EDIT Menu
4A 154
www.valuetronics.com
Step 3: Use the general purpose knob to specify the position to paste
the copied line with the inverted display cursor. The position for pasting
is directly before the inverted display cursor in the equation list.
Step 4: Select Paste from Buffer from the side menu.

Insert Other Equation File

Use Insert Other Equation to select an equation file from internal memory
(see Figure 4A 116). An equation file is inserted from this list into the equa
tion list.

Figure 4A 116: Menu Displayed When Insert Other Equation is Selected

Procedure
Step 1: Use the same procedure as described in Cutting a Line to line
up the inverted display cursor with the line where the other equation file
is to be inserted.
Step 2: Select Insert Other Equation from the side menu.
Step 3: Use the general purpose knob to select the equation file to be
inserted.
Step 4: After selecting the file, press the O.K. side menu button to
insert the selected file directly before the inverted cursor within the
equation list. Press the Cancel side menu button to cancel the selection
and return the system to the equation editor.
