- Page 1 ProLine Drying Cabinet TS 93 E Installation and operation manual Warning! Use safety glasses when building this equipment. Do not use this appliance until you 01/2025 have read these instructions! Product No. 233001/233002...
-
Page 2: Dear Customer
Dear Customer Sparing use of energy and short drying times help to ensure that We are pleased that you have chosen our drying cabinet. you can use your drying cabinet as economically as possible. Your new drying cabinet is the result of many years of develop- Please read these instructions carefully to enable you to use ment work. -
Page 3: Table Of Contents
Contents Safety regulations Important safety instructions Specification Dimensions Technical information Assembly instructions Installation of the cabinet Step 1: Put the cabinet in place Step 2: Fasten the cabinet to the wall Step 3: Connect the cabinet to the ventilation channel Step 4: Connect the drying cabinet to the main switch/breaker Step 5: Control that the heating relay is working Requirements for ventilation... -
Page 4: Safety Regulations
Safety regulations Important safety instructions Throughout this manual you will find text warnings in text boxes: “WARNING” and “CAUTION”. In these boxes you’ll find the safety measurements you’ll have to take; end user, service staff or instal- lation staff. WARNING CAUTION To minimize the risk of fire, electrical shock, personal injuries or death when the cabinet is in use the following precautions must... -
Page 5: Specification
Specification Dimensions Measurements shown in millimeter (mm). 1800 1. Electrical connection 2. Outlet exhaust... -
Page 6: Technical Information
Technical Information Machine type Drying cabinet Product No. 3P electrical connection 233001 Product No. 1P electrical connection 233002 Warrany 3 years limited Color Grey Mail data Type Air vented Hanging length (swinging hanging rail) ft/m 105/32 Capacity (dry weight) lb/kg 40/18 Interior capacity cu ft/L... -
Page 7: Assembly Instructions
Assembly instructions Tools You need the following tools to easily install the drying cabinet, : • Cordless screwdriver • Wrench • Hex key 3 and 5 mm • Level • Torx screwdriver bit no. 25... - Page 9 (repeat step 3-5)
- Page 16 WARNING When positioning the top, make sure no cables get caught between the top and the frame.
- Page 18 Connect the cables Light (LIGHT) Relay board Reläkort Humidity sensor (HUMIDITY) Control board Temp sensor (NTC1) Relay board (X11) Door switch (DOOR)
- Page 19 NOTE: Single Bar installation on page 22. 35 Nm...
- Page 21 To be completed after electrical connecteion. See page 24 for details.
- Page 22 Note! Only for cabinets with single rack bar Note! Only for cabinets with single rack bar Repeat on left side...
-
Page 23: Installation Of The Cabinet
Installation of the cabinet Step 1: Put the cabinet in place Step 3: Connect the cabinet to the ventilation channel Place the cabinet with enough space in front of the cabinet and on the sides to be able to open the doors. For further instructions, se page 25: Requirements for ventilation. -
Page 24: Step 4: Connect The Drying Cabinet To The Main Switch/Breaker
Step 4: Connect the drying cabinet to the WARNING main switch/breaker To prevent that fi re and electric shock appear, the cabinet MUST It is always the buyer that has the responsibility to check that be connected according to the color codes on the cables. Only an authorized electrician makes the electrical connections of an authorized electrician is allowed to install the electrical con- the cabinet. -
Page 25: Requirements For Ventilation
Requirements for ventilation Material, the design and the length of the channel have a large WARNING impact on the air flow. In order to get the best possible perfor- mance, the pressure fall shall be as low as possible. A drying cabinet produces inflammable dust. To minimize the When the air is transported through the channel, it is exposed to risk for fire, the evacuation of the cabinet must be connected different kind of resistance. -
Page 26: Evacuated Amount Of Air And Pressure Fall
Evacuated amount of air and pressure fall Decrease the outgoing air flow The cabinets function and automatic programmes are optimized In order to get TS 93 to work properly, the ventilation channel for the recommended air flow of 210 cfm / 350 m3/h. If the de- shall be designed to get an out coming air flow from the cabinet sign of the ventilation is made so that evacuated air flow exceeds of about 210 cfm / 350 m³/h. -
Page 27: User Manual
User manual Cool down Fill the cabinet All programs have a cool down phase of 10 minutes. This cool To get the best drying result: dry the same type of material at down time is included in the chosen time for the timed drying the same time. -
Page 28: Maintenance
Maintenance Take good care of the cabinet Only use a damp cloth with a mild detergent when cleaning the cabinet. Never use solvent to clean the display. Ventilation system Loosen the ventilation pipe on the cabinet every year and clean if necessary around the evacuating channel. -
Page 29: Warranty
Warranty Customer care If you have encountered a problem that you cannot resolve, please contact your dealer. www.podab.com +1 (800) 683-4873 support.na@podab.com When making contact, provide the details on the serial number plate. Include the product number (1) and the serial number (2). -
Page 30: Notes
Notes... - Page 31 Notes...
- Page 32 To minimize our environmental impact, we are limiting printed materials. Additional documents and information Copyright © 2025 PODAB. All rights reserved. about your machines can be found in the information We reserve the right to make changes without prior notice.
