70047 Rev 1
4/3/05
11:46 AM
Page 1
Allergy cylinder vacuum cleaner
Please read and keep these instructions
getting the best from
your new cleaner...
If your cleaner isn't picking up as well as
it should, please check
• Dustbags
It is important to replace them, otherwise the performance
of the cleaner will be impaired
• Filters
It is important that the filters are cleaned regularly or
replaced to allow air through the appliance
• Blockages
Check the nozzle, tubes and hose for blockages
www.morphyrichards.com
Advertisement
Table of Contents
Related Manuals for Morphy Richards Allergy cylinder vacuum cleaner
Summary of Contents for Morphy Richards Allergy cylinder vacuum cleaner
- Page 1 70047 Rev 1 4/3/05 11:46 AM Allergy cylinder vacuum cleaner getting the best from your new cleaner... If your cleaner isn’t picking up as well as it should, please check • Dustbags It is important to replace them, otherwise the performance of the cleaner will be impaired •...
-
Page 2: Important Safety Instructions
• Repairs to electrical appliances are only to be undertaken by trained personnel. Unprofessional repairs can be dangerous for users. • Use only genuine Morphy Richards spare parts and accessories. • The appliance must never be left running when unsupervised. - Page 3 70047 Rev 1 4/3/05 11:46 AM Features ⁄ Dust compartment cover ¤ Opening for suction hose ‹ Dust compartment lock button › Tool storage compartment cover fi Motor protection filter (not shown) fl Dustbag safety lock (not shown) ‡ Slot for attaching dustbag holder (not shown) ·...
-
Page 4: Tool Storage
Suction hose Snap the 360° rotating head on the suction hose into the suction hose opening on the vacuum cleaner. The appropriate cleaning tool can be attached directly to the other end of the suction hose or the connecting tube can be used between the suction hose and the tool. -
Page 5: Controlling Suction Power
The vacuum cleaner cuts out automatically when: • The floor nozzle or tubes become blocked • Using the vacuum cleaner with a full dustbag • The motor protection filter is very dirty • The exhaust filter is very dirty. Check and rectify before attempting to reuse your vacuum cleaner. -
Page 6: Tube Standby
Storage Tube park The vacuum cleaner can be stored in an upright position. Rotate the floor nozzle until the lug on the back of it can be fitted into the tube park slot on the base of the appliance. -
Page 7: Changing The Dust Bag
70047 Rev 1 4/3/05 11:46 AM Changing the dustbag If suction power is reduced or if the ‘dust bag full’ indicator is permanently on, the dust bag needs changing. Also check whether the suction hose, tube or nozzle are blocked. To access the dust bag, press the dust compartment release button to open the cover. -
Page 8: Changing The Motor Protection Filter
70047 Rev 1 4/3/05 11:46 AM Changing the motor protection filter IMPORTANT: Never use the appliance without the motor protection filter installed, otherwise damage to the motor may occur which would not be covered by the guarantee. Allergy models with 3-layer hygiene filter cassette 1 Pull out the filter cassette in an upward direction and clean by tapping gently or... -
Page 9: Cleaning And Maintenance
To keep the underside of the floor nozzle clean, vacuum it at regular intervals using the crevice tool. Purchasing replacement filters Use only Morphy Richards replacement filters which can be purchased from specialist retailers or by calling the number on the front page of this leaflet. Helpline If you have any difficulty with your appliance, do not hesitate to call us. - Page 10 70047 Rev 1 4/3/05 11:46 AM PremAir Allergy cylinder vacuum cleaners The British Allergy Foundation considers that these products may, in proper use, reduce exposure to both House Dust Mite (Der p 1) and Cat Allergen (Fel d 1). Assessment carried out by BAF indicate that an individuals exposure can be reduced but this does not mean that an individuals allergic symptoms will necessarily diminish.
- Page 11 4 Where the appliance has been used for hire purposes or non-domestic use. 5 The guarantee excludes consumables such as bags and filters. 6 Morphy Richards are not liable to carry out any type of servicing work, under the guarantee. This guarantee does not confer any rights...
- Page 12 4/3/05 11:46 AM Morphy Richards products are intended for household use only Morphy Richards has a policy of continuous improvement in product quality and design. The Company, therefore, reserves the right to change the specification of its models at any time.
