Becker C33 PLUS Series Assembly And Operating Instructions Manual

Tubular drive with integrated radio transceiver for sun protection systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R20-17...R40-17
Model: C33 PLUS
Assembly and Operating Instructions
en
Tubular drive with integrated radio transceiver for
sun protection systems
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
2010 301 398 0     16/12/2024
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
info@becker-antriebe.com
www.becker-antriebe.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C33 PLUS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Becker C33 PLUS Series

Summary of Contents for Becker C33 PLUS Series

  • Page 1 Tubular drive with integrated radio transceiver for sun protection systems Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 2010 301 398 0     16/12/2024     Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany info@becker-antriebe.com www.becker-antriebe.com...

  • Page 2: Table Of Contents

    Table of contents General .................................... 3 Warranty .....................................  3 Safety instructions ................................ 4 Instructions for the user.............................. 4 Instructions for installation and commissioning........................ 4 Intended use .................................. 6 Assembling and disassembling the plug-in connecting cable.................... 6 Assembly ....................................  7 Compatible Centronic transmitters ............................ 10 Explanation of functions ..............................

  • Page 3: General

    General These tubular drives are high-quality products with the following features: • Optimised for sun protection applications • Tensile load is optimally adapted to the mechanical requirements of the sun protection system • Individual, group and central radio control • No need to run wires to a switch or relay control device •...

  • Page 4: Safety Instructions

    Safety instructions The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury. Instructions for the user General information • The drive must be disconnected from its power source during cleaning and maintenance and when re- placing parts.
  • Page 5 • If the drive is used for shading solutions in a specially marked area (e.g., escape routes, hazard zones, safety areas), compliance with all applicable regulations and standards must be ensured. • Once the drive has been installed, the fitter must mark the used tubular drive in the “Technical data” chapter and make a note of the installation position.

  • Page 6: Intended Use

    Intended use The type of tubular drive in these instructions is designed exclusively for operation of awnings with mechanical limiting in the Ex- tend limit position (e.g. the articulated arms cannot be extended completely). It may only be used in networked systems if all the individual drives are exactly synchronised and reach the limit positions at the same time.

  • Page 7: Assembly

    Assembly Assembling the drive Caution Electrical connections may only be carried out by a qualified electrician. Prior to assembly, the power supply must be disconnected and secured. Please give the enclosed connection information to the responsible electrical contractor. Attention To connect the drive to the driven part, solely mechanical accessory components made by the drive manufacturer from the current product catalogue may be used.
  • Page 8 Installing and removing the drive adapter for applications with separate emergency crank Caution Never screw the drive adapter to the shaft. Make absolutely sure that the installation dir- ection of the drive adapter is correct! The arrows on the white ring of the drive adapter must be pointing in the wind-up direction.
  • Page 9 Mounting the drive in the tube For profile shafts: In the case of some drive adapters, tolerances of the groove widths in different barrels can be offset by rotating the drive adapter into a different groove recess. These groove recesses have different sizes and allow the drive to fit exactly.

  • Page 10: Compatible Centronic Transmitters

    All CentronicPlus receivers can be operated with the Centronic transmitters listed in the Centronic/CentronicPlus compatibility table at www.becker-antriebe.com/downloads As two fundamentally different radio technologies are linked in this case, the full performance of the CentronicPlus radio control system is not available in this combination. When using the Centronic transmitter with CentronicPlus receiver, the range perform- ance may be reduced under certain circumstances.

  • Page 11: Commissioning With A Centronicplus Transmitter

    The receiver extends when it rains 15 min. Automatic Winter mode Automatic 3 min. 15 min. Commissioning with a CentronicPLUS transmitter Explanation of symbols Retract button STOP button Extend button Programming button (on the transmitter) Function button (on the transmitter) LED ring on the transmitter Receiver confirms once or multiple times by “clicking”...

  • Page 12: Establish Programming Mode

    Connecting the tubular drive Connect the tubular drive to the power supply. 230V AC / 50 Hz 1 = blue 3 = black 2 = brown 4 = green / yellow Switch on the power. ► The tubular drive confirms. Establish programming mode This step is only necessary if one of the devices to be programmed is not yet part of the in- stallation.

