Fusion bagless cylinder vacuum cleaners
Please read and keep these instructions
getting the best from your
new cleaner...
If your cleaner is not picking up as well as it should,
please check
• Filters
It is important that the airbox and filters are cleaned regularly to allow
air through the appliance. Tap to remove dust, the filter can also be
washed in warm water and left to air dry.
IMPORTANT - Ensure filter is totally dry before refitting into machine.
A spare pleated filter is provided, this allows one to be washed
and dried whilst the other is in use.
If you find that washing the filter is a problem we can help. Call our
dedicated helpline on 0870 060 2604 for further details.
• Blockages
Check the hose, handle and tools for blockages.
• Overheating protection
The cleaner automatically cuts off in the event of overheating caused
by blocked hoses / filters. Remove plug, clear blockage and allow 15
minutes for the cleaner to automatically reset.
www.morphyrichards.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IB70045 and is the answer not in the manual?

Questions and answers

Summary of Contents for Morphy Richards IB70045

  • Page 1 Fusion bagless cylinder vacuum cleaners Please read and keep these instructions getting the best from your new cleaner... If your cleaner is not picking up as well as it should, please check • Filters It is important that the airbox and filters are cleaned regularly to allow air through the appliance.
  • Page 2: Important Safety Instructions

    Unprofessional repairs can be socket outlet. dangerous for users. • Use only genuine Morphy Richards Should the fuse in the 13 amp plug spare parts and accessories. require changing a 13 amp BS1362 fuse...
  • Page 3 ‰ Tube park (on underside of cleaner) Features  Tube standby slot ⁄ Dust compartment cover Accessories you should have ¤ Inlet for suction hose 13 and 14 come assembled as one piece ‹ Dust compartment release button Ê Suction hose with 360˚swivel connector ›...
  • Page 4: Operation

    Assembly Push the elbow-shaped end of the suction hose into the housing until it clicks into place. Telescopic tube È Attach the tube to the handle. To adjust the length, press the release button as indicated and pull or push the tube to the È...
  • Page 5: Controlling Suction Power

    Controlling suction power The suction power can be varied to suit the surface being cleaned, by using the electronic suction power regulator. See table for guideline settings. Overheating protection Power setting Application In the event of a motor overload, your vacuum cleaner will switch off automatically.
  • Page 6: Tube Standby

    Accessories The accessories are stored in the tool compartment as shown. The accessories can be attached to the end of the tube or to the handle. • Upholstery tool Í for curtains and Í sofas/armchairs. • Crevice tool Î for small gaps - various Î...
  • Page 7 Emptying the air box To maintain the performance of your vacuum cleaner the airbox must be emptied regularly and the filters cleaned. The suction gauge indicates the air flow through the cleaner. If in use, the suction gauge is continuously in the red, the airbox must be emptied and the filters cleaned.
  • Page 8 Cleaning the airbox filter IT IS IMPORTANT TO CLEAN THE FILTER TO MAINTAIN PERFORMANCE, EVERY TIME THE AIRBOX IS EMPTIED. • After emptying the dust, twist the filter assembly anti-clockwise to remove as shown. • Slide off the outer mesh filter. •...
  • Page 9: Cleaning The Motor Protection Filter

    Cleaning the motor protection filter The motor protection filter is accessible from the dust compartment only when the airbox has been removed first. WARNING: NEVER USE THE APPLIANCE WITHOUT THE MOTOR PROTECTION FILTER INSTALLED, OTHERWISE DAMAGE TO THE MOTOR MAY OCCUR WHICH WOULD NOT BE COVERED BY THE GUARANTEE.
  • Page 10: Cleaning The Exhaust Air Filter

    Cleaning the exhaust air filter The exhaust air filter cleans the air before it exits the vacuum cleaner. Recommendation The exhaust air filter should be cleaned when you have emptied the airbox 5 times. How to clean the exhaust air filter 1 Push the lock and remove the cover in an upward direction.
  • Page 11: Cleaning And Maintenance

    Cleaning and maintenance Unplug from the mains before cleaning. The dust compartment and all accessories can be cleaned using a damp cloth or a non- abrasive domestic cleaner and wiped dry. To keep the underside of the floor nozzle clean, vacuum it at regular intervals using the crevice tool.
  • Page 12 Helpline number quoting products. Model number and Serial number on the 3 Repairs have been attempted by persons product, or write to Morphy Richards at the other than our service staff (or authorised address shown. You will be asked to return dealer).
