SERVICE PARTS
99460T-4
R99460T-4
99463T-4
1219595**
864104**
1213567
3016381
1181007**
1030624
1216770**
831727**
**Color code must be specified when ordering.
NOTE: For all Asia pacific regions (excluding China) add SP (SPxxxxxxx**) in front of the part number when ordering.
1223737-2A-E
KUMIN
Wall Mount Bath Shower Faucet
Wall Mount Shower Faucet
1226316**
3013706
3008523
1209778**
1209777
1292054
99460T:1223034**
99460T:1223033**
99460T:3020067
99463T:3016381
99460T:1223039
99463T:1213561
INSTALLATION INSTRUCTIONS
99460T-4
99463T-4
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
3. Observe local plumbing codes.
4. The minimum inlet water pressure for the diverter is 0.05MPa(0.5bar).
5. The highest working pressure for handspray is 0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a pressure reducer is
needed. The highest water and environment temperature is 60°C. Please keep handspray, showerhead and the
shower arm away from heater, or it may become damaged and cause injury to the user.
HANDLE OPERATION
Lift handle gently. Turn clockwise for hot water, turn counter-colckwise for cold water.
from spout when faucet diverter is in the normal position; lift the diverter gently, turn clockwise for handspray; shut
off the faucet, turn counter-clockwise until it stops.
STANDARD APPLICABLE
Special model meets or exceeds the following at date of manufacture: TIS
ROUGH-IN DIMENSIONS
128
99460T-4
4
1223737-2A-E
R99460T-4
Wall Mount Bath Shower Faucet
Wall Mount Shower Faucet
130
18º
G1/2˝
G1/2˝
56
171
188
99463T-4
KUMIN
For 99460T, Water flows out
87
G1/2˝
G1/2˝
G1/2˝
49
60
1