  • Page 13: Programming The Centronicplus Transmitter

    Programming the CentronicPLUS transmitter With brand new products, devices from another installation or products that have been re- stored to factory settings, programming mode must be established beforehand (see Es- tablishing programming mode). Bring the transmitter as close as possible to the receiver to be programmed. Press the programming button for 3 seconds when it is ready to program.

  • Page 14: Adding Additional Transmitters To The Installation

    Adding additional transmitters to the installation Press the programming button on an already programmed transmitter for 3 seconds. The transmitter performs a search and the LED ring continuously changes colour. The transmitter then switches to receiver selection and selects the receiver with the best connection quality.

  • Page 15: Checking That The Running Direction Is Correct

    Briefly press the programming button to change to the setting mode. ▻ The receiver confirms. ▻ The LED ring of the transmitter slowly pulses light blue. ▻ The receiver now enters dead-man mode. ► The setting mode is now active.   If a receiver has not yet been added to the installation (LED ring lights up yellow), it will not be possible to select it in this way.

  • Page 16: Intelligent Installation Management

    Then press the programming button for 3 seconds to change to normal mode. ► The LED ring goes out. Intelligent installation management Completion of installation following automatic setting of limit position "Stop" Next time the “stop” limit position is travelled to, this position will be provisionally saved as the limit position. Once the limit position has been detected at this position 3 times in a row without any problems, it will be definitively saved.

  • Page 17: Changing The Additional Stop Behaviour Function

    Changing the additional stop behaviour function On delivery, the drives have an increased stop behaviour. Proceed as follows to change the stop behaviour:   The "to retracted stop" limit position must be set in order to adjust the stop behaviour. The stop behaviour can be changed during the first 3 runs towards the stop.

  • Page 18: Setting The Limit Positions With Auto-Install

    Setting the limit positions with Auto-Install Intelligent installation management Completion of installation following automatic setting of limit position "Stop" Next time the “stop” limit position is travelled to, this position will be provisionally saved as the limit position. Once the limit position has been detected at this position 3 times in a row without any problems, it will be definitively saved.

  • Page 19: Deleting The Limit Positions

    Auto point to retracted stop (only with articulated-arm awnings) Attention Ensure that the cloth is not wound up the wrong way by the barrel. Extend Retract Select the required receiver as described in the chapter Selection of the receiver for the setting mode [} 14].

  • Page 20: Intermediate Positions I + Ii

    Intermediate positions I + II The intermediate positions I + II are freely selectable positions for the shading solution between the two limit positions. Each travel button can be assigned one intermediate posi- tion. Both limit positions must be set before an intermediate position is set. Setting/modifying the desired intermediate position Open/close the shading solution to the desired intermediate position.

  • Page 21: Restoring The Wireless Memory Of The Tubular Drive To Factory Settings

    Restoring the wireless memory of the tubular drive to factory settings There are a number of options: • Using a programmed CentronicPlus transmitter • Using the universal programming unit (item no. 4935 000 001 0) The set limit positions and all of the other set functions (intermediate position I, intermedi- ate position II, fabric untensioning, fabric stretching, stop behaviour, obstruction detec- tion) are retained.
  • Page 22 Using the universal programming unit (item no. 4935 000 001 0) Connect the wires of the tubular drive to those of the same colour in the programming unit. Connect the programming unit to the mains supply. Now press and hold the button "Tubular drive with electronic limit switching and ra- dio".

  • Page 23: Commissioning With A Centronic Transmitter

    Commissioning with a Centronic transmitter Explanation of symbols Retract button STOP button Extend button Programming button (on the transmitter) Receiver confirms once or multiple times by “clicking” or “shifting” 1 = direction switch 2 = radio switch Attention The tubular drives are designed for short-time operation. An inbuilt thermal protection switch prevents overheating of the tubular drive.

  • Page 24: Intelligent Installation Management

    Readying the tubular drive for programming by switching on the power Switch on the power. ▻ The tubular drive confirms. ► The tubular drive is ready to program for 3 minutes. If several tubular drives are to be connected in parallel, you can deactivate the program- ming mode on one tubular drive by switching the radio switch to the outside position after turning the power on.

