School Pattern Dual Mixer
Installation and Maintenance Instructions
VP370
VP370C
VPQ370
technical data
Jumper Valve
Working Pressure Range
Maximum Static Pressure 1200 kPa
Maximum Working
Temperature
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00532_16 Feb 2024
1300 369 273 | info@enware.com.au | enware.com.au
Min 50 kPa
Max 500 kPa
95°C
Ceramic Disc
Working Pressure Range
Maximum Static Pressure 800 kPa
Maximum Working
Temperature
Min 50 kPa
Max 500 kPa
85°C
Advertisement
Related Manuals for Watts ENWARE VP370
Summary of Contents for Watts ENWARE VP370
- Page 1 School Pattern Dual Mixer Installation and Maintenance Instructions VP370 VP370C VPQ370 technical data Jumper Valve Ceramic Disc Working Pressure Range Min 50 kPa Working Pressure Range Min 50 kPa Max 500 kPa Max 500 kPa Maximum Static Pressure 1200 kPa Maximum Static Pressure 800 kPa 95°C 85°C...
-
Page 2: Installation Procedure
installation Ensure all supply lines are flushed thoroughly to remove debris prior to the installation of this product. Strainers (40 mesh) are recommended if debris is an ongoing problem. A pressure reduction valve may be required to comply with the recommended maximum supply pressure requirements. - Page 3 6. Remove grub screw from the tap base. Use a 2.5mm Allen key to unscrew. 7. Fit riser and/or diverter onto the tap base. To do this, firstly align the joints straight, then gently but firmly push the male double O-ring spigot into the female connection, taking care not to pinch or damage the O-rings while doing so.
- Page 4 AERATOR / TUBE NOZZLE Choose aerator or tube nozzle supplied, and screw onto spout. (VP370 model) Ensure the rubber washer is in place between spout and aerator or tube nozzle. SEE IMAGE 06 For Anti-Vandal aerator, use the supplied aerator key to fit aerator onto spout.
-
Page 5: Maintenance
maintenance ACCESS TO SBA SPINDLE Turn off the water supply to tap. Remove the insert from the handle by using the spanner key, then remove the handle. SEE IMAGE 04 & 05 Use the semi-circle cutout on the spanner key to push &... -
Page 6: Spare Parts
AERATOR Spout aerator should be checked and cleaned periodically for debris. Unscrew aerator housing on the spout to access the aerator. Inspect and reverse rinse aerator under running water to clear any debris. Replace aerator if necessary. IMAGE 08 CLEANING Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. -
Page 7: Troubleshooting
troubleshooting PROBLEM CAUSE RECTIFICATION Water leaking from outlet Jumper valve / SBA spindle Remove SBA and inspect. has debris caught in the Remove debris and clean. Water dripping and does mechanism. Install an inline strainer. not shut off Tap seat is damaged Refurbish tap seat using a reseating tool. -
Page 8: Product Warranty Statement
- WATTS AUSTRALIA Effective 27 October 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662...
