Summary of Contents for Tektronix A6302
- Page 1 Instructions A6302 & A6302XL 20 Ampere AC/DC Current Probes 070-3905-04 Warning The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so. Refer to all safety summaries prior to...
- Page 2 Copyright Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved. Printed in the U.S.A. Tektronix, Inc., P.O. Box 1000, Wilsonville, OR 97070–1000...
- Page 3 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located.
- Page 4 Eliminates unexpected service expenses For Information and Ordering For more information or to order Service Assurance, contact your Tektronix representative and provide the information below. Service Assurance may not be available in locations outside the United States of America. Name...
-
Page 5: Table Of Contents
........A6302 and A6302XL Instructions... - Page 6 Figure 4: A6302 and A6302XL specified operating area ... Figure 5: A6302 and A6302XL frequency derating curve for maximum input current ......... . .
-
Page 7: General Safety Summary
Do Not Operate With Suspected Failures. If you suspect there is damage to this Precautions product, have it inspected by qualified service personnel. Do Not Immerse in Liquids. Clean the probe using only a damp cloth. Refer to cleaning instructions. A6302 and A6302XL Instructions... - Page 8 Symbols on the Product. The following symbols may appear on the product: DANGER Protective Ground ATTENTION Double High Voltage (Earth) Terminal Refer to Manual Insulated Certifications and Refer to the specifications section for a listing of certifications and compliances Compliances that apply to this product. A6302 and A6302XL Instructions...
- Page 9 Preface This instruction manual supports the operation and maintenance of the A6302 and A6302XL current probes with any of the AM 503 series current probe amplifiers. You can find additional documentation supporting the operation and maintenance of the AM 503 series amplifiers in the following manuals:...
- Page 10 Preface A6302 and A6302XL Instructions...
-
Page 11: Getting Started
11A16 plug-in. With the AM 503 family, the A6302 can measure currents to 20 A (DC + peak AC), and up to 50 A peak current (while not exceeding the amp-second rating). With the 11A16 plug-in, the A6302 can measure currents to 10.5 A. -
Page 12: Probe Installation
Current probe connector Current probe connector Amplifier Groove Slot Alignment dot (a) Align the tab with the connector slot (b) Insert the connector into the amplifier Figure 1: Connecting a current probe to the current probe amplifier A6302 and A6302XL Instructions... -
Page 13: Operating The Current Probe Slide
Figure 2 illustrates the slide operation of the probe. To open the probe, pull the slide back until the jaw is open. To lock the probe, push the slide forward until the detent snaps into place. Probe open Probe locked Figure 2: Operating the probe slide A6302 and A6302XL Instructions... -
Page 14: Degaussing And Autobalancing The Current Probe
Probe trim adjust is a multiplicative factor that you can use to adjust the gain of the current amplifier system. You can set this multiplier in increments of 0.001 from 0.750 through 1.250. Probe trim adjust is used for an optional calibration of A6302 and A6302XL Instructions... -
Page 15: Maximum Current Limits
Ampere-second product rating of the probe. Exceeding these ratings can magnetize the probe and cause measurement errors. To determine if your measurement exceeds the Ampere-second product, perform either Procedure A or Procedure B: A6302 and A6302XL Instructions... -
Page 16: Figure 3: Applying The Amp-Second Product Rule
For example, the A6302 current probe has a maximum Ampere-second product of 100 A s. If a pulse measured with an A6302 probe has a peak current of 40 A, the maximum allowable pulse width would be 100 A s divided by 40 A, or 2.5 s. - Page 17 For example, the A6302 current probe has a maximum Ampere-second product of 100 A s. If a pulse measured with an A6302 probe has a width of 3 s, the maximum allowable peak current would be 100 A s divided by 3 s, or 33.3 A.