  • Page 25: Setting The Limit Positions

    Switch the direction switch (1) to the opposite position. ▻ The running direction will now have changed. ► Check the running direction again. Changing direction of rotation via master transmitter Press the button. ▻ The shading solution runs in the desired direction. ►...

  • Page 26: Changing The Additional Stop Behaviour Function With The Master Transmitter

    Changing the additional stop behaviour function with the master transmitter On delivery, the drives have an increased stop behaviour. Proceed as follows to change the stop behaviour:   The "to retracted stop" limit position must be set in order to adjust the stop behaviour. The stop behaviour can be changed during the first 3 runs towards the stop.

  • Page 27: Setting The Limit Positions With Auto-Install

    Setting the limit positions with Auto-Install Intelligent installation management Completion of installation following automatic setting of limit position "Stop" Next time the “stop” limit position is travelled to, this position will be provisionally saved as the limit position. Once the limit position has been detected at this position 3 times in a row without any problems, it will be definitively saved.

  • Page 28: Deleting The Limit Positions

    Auto point to retracted stop (only with articulated-arm awnings) Attention Ensure that the cloth is not wound up the wrong way by the barrel. Extend Retract Extend the articulated-arm awning until the articulated arms are fully protracted and the cloth is lying loosely over them.

  • Page 29: Programming Additional Transmitters

    Travelling to the desired intermediate position Press the travel button for the desired intermediate position twice within one second. ► The curtain runs to the intermediate position assigned to the travel button. Deleting the desired intermediate position Move the shading solution to the intermediate position that is to be deleted. Now press the STOP button and, within 3 seconds, also press the travel button as- signed to the intermediate position and hold the two buttons down.

  • Page 30: Overwriting The Master

    Deleting all transmitters (except the master transmitter) Press the programming button on the master transmitter for 3 seconds. ▻ The tubular drive acknowledges. Re-press the programming button on the master transmitter for 3 seconds. ▻ The tubular drive acknowledges. Re-press the programming button on the master transmitter for 10 seconds. ▻...

  • Page 31: Additional Functions With Centronicplus / Centronic

    Additional functions with CentronicPLUS / Centronic Activating/deactivating the additional fabric untensioning function The "to retracted stop" limit position must be set for the fabric untensioning function. On delivery, the fabric untensioning function is activated. Activating/deactivating the fabric untensioning function with a CentronicPLUS transmitter Select the required receiver as described in the chapter Selection of the receiver for the setting mode [} 14].
  • Page 32 Deactivating the fabric tensioning function with a CentronicPLUS transmitter Select the required receiver as described in the chapter Selection of the receiver for the setting mode [} 14]. To deactivate it, move to the fabric tensioning limit position. Press the programming button and, within the next 3 seconds, press the STOP and buttons at the same time and hold the buttons down for 3 seconds.

  • Page 33: Local Operation With A Single Button

    Programming and deleting the run times Programming the run times This function is only available with MemoControl transmitters from the Becker Centronic range of control units. This tubular drive can save one switching time for one retraction and one extension cycle.

  • Page 34: Obstacle Detection

    Obstacle detection Caution Use of the drive’s obstacle detection system as personal protection is not permitted. It has been designed exclusively to protect the sun protection system from being damaged. If the drive is correctly installed, it switches off when it detects obstructions or fabric faults and tries to run past the obstruction a second time.

  • Page 35: Error Messages

    Error messages The tubular drive is blocked. ► The transmitter confirms with 10 red flashes of the LED ring. The tubular drive is overheated. ► The transmitter confirms with 5 red / yellow flashes of the LED ring. The tubular drive is not responding. ►...

  • Page 36: Sample Wiring Diagram

    Problem Remedy The LED ring lights up red when the receiver for the setting Reduce distance from receiver. mode is selected. Check electr. connection of the receiver. Put the receiver into programming mode. Add the transmitter to the installation. The required setting cannot be changed. Make sure that the CentronicPlus transmitter is in setting mode.

  • Page 37: Declaration Of Conformity

    Declaration of conformity 37 - en...

This manual is also suitable for:

R20-17-c33 plusR30-17-c33 plusR40-17-c33 plus
