102891
4
1241098-2A-C
99856T-4
Single Handle Lavatory Faucet
99858T-4
Single Handle Tall Lavatory Faucet
Min.30
117.5
46
Ø33~Ø38
144
G1/2˝
BEITOU
Ø69
Ø60
Ø41.2
Ø31.75
99858T-4
