School Pattern Shower Outlet

Installation and Maintenance Instructions

VP310

technical data

Working Pressure Range

Maximum Working

Temperature

Flow Rate

Inlet Connection

Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.

Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.

Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government

regulations when considering the choice of, and the installation of these products.

This product must be installed and commissioned by a qualified plumber.

For use with potable water only.

NOTE: Enware Australia advises:

1. Due to ongoing Research and Development, specifications may change without notice.

2. Component specifications may change on some export models.

I00601_20 Dec 2023

1300 369 273 | info@enware.com.au | enware.com.au

Min 50 kPa

Max 500 kPa

70°C

8 L/min

1/2" BSP (15mm) Female

Need help?

Do you have a question about the ENWARE VP310 and is the answer not in the manual?

Page 1 School Pattern Shower Outlet Installation and Maintenance Instructions VP310 technical data Working Pressure Range Min 50 kPa Max 500 kPa Maximum Working 70°C Temperature 8 L/min Flow Rate 1/2” BSP (15mm) Female Inlet Connection Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500. Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Page 2 installation Ensure all supply lines are flushed thoroughly to remove debris prior to the installation of this product. Strainers (40 mesh) are recommended if debris is an ongoing problem. A pressure reduction valve may be required to comply with the recommended maximum supply pressure requirements.
Page 3 5. Screw wall base onto thread, all the way until wall base is tight against the finished wall. Use a spanner on the hex of the wall base to tighten. SEE IMAGE 03 6. Fit shower rose back onto wall. Push the shower rose all the way so that it is tight against the finished wall.
Page 4 - WATTS AUSTRALIA Effective 27 October 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662...