-
Page 18: Specifications
4. The bandwidth of the measurement instrument must be limited to 200 MHz. Mechanical, electrical, and environmental characteristics for the A6302 and A6302XL current probes are listed in Tables 2 through 4 and Figures 4 through 7. -
Page 19: Figure 4: A6302 And A6302Xl Specified Operating Area
Amp-second product limit = 100 A Maximum continuous input ( 20 A) Any width Allowable pulse width (microseconds) Figure 4: A6302 and A6302XL specified operating area Frequency Figure 5: A6302 and A6302XL frequency derating curve for maximum input current A6302 and A6302XL Instructions... -
Page 20: Figure 6: A6302 And A6302Xl Insertion Impedance Curve
Specifications Typical impedance Impedance deviation Frequency (MHz) Figure 6: A6302 and A6302XL insertion impedance curve Table 3: Mechanical characteristics Probe dimensions Length: 20 cm (7.77 inches) Width: 1.6 cm (0.625 inches) Height: 3.2 cm (1.25 inches) Cable length A6302: 2 m (6.6 feet) A6302XL: 8 m (26.25 feet) -
Page 21: Table 4: Environmental Characteristics
Random vibration Operating 0.31 g , 5 to 500 Hz, 10 minutes on each axis Tektronix Std. 062–2858–00, Rev. B, Class 3 Table 5 lists the product certifications and compliances. Table 5: Certifications and compliances EC Declaration of Conformity Meets intent of Low Voltage Directive 73/23/EEC for Product Safety. Compliance was... -
Page 22: Maintenance
Maintenance This section explains how to clean the A6302 and A6302XL current probes and, if necessary, disassemble a probe for maintenance or repair. Also included are instructions for preparing a probe for shipment. WARNING. Probe disassembly should only be performed by qualified service personnel. -
Page 23: Figure 8: Removing The Strain Relief Boot
3. Hold the probe in a top-up horizontal position and slide the top half of the probe body off as shown in Figure 9. 4. Remove the metal ball. 5. Turn the probe upside down, push the slide back slightly, and remove the slide (see Figure 10). A6302 and A6302XL Instructions... -
Page 24: Figure 9: Removing The Top Half Of The Probe
(2) Grasp the top half of the probe body here with your other hand, then (a) push the slide back slightly, and (b) withdraw the slide from the probe body Figure 10: Removing the probe slide A6302 and A6302XL Instructions... -
Page 25: Figure 11: Removing The Current Transformer And Cable Assembly Of The A6302 Probe
Maintenance Replacing the Current Replace the current transformer or cable assembly of the A6302 probe as Transformer or Cable follows: Assembly of the 1. To remove the current transformer, lift the front edge of the circuit board and A6302 Probe transformer out of the probe and then pull the transformer socket off the circuit board pins. -
Page 26: Figure 12: Removing The Current Transformer Of The A6302Xl Probe
4. Probe reassembly is the reverse of steps 1 through 2 of this procedure and steps 1 through 5 on pages 12 through 14. NOTE. Exercise care when fitting the slide back into the probe body; aligning the switch contacts can require patience. A6302 and A6302XL Instructions... -
Page 27: Obtaining Replacement Parts
Refer to the Replaceable Parts List on page 18 for more informa- tion. Preparation for Shipment If you must ship your Tektronix product, please use the original packaging if possible. If the original packaging is unfit for use or not available, use the following packaging guidelines: 1. -
Page 28: Replaceable Parts
Replaceable Parts This section contains a list of the replaceable components for the A6302 and A6302XL current probes. Use this list to identify and order replacement parts. Parts Ordering Information Replacement parts are available through your local Tektronix field office or representative. - Page 29 Items in this section are referenced by figure and index numbers to the exploded view illustrations. Tektronix Part Number Use this part number when ordering replacement parts from Tektronix. 3 and 4 Serial Number Column three indicates the serial number at which the part was first effective. Column four indicates the serial number at which the part was discontinued.
- Page 30 Replaceable Parts A6302 Replaceable parts list Fig. & Tektronix Serial No. Serial No. Index Part Number Effective Discont’d Number Name & Description Mfr. Code Mfr. Part Number 13– ––––––––––– PROBE, CURRENT:A6302 –1 204–0288–03 BODY HALF,PROBE:UPPER BODY 80009 204–0288–03 HALF,BLACK,POLY –2 214–0835–00...
-
Page 31: Figure 13: A6302 Exploded View
Replaceable Parts A6302 BO64999 & below Figure 13: A6302 exploded view A6302 and A6302XL Instructions... - Page 32 CONTACT,ELEC:UPPER SHELF,CU BE 80009 214–0854–00 –11 351–0121–01 CONT ASSY,ELEC:PROBE SLIDE ASSY TK2565 351–0121–01 –12 214–0997–00 BALL,BEARING:0.094,SST 05469 ORDER BY DESC Standard Accessories –13 020–0167–01 ACCESSORY PKG: LEAD,ELECTRICAL,PROBE 80009 020–0167–01 GROUND;SDI,23 AWG,6.0 L 070–3905–04 MANUAL,TECH:INSTRUCTIONS,A6302,A6302XL,DP 80009 070–3905–04 A6302 and A6302XL Instructions...
-
Page 33: Figure 14: A6302Xl Exploded View
Replaceable Parts A6302XL BO10999 & below Figure 14: A6302XL exploded view A6302 and A6302XL Instructions... - Page 34 CONNOR FORMED METAL PRODUCTS 1729 JUNCTION AVENUE SAN JOSE, CA 95112 TK1947 NORTHWEST ETCH TECHNOLOGY 2601 S HOOD ST TACOMA, WA 98411–0610 PO BOX 110610 TK2565 VISION PLASTICS INC 26000 SW PARKWAY CENTER DRIVE WILSONVILLE, OR 97070 A6302 and A6302XL Instructions...
