70530 Rev 4
2/6/04
2:53 PM
Page 1
Steam cleaner
Please read and keep these instructions
getting the best from your
new steam cleaner...
• Quick start
1 Fill the tank up to a maximum of 1.4 litres of water (using warm
water and less water will reduce heat-up time). Screw cap on
and tighten fully.
2 Attach the required accessories.
3 Connect to the power supply.
4 Press the on/off button to start heat-up. When orange light turns
off, the steam is ready.
5 Press the trigger on the handle to release the steam.
6 Aim the steam safely: Note at the start water may be ejected.
Hold over a sink or bucket until excess water has cleared.
• Descale
Descale regularly, do not wait for a problem to occur. In very hard
water areas we recommend using distilled water. See page 10 for
descaling instructions.
with attachments
www.morphyrichards.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Steam cleaner and is the answer not in the manual?

Questions and answers

Related Manuals for Morphy Richards Steam cleaner

Summary of Contents for Morphy Richards Steam cleaner

  • Page 1 2/6/04 2:53 PM Steam cleaner getting the best from your new steam cleaner... • Quick start 1 Fill the tank up to a maximum of 1.4 litres of water (using warm 2 Attach the required accessories. 3 Connect to the power supply.

  • Page 2: Important Safety Instructions

    • The appliance must never be left running when unsupervised. • This steam cleaner is intended for domestic use only. Misuse or use for commercial or any other purpose will render the guarantee invalid.
  • Page 3 70530 Rev 4 2/6/04 2:53 PM Illustration ¤ „ ‰ ‹ ‡ È Ë Ï Î Ú Features ⁄ Filler cap ¤ On/off switch ‹ Tool storage cover › Wheel fi Tube park (see page 9) fl Carrying handle ‡ Hose ·...

  • Page 4: Accessory Assembly

    70530 Rev 4 2/6/04 2:53 PM Page 4 Accessory assembly · Ù Í È Ì È Ú Ë Ï Î Please refer to the assembly sequence to assemble your steam cleaner.

  • Page 5: Operation

    70530 Rev 4 2/6/04 2:53 PM Operation Please remember that the steam cleaner operates by emitting steam at an increased temperature of 130˚C. Never use it on objects or surfaces which cannot resist this temperature, delicate materials, dralon, plastic, natural fur etc. Where any doubt exists check carefully on a part of the material where minor marks will not matter.

  • Page 6: On/Off Switch

    2 When the correct temperature has been reached the steam ready light (orange) will go out. The steam cleaner is now ready to use. Note: The steam ready light will go on and off during use. This is to keep the steam at the correct temperature.

  • Page 7: Floor Nozzle

    70530 Rev 4 2/6/04 2:53 PM Attaching tubes & handle WARNING: Unplug the unit and allow to cool before fitting or changing attachments as they become hot during use. Attach the desired accessory to the hose handle, extension tubes can be attached to the handle for extra reach.

  • Page 8: Accessory Adaptor

    70530 Rev 4 2/6/04 2:53 PM • The cleaning power of the cloth can be optimised by turning and changing the cleaning cloth regularly. • To clean very dirty areas, move the cleaning nozzle over the surface more slowly in order to increase the cleaning action of the steam.

  • Page 9: Tool Storage

    • During use the tubes and nozzle can be stored in the park position for short breaks whilst cleaning. Tool storage • The accessories for your steam cleaner can be neatly stored in the machine under your tool storage cover as shown.

  • Page 10: After Use

    70530 Rev 4 2/6/04 2:53 PM After use 1 Switch the cleaner off and unplug from the socket. Wait until the cleaner has cooled down completely. 2 Release any steam pressure by pressing the steam trigger on the handle 3 Apply the steam safety lock. 4 Remove the filler cap.

  • Page 11: Care And Maintenance

    70530 Rev 4 2/6/04 2:53 PM Care and maintenance Your cleaner is manufactured to withstand normal day-to-day use, but an occasional wipe over with a damp cloth will help maintain its good looks. Abrasive cleaners should not be used. Purchasing parts Use original parts.
  • Page 12 70530 Rev 4 2/6/04 2:53 PM Your two year guarantee It is important to retain the retailers receipt as proof of purchase. Staple your receipt to this back cover for future reference. Please quote the following information if the product develops a fault. These numbers can be found on the base of the product.
